  • Page 2 In Canada, products are distributed by Bombardier Recreational Products Inc. The following are trademarks of Bombardier Recreational Products Inc. or its sub- sidiaries. ® RER™ ® TRA™ SKI-DOO ROTAX HPG™ REV-XP™ SC™ XPS™ mmo2010-007 en AG ®™ and the BRP logo are trademarks of Bombardier Recreational Products Inc. or its affiliates.

  • Page 3: Foreword

    Bombardier Recreational Products injury. Inc. (BRP) warranty and a network of authorized Ski-Doo snowmobile deal- NOTICE Indicates an instruction ers ready to provide the parts, service which, if not followed, could se- or accessories you may require.

  • Page 4: Table Of Contents

    TABLE OF CONTENTS FOREWORD ................1 Know Before you Go .
  • Page 5 TABLE OF CONTENTS CONTROLS, INSTRUMENTS AND EQUIPMENT (cont’d) 10) Headlights Dimmer Switch (Tundra) ........35 11) Electronic Reverse Button (RER) (Tundra) .
  • Page 6 2010 SKI-DOO SNOWMOBILES ..............94...

  • Page 7: Safety Information

    SAFETY INFORMATION ________ ________ SAFETY INFORMATION...

  • Page 8: General Precautions

    Avoid Gasoline Fires and See your authorized Ski-Doo dealer for Other Hazards available accessories for your vehicle. Gasoline is extremely flammable and highly explosive. Fuel vapors can...

  • Page 9: Special Safety Messages

    SPECIAL SAFETY MESSAGES SEVERE INJURY OR DEATH can result if you do not follow these instructions: – Always make a pre-ride inspection BEFORE you start the engine. – Throttle mechanism should be checked for free movement and return to idle po- sition before starting engine.
  • Page 10 SPECIAL SAFETY MESSAGES – Remember, promotional material may show risky maneuvers performed by professional riders under ideal and/or controlled conditions. You should never attempt any such risky maneuvers if they are beyond your level of riding ability. – Never ride this vehicle under influence of alcohol or drugs. They slow reaction time and impair judgement.
  • Page 11 – Do not stud the track unless it has been approved for studs. At speed, a studded track that has not been approved for studs could tear and separate from vehicle posing a risk of severe injury or death. See an authorized Ski-Doo dealer for cur- rent specific studding availability and applications.

  • Page 12: Riding The Vehicle

    Replenish if necessary and those whom you allow to ride or drive. see an authorized Ski-Doo dealer in There may be noticeable handling and case of any leaks. performance differences from one 5.

  • Page 13: How To Ride

    RIDING THE VEHICLE Pre-Ride Check List ✔ ITEM OPERATION Body including seat, footrests, lights, air filter, controls and Check condition and remove snow or ice. instruments Skis and steering Check for free movement and proper action. Fuel and oil Check for proper level and leaks. Check for proper latching and no heavy or Storage compartment breakable objects.
  • Page 14 RIDING THE VEHICLE Include other items depending on the Posting length and time of your ride. A semi-sitting position with the body off the seat and the feet under the body Riding Position in a sort of squatting posture, thus al- Your riding position and balance are lowing the legs to absorb the shocks the two basic principles of making your...

  • Page 15: Carrying A Passenger

    RIDING THE VEHICLE Each operator has a responsibility to ensure the safety of his passengers and should inform them of snowmobil- ing basics. WARNING – Passengers must only sit on designated passenger seats. Never allow anyone to sit be- tween the handlebar and the mmo2008-003-004 operator.

  • Page 16: Terrain/Riding Variations

    RIDING THE VEHICLE Deep Snow WARNING In deep “powder” snow, your vehicle When riding with a passenger: could begin to “bog” down. If this oc- – Braking ability and steering curs, turn in as wide an arc as possible control are reduced. Decrease and look for a firmer base.
  • Page 17 RIDING THE VEHICLE yourself plenty of room for stopping If a higher than safe speed is reached, and turning. This is especially true at slow down by braking but apply the night. brake with frequent light pressure. Never jam the brake and lock the track. Hard Packed Snow Side Hill Don't underestimate hard packed...
  • Page 18 RIDING THE VEHICLE snowmobile ride. Even when fol- Jumping a snowmobile is an unsafe lowing existing tracks, be cautious. and dangerous practice. However, if Travel at a speed so you can see what the trail does suddenly drop away from is around the next bend or over the top you, crouch (stand) towards the rear of the hill.

  • Page 19: Environment

    RIDING THE VEHICLE the bank. Stop completely at the top the trail boss or, for that matter, any of the bank and wait for all traffic to other snowmobile. Use down-the-line clear. Judge the drop to the roadway. hand signals to indicate hazards or in- Cross the road at a 90°...
  • Page 20 RIDING THE VEHICLE The guidelines that we support are not to take the lead and take action. It ap- designed to limit your snowmobiling plies to the environment in general, its fun, but to preserve the beautiful free- proper care and maintenance, its natu- ral inhabitants and all enthusiasts and dom that you can experience only on a snowmobile! These guidelines will...
  • Page 21 So whether you're driving a high perfor- mance Ski-Doo, a sporty MX Z™ snow- mobile or any other make or model, show you know what you're doing.

  • Page 22: Traction Enhancing Products

    However, you MUST since that depends on your personal only use the BRP approved type preferences, your riding style, and how stud for use on these Ski-Doo your suspension is adjusted. snowmobiles. DO NOT EVER use conventional studs as the...

  • Page 23: Acceleration

    TRACTION ENHANCING PRODUCTS Understeering WARNING In certain conditions, the use of studs To prevent surprises that could on the track could make the snowmo- lead to a loss of control of the bile prone to understeering if the skis snowmobile: are not equipped with more aggressive –...

  • Page 24: Effects Of Having A Studded Track On The Life Of The Snowmobile

    TRACTION ENHANCING PRODUCTS Effects of Having a Installation of Studs on Studded Track on the BRP Approved Tracks Life of the Snowmobile WARNING The use of traction enhancing products can increase the load and the stress on Never stud a track that has not certain snowmobile components, as been approved for studs.

  • Page 25: Maintenance/Replacement

    TRACTION ENHANCING PRODUCTS – Broken studs (studded tracks) WARNING – Bent studs (studded tracks) – See authorized Ski-Doo – Missing studs dealer for current specific stud- – Studs that are torn off the track ding availability and applica- – Missing track guide(s) tions.

  • Page 26: Important On-Product Labels

    If missing or damaged, the decals can be replaced free of charge. See an au- thorized Ski-Doo dealer. NOTE: The following illustrations used in this Operator's Guide are a general representation only. Your model may differ.
  • Page 27 IMPORTANT ON-PRODUCT LABELS mmo2008-003-065_c TYPICAL - TUNDRA™ mmo2009-003-001_en INSTRUCTION 1 mmo2010-007-004_a TYPICAL INSTRUCTION 2 mmo2010-007-005_a TYPICAL INSTRUCTION 3 ________ ________ SAFETY INFORMATION...
  • Page 28 IMPORTANT ON-PRODUCT LABELS mmo2008-003-006_a TYPICAL - INSTRUCTION 4 mmo2007-009-058_en INSTRUCTION 7 - TUNDRA mmo2010-003-021_en INSTRUCTION 8 - TUNDRA SPORT mmo2009-003-002_en INSTRUCTION 5 mmo2010-007-001_en INSTRUCTION 8 - TUNDRA LT mmo2007-009-053_en INSTRUCTION 6 - TUNDRA _______ ________ SAFETY INFORMATION...
  • Page 29 IMPORTANT ON-PRODUCT LABELS mmo2006-003-007_a INSTRUCTION 10 - EUROPEAN MODELS mmo2010-003-003_en INSTRUCTION 9 - TUNDRA SPORT AND TUNDRA LT mmo2008-003-052_en INSTRUCTION 11 - MODELS WITH TRACK APPROVED FOR STUDS mmo2008-008-023 mmo2010-007-002_en ON BRAKE DISC GUARD INSTRUCTION 12 mmo2010-003-101_en ON SHOCK GAS CHARGED ABSORBERS ________ ________ SAFETY INFORMATION...

  • Page 30: Compliance Labels

    IMPORTANT ON-PRODUCT LABELS Compliance Labels Technical Information Labels EPA Compliance Label xxxx xxxx xxxx xxxx xxxx mmo2010-004-007_en INSTRUCTION 13 xxxx mmo2007-009-070 IN ENGINE COMPARTMENT SSCC Label mmo2007-009-051 INSTRUCTION 14 Safety standards for snowmobiles have been adopted by the Snowmo- bile Safety and Certification Commit- tee (SSCC) of which BRP is a proud participating member.

  • Page 31: Vehicle Information

    VEHICLE INFORMATION _______________...

  • Page 32: Controls, Instruments And Equipment

    CONTROLS, INSTRUMENTS AND EQUIPMENT NOTE: Some controls, instruments or equipment do not apply or are optional on some models. mmo2010-007-008_a TYPICAL TYPICAL mmo2010-007-009_a TUNDRA ______________...

  • Page 33: Handlebar

    CONTROLS, INSTRUMENTS AND EQUIPMENT mmo2010-007-003_b TYPICAL WARNING Fast reverse while turning, could result in loss of stability and con- trol. 2) Throttle Lever Throttle lever is located on the RH side of handlebar. mmo2008-003-069_g Designed to be thumb activated. TUNDRA LT When squeezed, it increases the en- gine speed and engages the transmis- 1) Handlebar...

  • Page 34: Brake Lever

    CONTROLS, INSTRUMENTS AND EQUIPMENT 4) Parking Brake Lever Parking brake is located on the LH side of handlebar. Parking brake should be used when- ever snowmobile is parked. mmo2008-008-011_b TYPICAL 1. Throttle lever 2. To accelerate 3. To decelerate WARNING Test the throttle lever operation each time before starting the en- mmo2008-008-012_c...

  • Page 35: Tether Stop Switch

    CONTROLS, INSTRUMENTS AND EQUIPMENT 6) Engine Stop Switch Engine stop switch is located on the RH side of handlebar. Push-pull type switch. To stop the en- gine in an emergency, select OFF posi- tion (down) and simultaneously apply the brake. To restart, button must be at the ON position (up).

  • Page 36: Ignition Switch

    If the switch has been used in an emergency caused by a suspected malfunction, the source of the mal- function should be determined and corrected before restarting engine. See an authorized Ski-Doo dealer for servicing. A06H1KA 1. OFF 7) Ignition Switch 2.

  • Page 37: Headlights Dimmer Switch (Tundra)

    CONTROLS, INSTRUMENTS AND EQUIPMENT Heated Grips Switch Select the switch position according to the desired heating intensity to keep your hands at a comfortable tempera- ture. mmo2010-007-006_a 1. Headlights dimmer switch 2. Low beam 3. High beam 11) Electronic Reverse Button (RER) (Tundra) The electronic reverse button is lo- mmo2007-003-003_b...

  • Page 38: Rewind Starter Handle

    CONTROLS, INSTRUMENTS AND EQUIPMENT mmo2010-007-007_a mmo2007-009-072_a 1. Heated grips and throttle lever switch 2. Hot 1. Seat latch 3. Warm Pull and hold seat latch, then, pull seat with a rearward movement. 13) Rewind Starter Handle Auto-rewind type located on right hand side of snowmobile.

  • Page 39: Tool Kit

    CONTROLS, INSTRUMENTS AND EQUIPMENT mmo2007-009-073_b mmo2008-003-061_a Step 1: Position seat in place TYPICAL Step 2: Push seat forward until it latch 1. Tool kit NOTE: A distinctive snap will be felt. 16) Grab Handle/Bumper Double check that the seat is secure by giving it a tug to confirm proper latch- To be used whenever snowmobile re- ing.

  • Page 40: Gauge

    4. Digital display NOTE: The gauge is factory preset in Imperial units but it is possible to change it to metric units, contact an authorized Ski-Doo dealer for unit set- tings. Speedometer Measures vehicle speed (in miles per hour or kilometers per hour depending on the setting).
  • Page 41 CONTROLS, INSTRUMENTS AND EQUIPMENT Pilot Lamps and Messages mmo2010-004-003_b 1. Digital display DISPLAY FEATURES FUNCTIONS REFER TO TOPICS mmo2010-004-005_a 1. Pilot lamps Odometer See table below for pilot lamps infor- Fuel level mation. A) Odometer PILOT LAMP(S) BEEPER DESCRIPTION Records the total distance travelled (in miles or kilometers depending on the Low fuel level.

  • Page 42: Mountain Strap

    CONTROLS, INSTRUMENTS AND EQUIPMENT 18) Mountain Strap How to Use the Hitch Detach hitch from its support by re- Tundra Sport and Tundra LT moving the hairpin. Mountain strap provides a grip for driver when side-hilling. WARNING This strap is not for towing, lift- ing or other purpose than tempo- rary use as a grab handle during side-hilling.
  • Page 43 CONTROLS, INSTRUMENTS AND EQUIPMENT mmo2008-003-072_a TYPICAL 1. Hairpin 2. Rod NOTICE To avoid damages to the vehicle, always release hitch from its support. Ensure hitch moves freely when towing accessories. mmo2008-003-073_a HITCH MOVES FREELY WHEN TOWING To avoid noise from hitch when not in use, secure hitch to its support by us- ing the hairpin.

  • Page 44: Fuel And Oil

    FUEL AND OIL Recommended Fuel Use unleaded gasoline available from most service stations or oxygenated fuel containing a maximum total of 10% of ethanol or methanol. The gaso- line used must have the following rec- ommended minimum octane rating. MINIMUM OCTANE RATING (550 F) mmo2008-008-004_a INSIDE NORTH TYPICAL...

  • Page 45: Injection Oil Level

    FUEL AND OIL If XPS Mineral Injection Oil is not avail- able, API TC high-quality low ash two- stroke injection oil may be used. NOTE: All XPS injection oils are com- patible, they can be mixed together. XPS mineral injection oil is a special blend of basic oil and additives espe- cially selected to ensure unequalled lu- brication, engine cleanliness and mini-...

  • Page 46: Operating Instructions

    8. Release parking brake. whichever comes first, your snow- NOTE: For an initial cold start, do not mobile be checked by an authorized release parking brake. Perform the MAINTE- Ski-Doo dealer. Refer to VEHICLE WARM-UP procedure as ex- NANCE INFORMATION section. plained below.

  • Page 47: Emergency Starting

    OPERATING INSTRUCTIONS NOTE: After the engine is started, let WARNING engine warm up at fast idle until engine Do not wind starting rope around speed drops. Then, close off choke to your hand. Hold rope by the han- ensure proper air-fuel mixture. dle only.

  • Page 48: Riding Conditions And Your Snowmobile

    Operating those vehicles above 600 m (2000 ft) requires parts and adjust- ments. NOTICE Failure re-calibrate may cause serious engine damage. Refer to an authorized Ski-Doo dealer for proper calibration modifications if required. mmo2008-005-012_a Temperature 1. Clip installation location This engine has been calibrated for Wind the rope tightly around drive pul- - 20°C (- 4°F).

  • Page 49: Reverse (Rer)

    OPERATING INSTRUCTIONS 4. Apply throttle until drive pulley en- – If engine is running at a speed above gages. Drive at low speed the first 4300 RPM, the function of the RER two or three minutes. button is disabled. – It is recommended to warm up the NOTICE If vehicle does not move engine to its normal operating tem-...

  • Page 50: Shutting Off The Engine

    OPERATING INSTRUCTIONS Shutting Off the Engine caution. In some areas, it may be ille- gal to do so. Check with state or local Release throttle lever and wait until en- authorities. gine has returned to idle speed. Remove the drive belt, attach the rope Shut off the engine using either igni- to the ski legs (spindles), have some- tion switch (key), engine stop switch...

  • Page 51: Tune Your Ride

    TUNE YOUR RIDE Snowmobile handling and comfort de- interrelated. It may be necessary to pend upon suspension adjustments. readjust center spring after adjusting front springs for instance. Test run the snowmobile under the same condi- WARNING tions; trail, speed, snow, driver riding Suspension adjustment could af- position, etc.
  • Page 52 TUNE YOUR RIDE Stopper strap length also has an effect miliarity with the various adjustments on center spring travel. as well as snow conditions will dictate the most efficient combination. NOTICE Whenever stopper strap Generally, a longer stopper strap set- length is changed, track tension ting gives better performance in deep must be checked.
  • Page 53 NOTE: If the specification is unattain- steering effort, handling and bump ab- able with the original springs, see an sorption. authorized Ski-Doo dealer for other Also, since center spring preload ad- available springs. justment puts more or less pressure NOTICE...
  • Page 54 TUNE YOUR RIDE ACTION RESULT ACTION RESULT Lighter steering More track surface on Increasing the ground More bump absorption preload capability Less extension lift Increasing Better deep snow starts Better reverse capability preload Decreasing especially in deep snow Better deep snow preload performance and More extension lift...
  • Page 55 TUNE YOUR RIDE RESULT SETTING Sets the suspension extension partially lifted and allows upwards movement Partial lift Better manoeuvrability on hard snow Better fuel efficiency mmo2010-007-024_a Good reverse capability PARTIALLY LIFTED 1. Adjustment cam Locks the suspension 2. Lower stop block extension in line with the suspension rails Locked...

  • Page 56: Adjustment Tips According To Vehicle Behavior

    TUNE YOUR RIDE Adjustment Tips According to Vehicle Behavior PROBLEM CORRECTIVE MEASURES Check ski alignment Front suspension darting – Increase center spring preload. – Reduce rear spring preload. Steering feels too heavy at steady – Increase center spring preload. speeds –...

  • Page 57: Vehicle Transportation

    VEHICLE TRANSPORTATION Make sure that oil reservoir and fuel tank caps are properly installed. Tilt bed trailers can easily be equipped with a winch mechanism to afford ma- ximum safety in loading. Simple as it may seem, never drive your snowmo- bile onto a tilt bed trailer or any other kind of trailer or vehicle.
  • Page 58 VEHICLE TRANSPORTATION ______________...

  • Page 59: Maintenance Information

    MAINTENANCE INFORMATION _______________...

  • Page 60: Maintenance Schedule

    Injection oil filter Oil injection pump FUEL SYSTEM Fuel stabilizer Fuel filter (2) Add to fuel prior to engine lubrication. Fuel lines and connections (3) Fuel filter must be replaced Carburetor venturi by an authorized Ski-Doo dealer. Throttle cable Air filter ______________...
  • Page 61 Drive belt (4) Adjust drive belt height and have the tension checked by an authorized Drive pulley Ski-Doo dealer at every belt replacement. (5) Tightening torque of drive pulley must be checked at the 10-hour inspection and Driven pulley every year or 3200 km (2000 mi) thereafter.
  • Page 62 Monthly or every 800 km (500 mi) L: Lubricate Every year or 3200 km (2000 mi) R: Replace Every 2 years or 6000 km (3700 mi) * To be performed by *Storage an authorized SKI-DOO dealer *Preseason PART/TASK LEGEND ELECTRICAL SYSTEM Spark plugs (10)

  • Page 63: 10-Hour Inspection

    10-HOUR INSPECTION We suggest that after the first 10 hours or 500 km (300 mi) of operation, whichever comes first, your vehicle be inspected by an authorized Ski-Doo dealer. The initial maintenance is very important and must not be neglected.

  • Page 64: Maintenance Procedures

    If not, see your authorized Ski-Doo dealer. Other important items in the mainte- nance schedule that are more difficult and require special tools are best per- formed by your authorized Ski-Doo mmo2010-007-012_a dealer. 1. Air filter NOTICE...

  • Page 65: Exhaust System

    MAINTENANCE PROCEDURES Exhaust System Exhaust System Verification The muffler tail pipe should be cen- tered with the exit hole in the bottom mmo2008-008-009 pan. Exhaust system must be free of 1. 19 mm socket 2. Screwdriver rod rust or leaks. Make sure that all parts are securely in place.

  • Page 66: Brake Fluid

    MAINTENANCE PROCEDURES Brake Fluid Recommended Fluid Use only DOT 4 brake fluid from a sealed container. An opened container may be contaminated or may have ab- sorbed moisture from the air. WARNING Use only DOT 4 brake fluid from a sealed container.

  • Page 67: Drive Belt Guard

    MAINTENANCE PROCEDURES Drive Belt Guard Drive Belt Guard Removal WARNING NEVER operate engine: – Without shields and belt guard securely installed. – With hood and/or side panels mmr2008-047-002_a opened or removed. 1. Magnetic check plug NEVER attempt to make adjust- ments to moving parts while en- NOTE: It is normal to find metallic par- gine is running.

  • Page 68: Spare Drive Belt

    MAINTENANCE PROCEDURES Drive Belt Guard Installation When reinstalling belt guard, position its cutaway toward front of snowmo- bile. 1. Place the front LH slot of the guard over the longest tab. 2. Pivot the guard inward to engage the shortest tab in the RH slot. mmo2008-003-063_a 1.
  • Page 69 MAINTENANCE PROCEDURES riod, burred or rusty sheave, oil on belt Drive Belt Installation or distorted spare belt. Contact an au- 1. If necessary, open the driven pul- thorized Ski-Doo dealer. DRIVE BELT REMOVAL ley, refer to above. Drive Belt Replacement 2.
  • Page 70 MAINTENANCE PROCEDURES BODY 2. Open LH side panel, refer to DRIVE 3. Remove belt guard, refer to BELT GUARD REMOVAL 4. Keep the set screws from turning using a 3 mm Allen key and loosen the three lock nuts using a 10 mm mmr2009-081-001_a open wrench.

  • Page 71: Drive Pulley

    MAINTENANCE PROCEDURES If the vehicle creeps, lower the drive belt height from the preliminary set- ting. Repeat procedure until creeping stops. Reverse Activation NOTE: The reverse may not activate or may be harder to activate if the belt is positioned too high in the driven pul- ley.

  • Page 72: Track

    Ski-Doo dealer. generated by the high rotational speed. Snowmobiles Equipped with See your Ski-Doo dealer to main- Traction Enhancing Products tain or service the drive pulley. Im- If your snowmobile is equipped with proper servicing or maintenance...
  • Page 73 MAINTENANCE PROCEDURES On approved studded tracks, replace Lift rear of snowmobile and support broken or damaged studs immediately. it with a wide-base snowmobile me- If your track shows signs of deteriora- chanical stand. tion, it must be replaced immediately. Allow the suspension to extend nor- When in doubt, ask your dealer.
  • Page 74 – Turn adjustment bolts to adjust. If correct tension is unattainable, con- tact an authorized Ski-Doo dealer. A01F05A 1. Guides 2. Slider shoes 3. Equal distance...

  • Page 75: Suspension

    (steering arms, tie rods, ski bolts, ski sive heat build-up and cause prema- legs, etc.). If necessary, contact an au- ture slider shoe wear. thorized Ski-Doo dealer. Suspension Stopper Strap Front Suspension Lubrication Condition Lubricate front suspension at grease...

  • Page 76: Skis

    If fuse has burnt out, source of mal- mmo2010-007-014_a function should be determined LH SIDE SHOWN and corrected before restarting. 1. Grease fitting See an authorized Ski-Doo dealer 2. Steering arm for servicing. Skis Fuse Location Wear and Condition of Skis and...

  • Page 77: Lights

    MAINTENANCE PROCEDURES mmo2007-009-016_b BEHIND AIR INTAKE SILENCER 1. Fuse location mmo2007-009-062_a TYPICAL Lights Always check light operation after bulb 3. Disconnect burnt bulb connector. replacement. Remove the rubber boot. Headlights Bulb Replacement NOTICE Never touch glass portion of an halogen bulb with bare fingers, it shortens its operating life.
  • Page 78 MAINTENANCE PROCEDURES NOTICE Taillight housing is held in place by two plastic pins inserted in rubber grommets. If taillight housing is forced too far sideways when removing, mounting pins may break and housing will have to be replaced. Do not pull taillight hous- ing out too far to avoid damaging wiring.

  • Page 79: Body

    MAINTENANCE PROCEDURES Body Hood WARNING Never operate engine with hood removed from vehicle. Hood Removal mmo2010-007-016_a 1. Unlatch both front rubber ties. 1. Rear hood slot 2. Console tab 3. Position hood outer tabs under the front rubber ties, then latch rubber ties.
  • Page 80 MAINTENANCE PROCEDURES mmo2010-007-012_b 1. Front rubber tie mmo2010-007-020_a LH SIDE SHOWN 1. Rear lower tab 2. Bottom pan slot mmo2010-007-018_a 1. Lower rubber tie 2. Upper rubber tie mmo2010-007-021_a 2. Pull panel backwards. LH SIDE SHOWN 1. Bottom pan slots Side Panel Installation 2.
  • Page 81 MAINTENANCE PROCEDURES To remove grease, oil and grime, use Heavy duty cleaner (P/N 293 110 001) (spray can 400 g) and (P/N 293 110 002) (4 L). NOTICE Do not use Heavy duty cleaner on decals or vinyl. To remove stubborn dirt from all plastic and vinyl surfaces, use Vinyl &...

  • Page 82: Storage And Preseason Preparation

    STORAGE AND PRESEASON PREPARATION NOTICE Have carburetors WARNING cleaned-up before restarting en- Have an authorized Ski-Doo dealer gine. inspect fuel and oil systems in- MAINTE- tegrity as specified in NANCE SCHEDULE Storage During summer, or when a snowmo- bile is not in use for more than three months, proper storage is a necessity.

  • Page 83: Technical Information

    TECHNICAL INFORMATION _______________...

  • Page 84: Vehicle Identification

    These numbers are required by the authorized Ski-Doo dealer to complete warranty claims properly. No warranty will be allowed by BRP if the engine identification number or vehicle identi- fication number (V.I.N.) is removed or...

  • Page 85: Ec Declaration Of Conformity

    The EC-Declaration of Conformity does not appear in this version of the Operator's Guide. Please refer to the printed version that was delivered with your vehicle. ddd2009-001...

  • Page 86: Epa Certified Engines

    For more detailed informa- When performing service on a certi- tion on this subject, you may contact fied Ski-Doo snowmobiles that carry the following locations: an emissions control information label, adjustments must be kept within pub- MAIL: lished factory specifications.

  • Page 87: Specifications

    SPECIFICATIONS MODEL TUNDRA, TUNDRA SPORT, TUNDRA LT ENGINE ® Rotax 552, fan-cooled (axial fan), Engine type cylinder reed porting Cylinders Displacement 553.4 cm³ (33.8 in³) Bore 76 mm (3 in) Stroke 61 mm (2.4 in) Maximum horsepower RPM 6800 RPM Carburetion 2 x VM-30 Exhaust system...
  • Page 88 SPECIFICATIONS MODEL TUNDRA, TUNDRA SPORT, TUNDRA LT DRIVE SYSTEM (cont'd) Tundra 31.8 mm (1.25 in) Tundra Sport Track profile height Tundra LT 38 mm (1.5 in) Deflection 30 mm to 35 mm (1-3/16 in to 1-3/8 in) Track tension Force 7.3 kg (16 lb) Equal distance between edges of track Track alignment...
  • Page 89 SPECIFICATIONS MODEL TUNDRA, TUNDRA SPORT, TUNDRA LT WEIGHT AND DIMENSIONS Tundra 190 kg (419 lb) Dry weight Tundra Sport 207 kg (456 lb) Tundra LT 216 kg (476 lb) Tundra 306.9 cm (120.8 in) Tundra Sport Vehicle overall length Tundra LT 332.9 cm (131.1 in) Vehicle overall width 100.2 cm (39.4 in)
  • Page 90 SPECIFICATIONS ______________...

  • Page 91: Troubleshooting

    TROUBLESHOOTING _______________...

  • Page 92: Troubleshooting Guidelines

    – If the drive belt has lost more than 3 mm (1/8 in) of its original width, it will af- fect vehicle performance. – Replace drive belt. 5. Incorrect track adjustment. – See MAINTENANCE PROCEDURES and/or an authorized Ski-Doo dealer for proper alignment and tension adjustments. ______________...
  • Page 93 – Clean/verify spark plug gap and identification number. Replace if required. 2. Too much oil supplied to engine. – Improper oil pump adjustment, refer to an authorized Ski-Doo dealer. 3. Water in fuel. – Drain fuel system and refill with fresh fuel.
  • Page 94 TROUBLESHOOTING GUIDELINES ______________...

  • Page 95: Warranty

    WARRANTY _______________...

  • Page 96: Brp Limited Warranty Usa And Canada: 2010 Ski-Doo

    All genuine Ski-Doo parts and accessories, installed by an authorized BRP dealer at the time of delivery of the 2010 Ski-Doo snowmobile, carry the same warranty as that of the snowmobile.
  • Page 97 This warranty coverage is available only if each of the following conditions has been fulfilled: – The 2010 Ski-Doo snowmobile must be purchased as new and unused by its first owner from a BRP dealer authorized to distribute Ski-Doo snowmobiles in the country in which the sale occurred (“BRP dealer”);...
  • Page 98 BRP’s obligations under this warranty are limited to, at its sole discretion, repairing parts found defective under normal use, maintenance and service, or replacing such parts with new genuine Ski-Doo parts without charge for parts and, at any authorized BRP dealer during the warranty coverage period under the conditions described herein.
  • Page 99 9) CONSUMER ASSISTANCE In the event of a controversy or a dispute in connection with this limited warranty, BRP suggests that you try to resolve the issue at the dealership level. We recom- mend discussing the issue with the authorized dealer's service manager or owner. If the issue has not yet been resolved, please submit your complaint in writing or call the appropriate number below: In Canada...

  • Page 100: Brp International Limited Warranty: 2010 Ski-Doo

    All genuine Ski-Doo parts and accessories, installed by an authorized BRP distributor/dealer at the time of delivery of the 2010 Ski-Doo snowmobile, carry the same warranty as that of the snowmobile. 2) LIMITATIONS OF LIABILITY...
  • Page 101 This warranty coverage is available only if each of the following conditions has been fulfilled: – The 2010 Ski-Doo snowmobile must be purchased as new and unused by its first owner from a BRP distributor/dealer authorized to distribute Ski-Doo snow- mobiles in the country in which the sale occurred (“BRP distributor/dealer”);...
  • Page 102 BRP’s obligations under this warranty are limited to, at its sole discretion, repairing parts found defective under normal use, maintenance and service, or replacing such parts with new genuine Ski-Doo parts without charge for parts and labour, at any authorized BRP distributor/dealer during the warranty coverage period under the conditions described herein.
  • Page 103 For European countries please contact our Finland office: BRP FINLAND OY Service Department Isoaavantie 7 FIN-96320 Rovaniemi Finland Tel.: +358 163 208 111 For countries within Middle East, Africa, CIS & Russia please contact our European office: BRP EUROPE N.V. Customer Assistance Center Skaldenstraat 125 9042 Gent...

  • Page 104: Brp Limited Warranty For The European Economic Area: 2010 Ski-Doo Snowmobiles

    All genuine Ski-Doo parts and accessories, installed by an authorized BRP distributor/dealer (at the time of delivery of the 2010 Ski-Doo snowmobile, carry the same warranty as that of the snowmobile.
  • Page 105 This warranty coverage is available only if each of the following conditions has been fulfilled: – The 2010 Ski-Doo snowmobile must be purchased as new and unused by its first owner from a BRP distributor/dealer authorized to distribute Ski-Doo products in the country in which the sale occurred (“BRP distributor/dealer”);...
  • Page 106 BRP’s obligations under this warranty are limited to, at its sole discretion, repairing parts found defective under normal use, maintenance and service, or replacing such parts with new genuine Ski-Doo parts without charge for parts and labour, at any authorized BRP distributor/dealer during the warranty coverage period under the conditions described herein.
  • Page 107 9) CONSUMER ASSISTANCE In the event of a controversy or a dispute in connection with this limited warranty, BRP suggests that you try to resolve the issue at the dealership level. We rec- ommend discussing the issue with the authorized distributor/dealer's service manager or owner.
  • Page 108 ______________...

  • Page 109: Customer Information

    CUSTOMER INFORMATION ______________...

  • Page 110: Privacy Obligation/Disclaimer

    PRIVACY OBLIGATION/DISCLAIMER We wish to inform you that your coordinates will be used for safety and warranty purposes. Sometimes, we also use the coordinates of our clients to inform them about our products and to present them offers. Should you prefer not to receive in- formation on our products, services and offers, please let us know by writing to the address below.

  • Page 111: Change Of Address/Ownership

    It is the owner’s responsibility to notify BRP. STOLEN UNITS: If your personal vehicle is stolen, you should notify BRP or an authorized Ski-Doo dealer. We will ask you to provide your name, address, phone number, the vehicle identification number and the date it was stolen.
  • Page 112 CHANGE OF ADDRESS/OWNERSHIP ______________...
  • Page 113 CHANGE OF ADDRESS/OWNERSHIP ______________...
  • Page 114 CHANGE OF ADDRESS/OWNERSHIP ______________...
