Model No. NTHK99900
Serial No.
Find the serial number in the location
shown below. Write the serial number
in the space above for reference.
Serial Number Decal
QUESTIONS?
As a manufacturer, we are com-
mitted to providing complete
customer satisfaction. If you
have questions, or if there are
missing parts, we will guarantee
complete satisfaction through di-
rect assistance from our factory.
TO AVOID UNNECESSARY DE-
LAYS, PLEASE CALL DIRECT TO
OUR TOLL-FREE CUSTOMER
HOT LINE. The trained techni-
cians on our Customer Hot Line
will provide immediate assis-
tance, free of charge to you.
CUSTOMER HOT LINE:
1-888-825-2588
Mon.–Fri., 6 a.m.–6 p.m. MST
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Save this manual
for future reference.
USER'S MANUAL
Visit our website at
www.nordictrack.com
new products, prizes,
fitness tips, and much more!
Patent Pending
Advertisement
Table of Contents
Related Manuals for NordicTrack NTHK99900
Summary of Contents for NordicTrack NTHK99900
- Page 1 Model No. NTHK99900 Serial No. Find the serial number in the location shown below. Write the serial number in the space above for reference. Serial Number Decal QUESTIONS? As a manufacturer, we are com- mitted to providing complete customer satisfaction. If you...
-
Page 2: Table Of Contents
LIMITED WARRANTY ............. .Back Cover Note: An EXPLODED DRAWING and a PART LIST are attached in the center of this manual. Save the EXPLODED DRAWING and the PART LIST for reference. NordicTrack is a registered trademark of ICON Health & Fitness, Inc. -
Page 3: Important Precautions
450 joules. The surge suppressor must be electrically rated for 120 volts AC and 15 amps. To purchase a surge suppressor, see your local NordicTrack dealer or call 1-888- 825-2588 and order part number 146148. 14. Keep the power cord and the surge suppres- sor away from heated surfaces. - Page 4 22. Never insert or drop any object into any opening. 23. When using iFit.com CD’s and videocassettes, an electronic “chirping” sound will alert you when the grade and/or speed of the hiker is about to change. Always listen for the “chirp” and be prepared for grade and/or speed changes.
-
Page 5: Before You Begin
The product model number is NTHK99900. The serial number can be found on a decal attached to the hiker (see the front cover of this manual for the location). -
Page 6: Assembly
Assembly Assembly requires two people. Set the hiker in a cleared area and remove all packing materials. Do not dis- pose of the packing materials until assembly is completed. Assembly requires the included allen wrench and your own Phillips screwdriver Note: The underside of the hiker walking belt is coated with high-performance lubricant. - Page 7 4. Set the Console (99) and the Handrail (27) on the floor. Locate the Handrail Wire Harness (30) in the Handrail (27). While a second person holds the Console (99), con- nect the 8-pin wire of the Handrail Wire Harness to the HD2 connector on the back of the Console.
-
Page 8: Operation And Adjustment
(see drawing 1 at the right). To purchase a surge suppressor, see your local NordicTrack dealer or call 1-888-825-2588 and order part number 146148. Use only a single-outlet surge suppressor that is UL 1449 listed as a transient voltage surge suppressor (TVSS). - Page 9 Note: If there is a thin sheet of clear plastic on the face of the console, remove it. FEATURES OF THE CONSOLE The revolutionary hiker combines state-of-the-art tech- nology with innovate design to provide you with a moti- vating and effective form of exercise in the convenience of your home.
- Page 10 CAUTION: Before operating the console, read the following precautions. • Do not stand on the walking belt when turn- ing on the power. • Always wear the clip (see the drawing below) while operating the hiker. • Adjust the speed in small increments to avoid sudden jumps in speed.
- Page 11 HOW TO USE THE MANUAL MODE Insert the key fully into the console. See GETTING STARTED on page 10. Select the manual mode. When the key is in- serted, the manual mode will automatically be selected, as shown by the Manual Control indicator.
- Page 12 The Distance/Time display—When the manual mode or an iFit.com program is se- lected, this display will show the distance you have hiked and the elapsed time. The distance will be shown for seven seconds and the time will be shown for fourteen seconds, as shown by the indi- cators around the display.
- Page 13 Press the Start button or the Speed + button to start the program. A moment after the button is pressed, the hiker will automatically adjust to the first grade and speed settings for the program. Hold the handrails and begin walking. Each program is divided into several time seg- ments of different lengths.
- Page 14 HOW TO CONNECT THE HIKER TO YOUR CD PLAYER, VCR, OR COMPUTER To use iFit.com CD’s, the hiker must be connected to your portable CD player, portable stereo, home stereo, or computer with CD player. See this page and page 15 for connecting instructions.
- Page 15 HOW TO CONNECT YOUR HOME STEREO Note: If your stereo has an unused LINE OUT jack, see instruction A below. If the LINE OUT jack is being used, see instruction B. A. Plug one end of the audio cable into the jack on the side of the hiker near the power cord.
- Page 16 HOW TO CONNECT YOUR VCR Note: If your VCR has an unused AUDIO OUT jack, see instruction A below. If the AUDIO OUT jack is being used, see instruction B. If you have a TV with a built-in VCR, see instruction B. If your VCR is connected to your home stereo, see HOW TO CONNECT YOUR HOME STEREO on page 15.
- Page 17 If the grade or speed settings are too high or too low, you can manually override the settings at any time by pressing the Grade or Speed buttons on the console. However, when the next “chirp” is heard, the speed and/or grade will change to the next settings of the CD or video program.
- Page 18 HOW TO USE PROGRAMS DIRECTLY FROM OUR INTERNET SITE Our new internet site at www.iFit.com allows you to access a selection of programs that interactively con- trol your hiker to help you achieve your specific exer- cise goals. In addition, you can play iFit.com audio and video programs directly from the internet.
- Page 19 THE INFORMATION MODE/DEMO MODE The console features an information mode that keeps track of the total number of hours that the hiker has been operated and the total number of miles that the walking belt has moved. The information mode also allows you to switch the console from miles to kilome- ters.
-
Page 20: How To Move The Hiker
How to Move the Hiker Before moving the hiker, change the grade of the hiker to the lowest level and unplug the power cord. 1. Hold the handrails as shown and place one foot against the walking belt. 2. Tilt the hiker back until it rolls freely on the wheels. The help of a second person may be helpful when tipping the hiker. - Page 21 PROBLEM: The power turns off during use SOLUTION: a. Check the circuit breaker located on the hiker near the power cord (see c. on page 20). If the cir- cuit breaker has tripped, wait for five minutes and then press the switch back in. b.
- Page 22 PROBLEM: The walking belt slows when walked on SOLUTION: a. Use only a UL-listed surge protector, rated at 15 amps, with a 14-gauge cord of five feet or less in length. b. If the walking belt is overtightened, hiker performance may decrease and the walking belt may become dam- aged.
-
Page 23: Conditioning Guidelines
Conditioning Guidelines WARNING: Before beginning this or any exercise program, consult your physi- cian. This is especially important for individu- als over the age of 35 or individuals with pre- existing health problems. The following guidelines will help you to plan your ex- ercise program. - Page 24 REMOVE THIS EXPLODED DRAWING AND PART LIST FROM THE MANUAL Save this EXPLODED DRAWING and PART LIST for future reference. Note: Specifications are subject to change without notice. For information about ordering replacement parts, see the back cover of the User’s Manual.
- Page 25 Part List—Model No. NTHK99900 No. Qty. Description Left Foot Rail Insert Left Foot Rail Motor Belt Platform Screw Belt Guide Small Screw Walking Platform Roller Guard Resistor Screw Walking Belt Drive Roller/Pulley Front Roller Clip Magnet Front Roller Cover Belly Pan Screw...
- Page 26 Exploded Drawing—Model No. NTHK99900 R0500A...
-
Page 27: Ordering Replacement Parts
If possible, place the hiker near your telephone for easy reference when calling. NordicTrack is a registered trademark of ICON Health & Fitness, Inc. ICON Health & Fitness, Inc. (ICON), warrants this product to be free from defects in workmanship and material, under normal use and service conditions, for a period of ninety (90) days from the date of pur- chase.
