- Page 1 Call 1-800-667-8721 anywhere in the US and Canada - www.rangehoods.com Model E54000 ENGLISH........2 ::rangehoods.com accessories kitchen:: Broan at is a division of...
- Page 2 C. The fire department is being called. D. You can fight the fire with your back to an exit. * Based on “Kitchen Fire Safety Tips” published by NFPA. - 2 - ::rangehoods.com accessories kitchen:: Broan at is a division of...
- Page 3 10. Use with approved cord-connection kit only. 11. Please read specification label on product for further information and requirements. - 3 - ::rangehoods.com accessories kitchen:: Broan at is a division of...
-
Page 4: Operation
Max, G-4 Base halogen bulb. Do not touch FIG. 2 replacement bulb with bare hands! Do not use bulbs greater then 20 Watts. Bulbs greater than 20 Watts will cause fuse to open. - 4 - ::rangehoods.com accessories kitchen:: Broan at is a division of... -
Page 5: Fuse Replacement
Fuses greater than 4 amps may damage the transformer. FUSE FIG. 3 5. Reinstall the fuse holder cap, fuse box cover and grease filters. 6. Reconnect power at the service entrance. - 5 - ::rangehoods.com accessories kitchen:: Broan at is a division of... -
Page 6: Maintenance
Rinse with water after exposure and wipe dry with a clean cloth. Painted surfaces should be cleaned with warm water and mild detergent only. - 6 - ::rangehoods.com accessories kitchen:: Broan at is a division of... -
Page 7: Prepare The Hood
DECORATIVE SUPPORT FLUE FRAME 14 MOUNTING SCREWS (3.9 x 9.5mm Pan Head) 6 SERRATED 4 WASHERS 2 MOUNTING WASHERS 6.4mm SCREWS (2.9 x 9.5mm Pan Head) FIG. 4 - 7 - ::rangehoods.com accessories kitchen:: Broan at is a division of... -
Page 8: Install The Ductwork
B (6x70mm) corresponds to the controls side. Fig. 2. FIG. 6 TOP VIEW OF SUPPORT FRAME ” ” 3” ” FIG. 7 - 8 - ::rangehoods.com accessories kitchen:: Broan at is a division of... - Page 9 5. Discard the upper support frame half supplied with the range hood. Replace with the longer upper support frame supplied with the flue extension. 6. Follow steps 1 through 4 shown above. - 9 - ::rangehoods.com accessories kitchen:: Broan at is a division of...
- Page 10 Install the 5” to 6” adapter (supplied with the non-ducted recirculation kit) over the blower discharge. Fig. 12. 2. Duct tape alljoints to make them secure and air tight. FIG.12 - 10 - ::rangehoods.com accessories kitchen:: Broan at is a division of...
- Page 11 Replace with the upper flue FIG.15 supplied with flue extension model FX54SS. 3. Install and secure the upper flue to the support frame with (2) 2.9x9.5mm mounting screws. - 11 - ::rangehoods.com accessories kitchen:: Broan at is a division of...
-
Page 12: Install The Hood
SERRATED hood. WASHERS 1. Secure the hood to the support frame with (6) 3.9x9.5mm mounting screws and (2) serrated washers. Fig. 18. MOUNTING SCREWS (3.9x9.5mm) FIG.18 - 12 - ::rangehoods.com accessories kitchen:: Broan at is a division of... -
Page 13: Install Electrical
7. Push wiring into the electrical box. Reinstall the wiring box cover. 8. Raise the upper flue and reinstall mounting screws. LINE IN 120 VOLTS - 60 HZ WIRING BOX COVER BLK-BLK WIRE CLAMP WHT-WHT GRN-GRN FIG.20 - 13 - ::rangehoods.com accessories kitchen:: Broan at is a division of... -
Page 14: Install Filters
Make sure the filter is securely engaged after as- sembly. 3. Install GREASE filter after charcoal filter CLAMP is installed. NON-DUCTED RECIRCULATION FILTER FIG.22 - 14 - ::rangehoods.com accessories kitchen:: Broan at is a division of...
