Page 1: Quick Installation Guide
Heritage Series ADSL Bridge/ Router Multi-Mode ADSL Ethernet Router Quick Installation Guide July. 2003... - Page 2 Copyright All rights reserved. No part of this document may be reproduced in any form or by any means without written permission from the product manufacturer. Changes are periodically made to the information in this document. They will be incorporated in subsequent editions. The product manufacturer may make improvements and/or changes in the product described in this document at any time.
-
Page 3: Getting Started
Heritage Series ADSL Bridge/ Router Quick Guide Getting Started This quick guide provides a quick and easy way to install and configure your ADSL Ethernet Router to match which do you need. The major functions of the ADSL Ethernet Router are performed via Ethernet 10/100Base-T network interface. - Page 4 Quick Guide Collect the necessary information You need to gather the connection information supplied by your ADSL service provider. VPI value: ______ VCI value: ______ Encapsulation type: □LLC/SNAP or □VC/MUX For RFC1483 or RFC1577 Host: ______________________ Domain: ___________________ Gateway: __________________ IP address: _______________________ Subnet Mask: _____________________ DHCP Server IP : __________________...
-
Page 5: Hardware Installation
Heritage Series ADSL Bridge/ Router Quick Guide Hardware Installation Connect the ADSL cable and optional telephone Connect the Ethernet cable Attach the power connector Turn on the ADSL Ethernet router and power up your system. ADSL Ethernet Router AC adapter Wall outlet Straight-through cable to Hub for LAN PCs . - Page 6 Quick Guide How to login to Web-Configuration? Web-Configuration is designed to work best with Microsoft Internet Explorer® version 5.0, Netscape Navigator® version 4.7, or later versions. Please configure the IP of your computer in the same subnet as ADSL Ethernet Router. The DHCP server of ADSL Ethernet Router is enabled by default.
- Page 7 Heritage Series ADSL Bridge/ Router Quick Guide The’ System View’ page displays each time you login to the Web-Configuration. How to create your new connection, simply and quickly? Step 1. Login to Web-Configuration, then click Quick Configuration to begin your configure procedures.
- Page 8 Quick Guide Step 2. Quick Configuration sub-session will appears several setting items. Please refer to the settings table, which on next page, and choice a connection type which you want. Then fill in the correct settings/values in the fields of Quick Configuration session.
- Page 9 Heritage Series ADSL Bridge/ Router Quick Guide The settings table for Quick Configuration ATM Interface Operation Mode PPPoA Encapsulation VC-Mux or LLC VC-Mux or LLC VC-Mux or LLC VC-Mux or LLC Bridge IGMP IP address Subnet Mask Default Route Gateway IP Address Username Password Use DNS...
- Page 10 Quick Guide Step 3. Click Yes to continue. Step 4. Click Admin tab in Web-Configuration screen.
- Page 11 Heritage Series ADSL Bridge/ Router Quick Guide Step 5. Click Commit & Reboot tab in the Admin session. Step 6. Click Commit button in Commit & Reboot sub-session.
- Page 12 Quick Guide The browser will appear the successful message. Step 7. Choice Reboot From Default Configuration item in Reboot Mode selection in Commit & Reboot sub-session. Then click Reboot button to reboot your ADSL Ethernet Router. Please wait 15 ~ 20 seconds for rebooting procedures, meanwhile don’t turn the power of your ADSL Ethernet Router off.
- Page 13 Heritage Series ADSL Bridge/ Router Quick Guide How to restores the factory’s default settings of ADSL Ethernet Router? You can restore the factory’s default settings of ADSL Ethernet Router, if you needed. Step 1. Login to Web configuration first, then Click Admin tab in the Home session.
- Page 14 Quick Guide Step 3. Choice Reboot From Default Configuration item in Reboot Mode selection in Commit & Reboot sub-session. Then click Reboot button to reboot your ADSL Ethernet Router. Please wait 15 ~ 20 seconds for rebooting procedures, meanwhile don’t turn the power of your ADSL Ethernet Router off.
