Model No. NTL20920
Serial No.
Find the serial number in the location
shown below. Write the serial number
in the space above for reference.
Serial Number Decal
QUESTIONS?
If you have questions, or if there
are missing parts, we will guar-
antee complete satisfaction
through direct assistance from
our factory.
TO AVOID DELAYS, PLEASE
CALL DIRECT TO OUR TOLL-
FREE CUSTOMER HOT LINE.
The trained technicians on our
Customer Hot Line will provide
immediate assistance, free of
charge to you.
CUSTOMER HOT LINE:
1-888-825-2588
Mon.–Fri., 6 a.m.–6 p.m. MST
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Save this man-
ual for future reference.
USER'S MANUAL
Patent Pending
Visit our website at
www.nordictrack.com
new products, prizes,
fitness tips, and much more!

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 4500 R NTL20920 and is the answer not in the manual?

Questions and answers

Related Manuals for NordicTrack 4500 R NTL20920

Summary of Contents for NordicTrack 4500 R NTL20920

  • Page 1 Mon.–Fri., 6 a.m.–6 p.m. MST CAUTION Read all precautions and instruc- tions in this manual before using this equipment. Save this man- ual for future reference. USER'S MANUAL Patent Pending Visit our website at www.nordictrack.com new products, prizes, fitness tips, and much more!

  • Page 2: Table Of Contents

    HOW TO FOLD AND MOVE THE TREADMILL ........

  • Page 3: Important Precautions

    11. Use only a single-outlet surge suppressor that meets all of the specifications described on page 9. To purchase a surge suppressor, see your local NordicTrack dealer or call 1-800- 806-3651 and order part number 146148. 12. Failure to use a properly functioning surge suppressor could result in damage to the con- trol system of the treadmill.
  • Page 4 SAVE THESE INSTRUCTIONS The decal shown at the right has been placed on your treadmill. If the decal is miss- ing or illegible, please call our Customer Service Department, toll-free, to order a free replacement decal (see ORDERING REPLACEMENT PARTS on page 31).

  • Page 5: Before You Begin

    The model number of the treadmill is NTL20920. The serial number can be found on a decal attached to the treadmill (see the front cover of this manual for the location). Before reading further, please familiarize yourself with the parts that are labeled in the drawing below.

  • Page 6: Assembly

    Note: The underside of the treadmill walking belt is coated with high-performance lubricant. During shipping, a small amount of lubricant may be transferred to the top of the treadmill or the shipping carton. This is a normal condition and does not affect treadmill performance. If there is lubricant on top of the walking belt or foot pads, simply wipe off the lubricant with a soft cloth and a mild, non-abrasive cleaner.
  • Page 7 Press an Upright Endcap (118) into each Upright. 7. Make sure that all parts are properly tightened before you use the treadmill. Keep the included allen wrench in a secure place. The allen wrench is used to adjust the walking belt (see page 28). To protect the floor or carpet from damage, place a mat under the treadmill.
  • Page 8 If you purchase the optional chest pulse sensor (see page 25), follow the steps below to install the re- ceiver and the short jumper wire included with the chest pulse sensor. 1. Make sure that the power cord is unplugged. Remove the indicated screws from the Console Back (A).

  • Page 9: To Plug In Power Cord

    (see drawing 1 at the right). To purchase a surge sup- pressor, see your local NordicTrack dealer or call 1-800-806-3651 and order part number 146148. Use only a single-outlet surge suppressor that is UL 1449 listed as a transient voltage surge sup- pressor (TVSS).

  • Page 10: Features Of The Console

    Note: The fitness test program and the pulse-driven program require the use of an optional chest pulse sensor (see page 25).

  • Page 11: Getting Started

    Insert the key fully into the console. Stand on the foot pads of the treadmill. Attach the clip securely to the waistband of your clothes. Next, insert the key into the console. After a moment, various displays and indicators on the console will light.

  • Page 12: How To Use The Manual Mode

    The time will begin to flash in the main display. To restart the walking belt, press the Start button or the Speed + button. Note: During the first few minutes that the treadmill is used, inspect the alignment of the walking belt and align it if necessary (see page 28).
  • Page 13 Step onto the foot pads, press the Stop button, and adjust the incline of the treadmill to the lowest level. The incline must be at the lowest level when the treadmill is raised to the storage po- sition or the treadmill will be damaged.
  • Page 14 In addition, if the speed and/or the incline of the treadmill is about to change, the speed setting and/or the incline setting will flash in the main display to alert you, and three tones will sound.

  • Page 15: How To Create Custom Programs

    To program a speed setting and an incline setting for the first segment, simply adjust the speed and incline of the treadmill as desired by pressing the Speed and Incline buttons. Every few times one of the Speed buttons is pressed, an additional indicator will light or darken in the Current Segment column.

  • Page 16: How To Use Custom Programs

    The speed setting for the second segment will then be shown in the flashing Current Segment column and the treadmill will automatically adjust to the second speed and incline settings that you pro- grammed previously.

  • Page 17: How To Use The Fitness Test Program

    (level 1), indicating that the first four-minute level of the fitness test pro- gram has begun. The incline of the treadmill will automatically adjust to 3% and the walking belt will begin to move at 1.5 mph. Hold the handrails and begin walking.
  • Page 18 HOW TO USE THE PULSE-DRIVEN PROGRAM The pulse-driven program automatically adjusts the speed and incline of the treadmill to keep your heart rate near a target level during your workout. Note: You must wear the optional chest pulse sensor to use the pulse-driven program (see page 25).
  • Page 19 The heart rate setting for the second segment will then be shown in the flashing Current Segment column, and the speed and/or incline of the treadmill will change, if needed, to bring your heart rate closer to the heart rate setting for the second segment.
  • Page 20 B. A. Plug one end of the audio cable into the jack on the front of the treadmill near the power cord. Plug the other end of the cable into the LINE OUT jack on your CD player.
  • Page 21 B. A. Plug one end of the audio cable into the jack on the front of the treadmill near the power cord. Plug the other end of the cable into the included adapter. Plug the adapter into the LINE OUT jack on your stereo.
  • Page 22 CONNECT YOUR HOME STEREO on page 21. A. Plug one end of the audio cable into the jack on the front of the treadmill near the power cord. Plug the other end of the cable into the included adapter. Plug the adapter into the AUDIO OUT jack on your VCR.
  • Page 23 Stop button or remove the key and go to step 1 on page 22. Note: If the speed or incline of the treadmill does not change when a “chirp” is heard: • Make sure that the iFIT.com indicator is lit and that the time is not flashing in the main dis- play.
  • Page 24 Additional options are soon to be available. See www.iFIT.com for details. To use programs from our Web site, the treadmill must be connected to your home computer. See HOW TO CONNECT YOUR COMPUTER on page 21. In addition, you must have an internet connection and an internet service provider.
  • Page 25 “demo” mode. This mode is intended to be used only when a treadmill is displayed in a store. When the console is in the demo mode, the power cord can be plugged in, the key can be removed from the...

  • Page 26: How To Fold And Move The Treadmill

    HOW TO LOWER THE TREADMILL FOR USE 1. See drawing 2 above. Hold the upper end of the treadmill with your right hand as shown. Pull the lock knob to the left and hold it. Pivot the treadmill down until the frame is past the pin on the lock knob.

  • Page 27: Troubleshooting

    PROBLEM: The power turns off during use SOLUTION: a. Check the circuit breaker located on the treadmill frame near the power cord (see c. above). If the circuit breaker has tripped, wait for five minutes and then press the switch back in.
  • Page 28 SOLUTION: a. With the key in the console, press one of the incline buttons. While the incline is changing, re- move the key. After a few seconds, re-insert the key. The treadmill will automatically rise to the maximum incline level and then return to the minimum level. This will recalibrate the incline system.

  • Page 29: Conditioning Guidelines

    For maximum fat burning, adjust the speed and incline of the treadmill until your heart rate is near the middle number in your training zone. Aerobic Exercise If your goal is to strengthen your cardiovascular sys- tem, your exercise must be “aerobic.”...

  • Page 30: Part List

    PART LIST—Model No. NTL20920 To locate the parts listed below, see the EXPLODED DRAWING attached in the center of this manual. Key No. Qty. Description Allen Wrench Rear Wheel Bolt Rear Endcap (Left) Roller Star Washer Rear Roller Adj. Bolt Rear Wheel Frame Pivot Nut Front Endcap Screw...

  • Page 31: Ordering Replacement Parts

    • The MODEL NUMBER OF THE PRODUCT (NTL20920) • The NAME OF THE PRODUCT (NordicTrack • The SERIAL NUMBER OF THE PRODUCT (see the front cover of this manual) • The KEY NUMBER AND DESCRIPTION OF THE PART(S) (see the PART LIST on pages 30 and 31 and the EXPLODED DRAWING attached in the center of this manual) Key No.
  • Page 32 EXPLODED DRAWING—Model No. NTL20920 R0203A...
  • Page 33 EXPLODED DRAWING—Model No. NTL20920 R0203A...

  • Page 34: Limited Warranty

    WHAT IS COVERED—The entire NordicTrack ® 4500 R treadmill (“Product”) is warranted to be free of all defects in ma- terial and workmanship. WHO IS COVERED—The original purchaser or any person receiving the Product as a gift from the original purchaser.
