Expolite TourLED City User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
U s e r Ma n u a l
T o u r L E D C i t y

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TourLED City and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Expolite TourLED City

Summary of Contents for Expolite TourLED City

  • Page 1 U s e r Ma n u a l T o u r L E D C i t y...

  • Page 2: Table Of Contents

    ABLE OF CONTENTS PART 1 PRODUCT SPECIFICATIONS...........1. 1.1--PRODUCT FEATURES..............1. 1.2--TECHNICAL SPECIFICATIONS.............1. 1.3--DIMENSIONS................1. 1.4--SAFETY WARNING..............2. PART 2 INSTALLATION...............3. 2.1--MOUNTING..................3. 2.2--POWER CONNECTIONS...............4. 2.3-- SIGNAL CONNECTIONS ...............4. PART 3 USING CODER ..............5. 3.1-- BASIC ..................5. 3.2-- MENU ..................6. 3.3--EDIT STATIC COLOUR..............7. 3.4--ACTIVATING AUTO PROGRAMS...........7. 3.5--DMX512 SETTINGS..............7.

  • Page 3: Part 1 Product Specifications

    1 PRODUCT SPECIFICATIONS PRODUCT FEATURES LED FIXTURE * Setting:LED display * Operation:DMX512/Static Play/Custion/Wireless * Function:RGBW 0-100%dimming;Linear/Nonlinear dimming;RGBW Calibration; * Installation:Bracket * Power:3 core in * Data :5 core in/out cable TECHNICAL SPECIFICATIONS LED MODULE LED MODULE: Voltage 100~240V...50/60Hz 650W Power 3W x 44 GREEN 3W x 44...

  • Page 4: Safety Warning

    SAFETY WARNING IMPORTANT ALWAYS READ THE USER MANUAL BEFORE OPERATION. PLEASE CONFIRM THAT THE POWER SUPPLY STATED ON THE PRODUCT IS THE SAME AS THE MAINS POWER SUPPLY IN YOUR AREA. This product must be installed by a qualified professional. Always operate the equipment as described in the user manual.

  • Page 5: Part 2 Installation

    2 INSTALLATION MOUNTING UPRIGHT The LED Fixture can be mounted in a sitting or wall mounted position using the supporting brackets. The LED Fixture should be placed on a non-flammable flat surface in any orientation and fixed by screws. There are four holes into the supporting bracket. HANGING: Ensure that fixture is mounted to a structure that is correct and suitable for hanging this kind of lighting fixture...

  • Page 6: Power Connections

    POWER CONNECTIONS GND E Data N Data L AC Power IN SIGNAL CONNECTIONS DMX OUT DMX IN 1 -GND 2 -Data - 3 -Data +...

  • Page 7: Part 3 Using Coder

    3 USING CODER 3.1 BASIC The LED fixture is mounted with a LCD display and 4 control buttons. MENU DOWN scroll through the main menu or return to the main menu MENU enter the currently selected menu or confirm the current function value ENTER scroll 'UP' through the menu list or increase the value of the current function scroll 'DOWN' through the menu list or decrease the value of the current function...

  • Page 8: Menu

    MENU MENU R.(0~255) STAT GREN G.(0~255) B.(0~255) BLUE WHIT W.(0~255) A.(0~255) AMBE S.(0~20) STRB AUTO AT.01 AT.02 AT.10 PR.01 PR.02 PR.10 ADDR D.(001~512) SLAV PERS TOUR ARC.1 AR1.D ARC.3 AR3.D AR3.S BLOC I.(01~66) PASS UPLD SEND REST PASS REST ID.ON DIM4 DIM1 DIM2...

  • Page 9: Edit Static Colour

    EDIT STATIC COLOUR MENU STAT (0~255) (0~255) Green Blue (0~255) White (0~255) Amber (0~255) (0~255) Amber Strob (0~20) STATIC COLOUR Combine Red , Green , Blue , White , Amber Amber to create an infinite range of colors (0-255) Set the value of the Strobe (0-20Hz) ACTIVATING AUTO PROGRAMS...

  • Page 10: Run Mode

    RUN MODE MENU SLAV Enter the RUN mode to set working mode. mode is for using the DMX512 controller to control the fixtures. SLAV mode is for Master -- Slave operation. PERSONALITY MENU PERS TOUR ARC.1 AR1.D ARC.3 AR3.D AR3.S BLOC PERSONALITY Enter the PERSONALITY mode to select DMX mode: TOUR , ARC.1 ,...

  • Page 11: Editing Custom Programs

    SETTING Select UPLD to upload the custom programs from the current MASTER unit to the SLAVE units. In order to activate the upload function the password must be entered. Password is the same as the main access password. When uploading the MASTER and SLAVE units will display YELLOW. If an error occurs when uploading the MASTER and/or SLAVE units will display RED.

  • Page 12: Rgb Calibration

    3.12 RGB CALIBRATION MENU (0~255) CAL2 RGBW Green (0~255) (0~255) Blue CAL2 Enter the CAL2 to adjust the RGB parameter to make different whites. When the new setting is activated, the DMX controller choose RGB = 255,255,255, the white color will be made by the actual RGB values on CAL2 3.13 WDMX SETTINGS...

  • Page 13: Part 4 Using Dmx512 Controller

    4 USING A DMX512 CONTROLLER BASIC ADDRESSING Set the DMX512 address in the DMX menu. It is possible to have the same DMX address or independent addresses for each fixture. CHANNEL ASSIGNMENT Note:This product has eight DMX512 channel configurations: TOUR ARC 1 ARC.3 and BLOC...
  • Page 14 VALUE VALUE FUNCTION FUNCTION CHANNEL CHANNEL RED UP/GREEN 0%/BLUE100% RED100%/GREEN 0%/BLU EDOWN RED100%/GREEN UP/BLUE UP RED DOWN/GREEN DOWN/BLUE 100% RED100%/GREEN 100%P/BLUE100%/WHITE 100%/AMBER 100% WHITE1 3200K WHITE2 3400K WHITE3 4200K WHITE4 4900K WHITE5 5600K WHITE6 5900K WHITE7 6500K WHITE8 7200K WHITE9 8000K WHITE10 8500K WHITE11 10000K STROBE...
  • Page 15 VALUE FUNCTION CHANNEL DIMMING SPEED PRESET DIMMER SPEED FROM DISPLAY MENU LINEAR DIMMER NON LINEAR DIMMER 1 fastest NON LINEAR DIMMER 2 NON LINEAR DIMMER 3 NON LINEAR DIMMER 4 slowest ID ADDRESS ID1~ID66 ID10 ID11 ID12 ID13 ID14 ID15 ID16 ID17 ID18...
  • Page 16 ARC.1 VALUE FUNCTION CHANNEL GREEN BLUE AR1.D FUNCTION CHANNEL VALUE MASTER DIMMER GREEN BLUE ARC.3 FUNCTION VALUE CHANNEL GREEN BLUE WHITE AMBER AR3.D CHANNEL VALUE FUNCTION MASTER DIMMER GREEN BLUE WHITE AMBER...
  • Page 17 AR3.S VALUE CHANNEL FUNCTION MASTER DIMMER GREEN BLUE WHITE AMBER STROBE VALUE FUNCTION CHANNEL HUE(0~100%) SATURATION(0~100%) VALUE(0~100%) BLOCK VALUE FUNCTION CHANNEL MODULE1 RED MODULE1 GREEN MODULE1 BLUE MODULE1 WHITE MODULE1 AMBER MODULE2 RED MODULE2 GREEN MODULE2 BLUE MODULE2 WHITE MODULE2 AMBER...

  • Page 18: Part 5 Operation With Wireless Dmx

    OPERATION WITH WIRELESS DMX W-DMX TRANSMITTER LED325XWAT When using this lighting fixture with W-DMX receiver installed inside, the fixture may be placed at a range of 300m from W-DMX transmitter 5.2 Select DMX from the <RUN> menu. 5.3 Select ACTI from the <WDMX> menu and proceed to turn ON the WDMX. If the WDMX receiver card is already paired with a WDMX transmitter then the fixture is ready for receiving DMX signal.
  • Page 19 By pressing the RESET button on W-DMX transmitter, transmitter will search for RESET lighting fixtures. During search transmitter green SIGNAL indicator will flash. After pairing with lighting fixture green SIGNAL indicator will display. POWER SIGNAL RESET ANTENNA Once a lighting fixture has been paired with a W-DMX transmitter, the green SIGNAL indicator will display.

  • Page 20: Part 6 Appendix

    6 APPENDIX MAINTENANCE ITEM ITEM Head casing set Head casing set Mounting bracket 1 Mounting bracket 1 Base handle Base handle Mounting frame set Mounting frame set Mounting rod Mounting rod Mounting rod Mounting rod Mounting bracket 2 Mounting bracket 2 Adjusting screw Adjusting screw W-DMX antenna (optional)
