Summary of Contents for Advanced PureAir Air Purifier NEWPORT 9000
- Page 1 Owner’s Manual Please read and fully understand this manual before operating your NEWPORT 9000.
- Page 2 Advanced PureAir Newport 9000 Owner’s Manual SAFETY OPERATION Please exercise caution when using the Newport 9000 or any other electrical device! This manual describes the safety precautions which should be observed in relation to your air purifier. Please review carefully SPECIAL ATTENTION The voltage rating for air purifiers sold in the USA, Japan and Canada is AC100-120V,...
- Page 3 Advanced PureAir Newport 9000 Owner’s Manual CONTROLS & AIR FLOW VENTS Front Face Plate Air Outlet Dust Sensor Air Inlets Air Inlets Front Panel Release Tabs Bottom Stand Soft Touch Control Panel Remote Control Odor Sensor ON/OFF FLOW AUTO ION UV TIMER...
- Page 4 Advanced PureAir Newport 9000 Owner’s Manual MAJOR COMPONENTS Back View Exploded Parts View...
- Page 5 Advanced PureAir Newport 9000 Owner’s Manual BEFORE USE Pre-Installation Air Ventilation Before plugging in the unit, please open the windows in the area where you will be using the unit. Ventilate the area for 2-3 hours if possible. Once the area has been ventilated, close the windows and plug in the unit.
- Page 6 Advanced PureAir Newport 9000 Owner’s Manual EXPLANATION OF INDICATORS Negative Ion Indicator During the process when negative ions are generated, the blue indicator on the Soft Touch Control Panel will gradually change from bright to dim and from dim back to bright every 5seconds. Odor Indicator The odor indicator on the Soft Touch Control Panel will glow whenever the odor sensor detects odor (such as indoor smoke).
- Page 7 Advanced PureAir Newport 9000 Owner’s Manual OPERATING INSTRUCTIONS Locate the Unit Place the Newport 9000 against a wall, near an electric outlet with 12-15 inches clearance on the front and sides. It is best to place the unit where it will be out of any children's play area. How to Start Plug the unit into a standard 120V/60Hz outlet.
- Page 8 Advanced PureAir Newport 9000 Owner’s Manual CLEANING AND MAINTENANCE Before starting any cleaning or maintenance, always turn-off and unplug the unit. Regular cleaning and maintenance is recommended every 2-3 months. Disassembling the Newport 9000 After unplugging, carefully lay the unit down face-up. Disassemble the unit in sequence of 1 to 5 as shown below.
- Page 9 Advanced PureAir Newport 9000 Owner’s Manual CLEANING AND MAINTENANCE ( CONT. ) Regular Cleaning and Maintenance Front Face Plate Can be cleaned with flowing water Please use a soft cloth to clean and avoid scraping off the paint on the cover Avoid cleaning with hot water or rubbing too hard or paint damage or deformation could occur.
- Page 10 Advanced PureAir Newport 9000 Owner’s Manual CLEANING AND MAINTENANCE ( CONT. ) Cleaning and Maintenance of the Washable Plasma Dust Filter The Washable Plasma Dust Filter needs cleaning when: 1) The cleaning indicator is glowing or blinking. 2) The dust collector is making electrical discharge sounds. 3) The device has been used frequently in an area with lower air quality condition.
- Page 11 Advanced PureAir Newport 9000 Owner’s Manual CLEANING AND MAINTENANCE ( CONT. ) The Cleaning and Maintenance of the Washable Plasma Dust Filter (Cont.) 4. Clean the Plasma Dust Filter Use mild detergent or plain water only. Use a soft scouring pad or toothbrush to clean the dust collector.
-
Page 12: Replacing Filters
Advanced PureAir Newport 9000 Owner’s Manual CLEANING AND MAINTENANCE ( CONT. ) -
Page 13: Odor Sensor
Advanced PureAir Newport 9000 Owner’s Manual FREQUENTLY ASKED QUESTIONS Air Quality Surveillance Why is there is only one LED glowing all the time with the air quality surveillance function? Indoor air has been clean the whole time. For testing purpose, dust either caused by a cigarette or a dusty cloth can be released near the irritant sensor. If the level of pollution goes up, then the unit should be operating properly. - Page 14 Advanced PureAir Newport 9000 Owner’s Manual FREQUENTLY ASKED QUESTIONS ( CONT. ) Filter Why is it so hard for the filter to get rid of dust and odors? Have the front and back of the HEPA/Charcoal filter been mistakenly reversed? The HEPA/Charcoal filter has been saturated with a serious amount of dust.
-
Page 15: Specifications
Advanced PureAir Newport 9000 Owner’s Manual TECHNICAL SPECIFICATIONS Real Spirit Style No.: Newport 9000 Rated Voltage: AC 120V/60Hz Power Consumption: Ion Output: ˃ 2 x 10 /cm Activated Oxygen Output: ˂ 0.05 ppm UV Spectrum: ˃ 20μ w/cm at 10 cm distance. PRODUCT SERVICING In case of any malfunction, contact your retailer or email us at info@realspiritusa.com.. - Page 16 Produced and distributed exclusively by: Real Spirit USA, Inc. • 9447 De Soto Ave • Chatsworth, CA 91311 Customer Service Phone 888.698.2080, ext. 210 www.AdvancedPureAir.com • info@RealSpiritUSA.com © Copyright Real Spirit USA, Inc. 2008. All Rights Reserved Manufactured in China...
Need help?
Do you have a question about the Air Purifier NEWPORT 9000 and is the answer not in the manual?
Questions and answers
The air flow is set to "auto" but the flow remains on "high"....never shifts back to "low" like it has in the past.
The Advanced PureAir Newport 9000 stays on "high" airflow when set to "auto" because the sensor detects a high level of odor, dust, or irritants in the air. In automatic operation, the device adjusts the fan speed based on air quality, running at higher speeds when more pollutants are present. Once the air becomes cleaner, it will automatically switch to lower modes like "LOW" or "QUIET."
This answer is automatically generated
Hi flow setting does not work
If the flow setting on the Advanced PureAir Air Purifier NEWPORT 9000 does not work, check that the unit is properly plugged into a power outlet and ensure it has been correctly reassembled after cleaning. The unit will not operate if the Washable Plasma Dust Filter or the Front Face Plate is not properly installed.
This answer is automatically generated
