Model No. NTBE01490
Serial No.
USERÕS MANUAL
Write the serial number in the space
above for reference.
Serial Number Decal (under seat)
QUESTIONS?
As a manufacturer, we are com-
mitted to providing complete
customer satisfaction. If you
have questions or if there are
missing parts, we will guarantee
you complete satisfaction
through direct assistance from
our factory.
TO AVOID UNNECESSARY
DELAYS, PLEASE CALL DIRECT
TO OUR TOLL-FREE CUSTOMER
HOT LINE. The trained techni-
Patent Pending
cians on our customer hot line
will provide immediate assis-
tance, free of charge to you.
CUSTOMER HOT LINE:
1-888-825-2588
Mon.ÐFri., 6 a.m.Ð6 p.m. MST
CAUTION
Visit our website at
Read all precautions and instruc-
tions in this manual before
www.nordictrack.com
using this equipment. Save this
new products, prizes,
manual for future reference.
fitness tips, and much more!

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NTBE01490 and is the answer not in the manual?

Questions and answers

Related Manuals for NordicTrack NTBE01490

Summary of Contents for NordicTrack NTBE01490

  • Page 1 ¨ Model No. NTBE01490 Serial No. USERÕS MANUAL Write the serial number in the space above for reference. Serial Number Decal (under seat) QUESTIONS? As a manufacturer, we are com- mitted to providing complete customer satisfaction. If you have questions or if there are...

  • Page 2: Table Of Contents

    Limited Warranty ............. . . Back Cover NordicTrack ¨...

  • Page 3: Important Precautions

    Important Precautions WARNING: To reduce the risk of serious injury, read the following important precautions before using the weight bench. 1. Read all instructions in this manual before using the weight bench. 2. Use the weight bench only as described in this manual.

  • Page 4: Before You Begin

    Friday, 6 a.m. until 6 p.m. Mountain Time (excluding holidays). When calling, please mention the product model number and serial number. The model number is NTBE01490. The serial number can be found on a decal attached to the weight bench (see the front cover of this manual).

  • Page 5: Part Identification Chart

    Part Identification ChartÑModel No. NTBE01490 R1099A M6 x 38mm Bolt (28)Ñ1 M6 x 55mm Bolt (2)Ñ4 M6 x 16mm Screw (1)Ñ4 M10 x 70mm Bolt (23)Ñ2 M10 Nylon Locknut (6)Ñ10 M6 Washer (18)Ñ5 M10 x 80mm Bolt (25)Ñ1 M8 Nylon Locknut (30)Ñ1 M10 Washer (4)Ñ6...

  • Page 6: Assembly

    Assembly ¥ Place all parts in a cleared area and remove the packing materials. Do not dispose of the packing materials until assembly is completed. ¥ Tighten all parts as you assemble them, unless instructed to do otherwise. For help identifying small parts, use the PART IDENTIFICATION CHART on page 5.
  • Page 7 4. Press two 20mm x 40mm Inner Caps (17) into each Backrest Tube (16). Press four 20mm x 40mm Inner Caps (17) into the Backrest Adjustment Frame (19). Lubricate an M10 x 180mm Bolt (13). Attach the Backrest Tubes (16) to the welded tube on the Backrest Adjustment Frame (19) with the Bolt, two M10 Washers (4), and an M10 Nylon Locknut (6).
  • Page 8 8. Press a 25mm x 50mm Inner Cap (27) into the open end of the Seat Support Tube (20). Lubricate an M8 x 80mm Bolt (29). Attach the Seat Adjustment Bracket (22) to the indicated side of the Seat Support Tube (20) with the Bolt and an M8 Nylon Locknut (30).

  • Page 9: Adjusting The Weight Bench

    The weight bench is designed to be used with your own dumbbell set for a variety of exercises. In addition, the weight bench can be used with the optional NordicTrack muscle group of the body. The instructions below show how the backrest and the seat can be adjusted and how the curl pad is used.

  • Page 10: Part List

    Part ListÑModel No. NTBE01490 Key No. Qty. Description M6 x 16mm Screw M6 x 55mm Bolt Bench Frame M10 Washer 50mm x 70mm Outer Cap M10 Nylon Locknut Curl Pad Seat Backrest Support Plate 50mm Square Outer Cap Front Leg...

  • Page 11: Exploded Drawing

    Exploded DrawingÑModel No. NTBE01490 R1099A...

  • Page 12: Ordering Replacement Parts

    Friday, 6 a.m. until 6 p.m. Mountain Time (excluding holidays). To help us assist you, please be pre- pared to give the following information: ¥ The MODEL NUMBER of the product (NTBE01490) ¥ The NAME of the product (NordicTrack ¥...
