Pin No. Pin Name
35 SPEED CTL
36 MUTE
37 VSS1
38 PM CTL
39 LED AVLS
40 LED BL SKIP
41, 42 NC
43 AVDD
44 AVREF
TE
L 13942296513
www
.
http://www.xiaoyu163.com
I/O
Motor speed control signal output to the capstan/reel motor drive
O
"L": normal speed, "H": 1/2 speed
O Power on muting control signal output to the audio master amplifier "L": muting on
— Ground terminal
O Plunger drive signal output "L": plunger on
O LED drive signal output of the AVLS indicator "L": LED on
O LED drive signal output of the BL SKIP/s indicator "L": LED on
— Not used
— Power supply terminal (+2.5V) (for A/D converter)
I Reference voltage input terminal (+2.5V) (for A/D converter)
