Parts Description - Air Cooler - Honeywell CO25MM Owner's Manual

Portable evaporative air cooler for outdoor, indoor & commercial use
Hide thumbs

Advertisement

PARTS DESCRIPTION - AIR COOLER

12
10
14
1 Tray for Tools
2 Left Side Panel
3 Control Panel
4 Horizontal Louvers
(Manual Adjustment)
5 Water Tank
6 Water Inlet Valve
7 Water Fill (continuous
water supply connection)
8 Water Fill (Manual Water Fill Hole)
10
11
10
9
16
15
9 Water Level Indicator
10 Lever for Horizontal Louvers
11 Right Side Panel
12 Back Panel
13 Drain Plug
14 Rear Grill Removal Screws
15 Honeycomb Cooling Media
16 Casters
1
8
2
3
4
5
6
7
13
