General - Sony Sa-Ts22W Service Manual
Surround speaker system
Table of Contents
Surround speaker (L)
The surround speaker (L) incorporates the IR receiver. It receives the sound from the IR transmitter and
sends it to the surround speaker (R).
Connect the surround speaker (R).
SERVICING NOTE
Label
After service, as shown in a figure,
a power cord is fixed.
power cord
SECTION 1
GENERAL
IR receiver
POWER
ON
OFF
ONLY FOR
DIR-R2
Rear side of the surround speaker (L)
SA-TS22W
Ver 1.1
This section is extracted
from instruction manual.
3
