Contents Components Symbols used to mark instructions...4 Attachments Included Attachments...5 Accessories Included Accessories...6 Guidance Congratulations...7 Getting the best results...7 Installation Assembly...8 Warnings...8 Operation Switching on the machine...9 Using the machine...10 During Use...10 Maintenance Daily...11 Weekly...11 Precautions Do’s & Don’ts...11 Service Guarantee...12 Technical Technical Data...13...
Components 1. Cold Water Tank 2. Detergent Tank 3. Steam Control 4. Filter Panel 5. Steam Hose Socket 6. Castor With Brake 7. Wire Basket Diagram A 8. Serial Number Diagram B English 9. On/Off Switch 10. Heater On LED 11.
Attachments These Parts were carefully packed at Nilfisk. Please check all accessories on receipt. If any parts are missing or damaged please contact the company in which you purchased this machine, within 7 days of purchase quoting your serial number on the back of the machine. 1.
English Accessories These Parts were carefully packed at Nilfisk. You will find these items in your box with all the attachments. Please check all accessories on receipt. If any parts are missing or damaged please contact the company in which you purchased this machine, within 7 days of purchase quoting your serial number on the back of the machine.
Guidance Congratulations ………………………………………………... We would like to take this opportunity to thank you for your purchase of the Nilfisk combined steam, detergent and vacuum cleaner. The GR8000 is manufactured in the EU to the highest quality Standards This instruction manual contains all of the necessary information to operate and maintain this machine.
Installation • Diagram D – Back wheel assembly. Using a 10 mm spanner remove the bolts from the machine and place the assembly into place towards the back of the machine. Tighten the bolts securely ensuring no movement on the brackets. •...
8. Switch the On/Off switch (Number 11 Diagram B) to the ON position. The Heater On light LED (Number 13 Diagram B) will illuminate. 9. Allow approximately 10 minutes for the boiler to heat the water 10. When the Steam Ready LED (Number 14 Diagram B) illuminates the machine is ready to be used.
3. The pumps will not work when the cold-water tank is empty. 4. Once the cold water refill LED is illuminated the boiler heater will remain on for 30 minutes. If the cold-water tank is not refilled within 30 minutes and the machine is left powered on the boiler heater will switch off.
Maintenance Warning: Disconnect the machine from the mains before cleaning or carrying out any maintenance work. Daily Maintenance ………………………………………………... To be carried out every day or every 8 hours of operation. 1. Grease “O” rings on the steam pin in the steam hose. 2.
Service & Guarantee If you require a service or advice on using or maintaining your machine please contact your Nilfisk approved distributor. Service Guarantee ………………………………………………... ………………………………………………... Nilfisk guarantees that if within 12 months from the date of purchase this appliance, or any parts thereof, is proved to be defective by reason of faulty workmanship or materials, we will at our option repair or replace the same free of charge for labour and materials, provided that: •...
Technical Technical Information ………………………………………………... Boiler Wattage: Type: Capacity: Continuous Fill Steam Pressure Steam at source: Electrical Voltage Low Voltage Controls Cord length Capacities Boiler Cold Water Tank Detergent Tank Weight English 3000W – (2000+1000) Stainless Steel 3.3 Litres 8 Bar 165°C >...
Steamer not ready Clean water tank is low (beeping sound& "refill" light is lit) Unknown No steam, Just water Steamer not ready Boiler at pressure and not heating(temperature less than 110ºC) Unknown Steam Leaking from front “O” Rings split socket “O”...
