TP-M131
YUB
SERVICE MANUAL
BASIC TAPE MECHANISM : M-186
MICROCASSETTE RECORDER
This Service Manual contains information about the difference between
TP-M130/M330 Y YU.
If requiring the other information, see Service Manual of the TP-M130/M330 Y YU
(S/M Code No. 09-995-329-4N1).
S/M Code No. 09-995-329-4N4
