Quick Start Guide
HMSM4050
Wireless
Motion Sensor
1

Advertisement

   Also See for Motorola HMSM4050

   Related Manuals for Motorola HMSM4050

   Summary of Contents for Motorola HMSM4050

  • Page 1 Quick Start Guide HMSM4050 Wireless Motion Sensor...
  • Page 2: How It Works

    Introduction Congratulations on your purchase of the Motorola Wireless Motion Sensor (WMS). Your sensor uses a heat/motion detector to scan a field 90 degrees wide up to a range of approximately 20 feet. This enables you to secure an area, regardless of day or night, rain or shine.
  • Page 3: Installation Overview

    Installation Overview Your package contains the following: Installing your sensor is a simple process. Twist the WMS clockwise at the seam in the middle and pull the two halves apart. Insert batteries. Register your sensor with your Wireless System Controller using a process called Discovery. Refer homesight Software User Guide for instructions on how to discover your Wireless Motion Sensor.
  • Page 4: Installation Hints

    Installation Hints Please consider the following points when mounting the sensor: • The sensor must be aimed so that it does not directly face the sun or any bright light; otherwise, this may cause damage to the sensor. • The Motorola Wireless Motion Sensor is constructed of UV-resistant ABS plastic.If installing the Wireless Motion Sensor outside, it should be shielded from the elements, such as underneath a porch roof.
  • Page 5 Wall Mount Drilling Template Mounting tools: Screwdriver, electric drill or awl. On hard surfaces, Motorola recommends that you pre-drill ½-inch deep pilot holes with a drill bit slightly smaller than the bracket mounting screws before securing the bracket to the surface.
  • Page 6: Troubleshooting

    Troubleshooting Problem Solution • Sensor will not register with the Wireless System Controller • • • • • Motion events are not triggered • • How far away can the sensor “see?” The motion sensor is capable of detecting objects up to 20 feet away with a field of view of 90 degrees. How can I most effectively use my Wireless Motion Sensor with my homesight System’s video camera? The WMS can act as a trigger to your system’s wired or wireless video camera.
  • Page 7: Features And Specifications

    Features and Specifications • Device signal communication • LED in sensor illuminates when activity occurs • 90 degree field of view for motion • Weather resistant • All hardware for either wall or ceiling mounting included • Two AA alkaline battery operation (batteries included) View: Surveilance range: Communication frequency:...
  • Page 8: Regulatory Information

    Regulatory Information CAUTION: Changes or modifications not expressly approved by Motorola for compliance could void the user’s authority to operate the equipment. FCC Compliance Class B Digital Device This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential environment.
  • Page 9: Limited Warranty

    SUBSTITUTE FOR A HOME SECURITY SYSTEM. MOTOROLA HEREBY DISCLAIMS ANY LIABILITY WHATSOEVER THAT MAY ARISE FROM THE USE OR INABILITY TO USE THIS PRODUCT AS A HOME SECURITY SYSTEM. IN NO EVENT SHALL MOTOROLA BE LIABLE TO YOU OR ANY OTHER PARTY FOR ANY DIRECT, INDIRECT, GENERAL, SPECIAL, INCIDENTAL, CONSEQUENTIAL, EXEMPLARY OR OTHER DAMAGES...
  • Page 10 Visit our website at: http://www.motorola.com/homemonitoring Copyright © April, 2005 by Motorola, Inc. All rights reserved. No part of this publication may be reproduced in any form or by any means or used to make any derivative work (such as translation, transformation or adaptation) without written permission from Motorola, Inc. Motorola reserves the right to revise this publication and to make changes in content from time to time without obligation on the part of Motorola to provide notification of such revision or change.
