Step
4
Ground circuit check
1) Turn ignition switch to OFF position.
2) Check for proper connection to junction block connector
at terminals "G271-3", "G272-9" and "L314-4".
3) If OK, then measure resistance between following
terminals.
• Between "G271-3" terminal of junction block
connector and vehicle body ground
• Between "G272-9" terminal of junction block
connector and vehicle body ground
• Between "L314-4" terminal of junction block connector
and vehicle body ground
Is each resistance 2
DTC B1133 (No. 1133): Battery Voltage Too High
Wiring Diagram
Refer to "BCM Power Circuit and Ground Circuit Check".
DTC Detecting Condition and Possible Cause
DTC detecting condition
Power voltage supplied from battery to BCM is
higher than 16 V.
Flow Test Description
Step 1: Check charging system
DTC Troubleshooting
Step
1
Charging system operation check
1) Check generator for operation referring to "Generator
Test (Overcharged Battery Check) in Section 1J".
Is it in good condition?
Action
Ω
or less?
• Charging system malfunction
• BCM malfunction
Action
Body Electrical Control System:
Yes
BCM power supply
circuit and ground circuit
are in good condition.
Possible cause
Yes
Substitute a known
good BCM (included in
junction block) and
recheck.
10B-18
No
Repair ground circuit.
S7RW0AA204008
No
Repair charging system.
