- Page 1 User's Manual A500.2 DRAGONFLY DIGITAL POWER AMPLIFIER www.altoproaudio.com Version 1.5 February 2006 English...
- Page 2 SAFETY RELATED SYMBOLS CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN This symbol, wherever used, alerts you to the presence of un-insulated and dangerous voltages within the product enclosure. These are voltages that may be sufficient to constitute the risk of electric shock or death. This symbol, wherever used, alerts you to important operating and ma- intenance instructions.
- Page 3 To avoid the risk of electric shock and damage, do not subject this product to any liquid/rain or moisture. Do not use this product when in close proximity to water. Do not install this product near any direct heat source. Do not block areas of ventilation.
- Page 4 Our A500.2 Amplifier is the result of many hours of listening and tests involving Co- mMon people, area experts, musicians and technicians.
-
Page 5: Table Of Contents
TABLE OF CONTENT 1. INTRODUCTION ...5 2. FEATURES ... 3. CONTROL ELEMENTS ...5 3.1 Front Panel 3.2 Rear Panel TECHNICAL SPECIFICATION 5. WARRANTY...7... -
Page 6: Introduction
1. INTRODUCTION LTO A500.2 DRAGONFLY is D-class digital Power Amplifier with advanced features and great efficiency. It delivers tremendous power in a small space, providing high level performance even under the most demanding conditions. The amplifier contains two independent channels with separate AC transformer, power supplies and protection system. -
Page 7: Rear Panel
Power LED This LED lights up when the unit is powered on. Power Switch Turn the unit on or off. Level Control for Channels 1 & 2 Adjust the output signal level of respective channel. Clip LED When the LED lights up, it means the output level of signal is too high and it is time to reduce the signal level until clip LED turns off. -
Page 8: Technical Specification
These NEUTRIK connectors are used to connect with your speakers. AC Input Use it to connect your A500.2 DRAGONFLY to the supplied AC cord only. Please check the voltage in your country before attempting toconnect the unit with the main AC. - Page 9 All the information presented in this Warranty Registration Card gives the manufac- turer a better understanding of the sales status, so as to purport a more effective and efficient after-sales warranty service. Please fill out all the information carefully and genuinely, miswriting or absence of this card will void your warranty service.
- Page 10 SEIKAKU TECHNICAL GROUP LIMITED SEKAKU ELECTRON INDUSTRY (H.K.) CO., LTD. No. 1, Lane 17, Sec. 2, Han Shi West Road, Taichung 40151, Taiwan http://www.altoproaudio.com Tel: 886-4-22313737 email: alto@altoproaudio.com Fax: 886-4-22346757 All rights reserved to ALTO. All features and content might be changed without prior notice.
