INSTALLATION AND OPERATION MANUAL
Version 08/04
© Copyright 2004 Incredible Technologies, Inc. All Rights Reserved.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SILVER STRIKE BOWLING and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for it SILVER STRIKE BOWLING

  • Page 1 INSTALLATION AND OPERATION MANUAL Version 08/04 © Copyright 2004 Incredible Technologies, Inc. All Rights Reserved.

  • Page 2: Warnings And Notices

    RMA number. Merchandise returned without an RMA number will not be accepted. Warranty may be void if serial number or security labels are tampered with or removed. Opening the Nighthawk Chassis system will void your warranty.

  • Page 3: Features

    Changing the camera gives you a new 'view' on all the action! Ø Powerful New Hardware Platform Silver Strike Bowling leaps into the future with new hardware that ramps up the fun! Ø Stunning 3D Graphics and Effects Players of all skill levels will enjoy the realistic feel and dynamic 3D graphics.

  • Page 4: Table Of Contents

    Contrast Adjustments Sound Tests Mechanical Meter Silver Strike Bowling™ © Copyright 2004 Incredible Technologies, Inc. All Rights Reserved. Unauthorized duplication is a violation of applicable law. All other marks are the properties of their respective owners. All rights reserved. TABLE OF CONTENTS...

  • Page 5: Kit Installation Section

    Silver Strike Bowling Kit Installation Silver Strike Bowling™ Version 08/04 Page 3 © Copyright 2004 Incredible Technologies, Inc. All Rights Reserved. Unauthorized duplication is a violation of applicable law. All other marks are the properties of their respective owners. All rights reserved.

  • Page 6: Kit Package Contents

    Please refer to these IT part numbers when placing orders. Included in the Silver Strike Bowling Kit (Part # 925000265) should be the following: A bag of parts is included in your kit and the contents can be found on the next page.
  • Page 7 JAMMA Wiring Diagram on page 43 in this manual. Silver Strike Bowling™ Version 08/04 Page 5 © Copyright 2004 Incredible Technologies, Inc. All Rights Reserved. Unauthorized duplication is a violation of applicable law.

  • Page 8: Recommended Tools

    Installation Preparation BEFORE YOU START… Before you install the Silver Strike Bowling kit into your cabinet there are a few things you should check first: Check to make sure your existing cabinet's monitor, speakers, AC power cord, and lights work.

  • Page 9: The Cabinet

    Cabinet Selection You can choose either a new cabinet or a used cabinet for your Silver Strike Bowling game. Reusing a cabinet is by far the most cost-effective way to maximize the return on your initial investment. In either case, all you need to provide is the cabinet with a monitor, JAMMA harness, coin and bill acceptors, working fluorescent/marquee lights, and speakers.

  • Page 10: Game Electronics

    Silver Strike Bowling comes with a specially designed I/O board that works with your cabinet's already installed JAMMA harness. The I/O board is used as a connection interface between the JAMMA and the Nighthawk Chassis.

  • Page 11: I/O Board Diagram

    To connect to a low or medium resolution RGB monitor refer to the figure below: 1. Connect one end of the 6 ft. SVGA video cable to the video out of the Nighthawk Chassis. 2. Connect the other end of the 6 ft. SVGA cable to the I/O board video in J501.

  • Page 12: Nighthawk Chassis Installation

    9. Dress all cables with additional clamps and wire tie wraps where needed. Refer to the diagrams on this page as well as a detailed diagram on page 45 for correct placements of Nighthawk Chassis, C.I.D., and cables from the Chassis to I/O board to peripherals: Silver Strike Bowling™...

  • Page 13: Cabinet Identification Device Installation

    Ticket Dispenser Silver Strike Bowling supports Entropy 2000 Ticket Dispenser Continuous Type (TD963CR) and Deltronic Labs DL-1275 Continuous Type ticket dispensers. If you wish to connect a ticket dispenser to this game, you will have to make a cable with the proper connectors.

  • Page 14: Trackball Preparation

    NOTE: Do NOT install the trackball or buttons until the control panel graphics have been applied. Control Panel Overlay Installation Silver Strike Bowling comes with an oversized control panel overlay that will accommodate a variety of existing game cabinets, but works best on Golden Tee Fore®, NFL® Blitz™ and EA Sports™ PGA Tour® Golf cabinets.

  • Page 15: Finishing The Control Panel

    NOTE: The post on the switch labeled COM should connect to the ground wire and the post labeled NO should connect to the signal wire. See the JAMMA pin out chart on page 43. Silver Strike Bowling™ © Copyright 2004 Incredible Technologies, Inc. All Rights Reserved. Unauthorized duplication is a violation of applicable law.

  • Page 16: Finishing The Kit

    Side Decals and Marquee Included with your Silver Strike Bowling kit is a set of decals to place on the side of your cabinet and a brand new marquee. This will help identify your new game as Silver Strike Bowling. By placing and installing these correctly it can help give players instant recognition, even from a distance.

  • Page 17: Coin Doors/Test Switch/Volume Control Panel

    Refer to the JAMMA Harness Connection table on page 43. Initial Power-Up There are several steps you should take when powering up your Silver Strike Bowling for the first time. This is a quick checklist for you to follow when doing your first initial power-up: Plug in the game and turn it ON;...
  • Page 18 Silver Strike Bowling™ Version 08/04 Page 16 © Copyright 2004 Incredible Technologies, Inc. All Rights Reserved. Unauthorized duplication is a violation of applicable law. All other marks are the properties of their respective owners. All rights reserved.

  • Page 19: Dedicated Cabinet Section

    Silver Strike Bowling Dedicated Version Silver Strike Bowling™ Version 08/04 Page 17 © Copyright 2004 Incredible Technologies, Inc. All Rights Reserved. Unauthorized duplication is a violation of applicable law. All other marks are the properties of their respective owners. All rights reserved.

  • Page 20: The Cabinet

    Operator Menus (see page 25). Monitor Your Silver Strike Bowling cabinet comes equipped with a digital monitor set to SVGA. Silver Strike Bowling dedicated cabinets support high-res. monitors, offering superb graphics and brilliant colors. Silver Strike Bowling supports low-res, mid-res., VGA and SVGA monitors. Make sure the I/O Board and monitor are set properly for best game play results.

  • Page 21: Dip Switch Settings

    25 KHz Initial Power-Up There are several steps you should take when powering up your Silver Strike Bowling for the first time. This is a quick checklist for you to follow when doing your first initial power-up: Plug in the game and turn it ON; be sure the game powers up correctly into the attract mode.
  • Page 22 Silver Strike Bowling™ Version 08/04 Page 20 © Copyright 2004 Incredible Technologies, Inc. All Rights Reserved. Unauthorized duplication is a violation of applicable law. All other marks are the properties of their respective owners. All rights reserved.

  • Page 23: Operator Menus Section

    Silver Strike Bowling Operator Menus Silver Strike Bowling™ Version 08/04 Page 21 © Copyright 2004 Incredible Technologies, Inc. All Rights Reserved. Unauthorized duplication is a violation of applicable law. All other marks are the properties of their respective owners. All rights reserved.

  • Page 24: Navigating The Menus

    Changing a Value A value can be changed at any time by rolling the trackball left or right. Operator Mode Menus The following is a listing of all the menus located in Silver Strike Bowling and their options: Main Menu Collections This will reset all audits in the Game Audits menu to zero except for Lifetime Money Total.

  • Page 25: General Settings

    This resets all values to their default value located on this page. Back This will take you back to the Operator Adjustables menu. Silver Strike Bowling™ Version 08/04 Page 23 © Copyright 2004 Incredible Technologies, Inc. All Rights Reserved. Unauthorized duplication is a violation of applicable law.

  • Page 26: Value Reset - General Adjustments

    This will not perform the reset and take you back to the previous menu. This will perform the reset and take you back to the previous menu. Silver Strike Bowling™ Version 08/04 Page 24 © Copyright 2004 Incredible Technologies, Inc. All Rights Reserved. Unauthorized duplication is a violation of applicable law.

  • Page 27: Sound Adjustments

    This will not perform the reset and take you back to the previous menu. This will perform the reset and take you back to the previous menu. Silver Strike Bowling™ Version 08/04 Page 25 © Copyright 2004 Incredible Technologies, Inc. All Rights Reserved. Unauthorized duplication is a violation of applicable law.

  • Page 28: System Tests

    Adjust your monitor to have blue display properly. Back This will take you back to the Video Tests menu. Silver Strike Bowling™ Version 08/04 Page 26 © Copyright 2004 Incredible Technologies, Inc. All Rights Reserved. Unauthorized duplication is a violation of applicable law.

  • Page 29: Copyright 2004 Incredible Technologies, Inc. All Rights Reserved. Unauthorized Duplication Is A Violation Of Applicable Law

    This test makes the hard meter adjust by one to make sure it is functioning properly. Back This will take you back to the System Tests menu. Silver Strike Bowling™ Version 08/04 Page 27 © Copyright 2004 Incredible Technologies, Inc. All Rights Reserved. Unauthorized duplication is a violation of applicable law.

  • Page 30: Hardware Tests

    This is a list of your game’s current basic system info. Back The Back button takes you back to the previous menu. Silver Strike Bowling™ Version 08/04 Page 28 © Copyright 2004 Incredible Technologies, Inc. All Rights Reserved. Unauthorized duplication is a violation of applicable law.

  • Page 31: Usb Info

    Back This will take you back to the Hardware Tests menu. Silver Strike Bowling™ © Copyright 2004 Incredible Technologies, Inc. All Rights Reserved. Unauthorized duplication is a violation of applicable law. All other marks are the properties of their respective owners. All rights reserved.

  • Page 32: Check Cooling

    This menu contains various options to set your game's ticket dispenser settings and clear any tickets owed. Back This will take you back to the Main Menu. Silver Strike Bowling™ Version 08/04 Page 30 © Copyright 2004 Incredible Technologies, Inc. All Rights Reserved. Unauthorized duplication is a violation of applicable law.

  • Page 33: Player Cost Schedule

    Series Play This option lets you adjust how much it costs a player to play a series, which is three full games in a row. WARNING: Series Play should cost more than Single Play. The default is set to $2.50.

  • Page 34: Game Audits

    Game Purchase Audits This menu contains totals including the number of three frame games, Single vs Series games, and Classic vs. Vegas games. Ticket Dispenser Audits This menu will allow you to view the total amount of tickets given out and the payout percentage.

  • Page 35: Game Purchase Audits

    Lifetime Money Total. Back This will take you back to the Game Audits menu. Silver Strike Bowling™ Version 08/04 Page 33 © Copyright 2004 Incredible Technologies, Inc. All Rights Reserved. Unauthorized duplication is a violation of applicable law.

  • Page 36: Value Reset - Collections & Audits

    This resets all values to their default value located on this page. Back This will take you back to the Silver Strike Settings menu. Silver Strike Bowling™ Version 08/04 Page 34 © Copyright 2004 Incredible Technologies, Inc. All Rights Reserved. Unauthorized duplication is a violation of applicable law.

  • Page 37: Value Reset - Game Options

    This will not perform the reset and take you back to the previous menu. This will perform the reset and take you back to the previous menu. Silver Strike Bowling™ Version 08/04 Page 35 © Copyright 2004 Incredible Technologies, Inc. All Rights Reserved. Unauthorized duplication is a violation of applicable law.

  • Page 38: Value Reset - Reset Leaderboards

    This option will reset all values located on this page to their default values. Back This will take you back to the Ticket Dispenser menu. Silver Strike Bowling™ Version 08/04 Page 36 © Copyright 2004 Incredible Technologies, Inc. All Rights Reserved. Unauthorized duplication is a violation of applicable law.

  • Page 39: Value Reset - Dispenser Settings

    This option will reset all values located on this page to their default values. Back This will take you back to the Ticket Dispenser menu. Silver Strike Bowling™ Version 08/04 Page 37 © Copyright 2004 Incredible Technologies, Inc. All Rights Reserved. Unauthorized duplication is a violation of applicable law.

  • Page 40: Value Reset - Ticket Settings

    This will not perform the reset and take you back to the previous menu. This will perform the reset and take you back to the previous menu. Silver Strike Bowling™ Version 08/04 Page 38 © Copyright 2004 Incredible Technologies, Inc. All Rights Reserved. Unauthorized duplication is a violation of applicable law.

  • Page 41: Troubleshooting And Reference

    Silver Strike Bowling Troubleshooting And Reference Silver Strike Bowling™ Version 08/04 Page 39 © Copyright 2004 Incredible Technologies, Inc. All Rights Reserved. Unauthorized duplication is a violation of applicable law. All other marks are the properties of their respective owners. All rights reserved.

  • Page 42: Troubleshooting Index

    Be sure the video connections are correct according to the type of monitor you are using. Refer to cable connection diagram - page 45. Verify A.C. power to the Nighthawk Chassis. Verify monitor is working on a known good system. Repair or replace.

  • Page 43: Sound Problems

    © Copyright 2004 Incredible Technologies, Inc. All Rights Reserved. Unauthorized duplication is a violation of applicable law. All other marks are the properties of their respective owners. All rights reserved. Probable Cause Audio Cable between the I/O board and the Nighthawk Chassis are not connected. Speakers are not connected properly.

  • Page 44: Nighthawk Chassis Problems

    © Copyright 2004 Incredible Technologies, Inc. All Rights Reserved. Unauthorized duplication is a violation of applicable law. All other marks are the properties of their respective owners. All rights reserved. Probable Cause No A.C. power to the Nighthawk Chassis. Power switch on the Nighthawk Chassis is off.

  • Page 45: Jamma Harness Connection

    PIN WIRE #4 - Purple PIN WIRE #6 – Purple Silver Strike Bowling™ © Copyright 2004 Incredible Technologies, Inc. All Rights Reserved. Unauthorized duplication is a violation of applicable law. All other marks are the properties of their respective owners. All rights reserved.

  • Page 46: Nighthawk Chassis Diagram

    Nighthawk Chassis and I/O Board Diagrams Nighthawk Chassis Diagram Kit I/O Board Diagram Dedicated I/O Board Diagram Silver Strike Bowling™ Version 08/04 Page 44 © Copyright 2004 Incredible Technologies, Inc. All Rights Reserved. Unauthorized duplication is a violation of applicable law.

  • Page 47: Detailed Cable Connection Diagram

    Detailed Cable Connection Diagram Silver Strike Bowling™ Version 08/04 Page 45 © Copyright 2004 Incredible Technologies, Inc. All Rights Reserved. Unauthorized duplication is a violation of applicable law. All other marks are the properties of their respective owners. All rights reserved.

  • Page 48: Ssb Cabinet Wiring Diagram

    SSB Cabinet Wiring Diagram Silver Strike Bowling™ Version 08/04 Page 46 © Copyright 2004 Incredible Technologies, Inc. All Rights Reserved. Unauthorized duplication is a violation of applicable law. All other marks are the properties of their respective owners. All rights reserved.

  • Page 49: Game Icon Descriptions

    If the fans do not - perate at suggested levels it may cause your game to overheat and fail. Call Incredible Technologies Technical Support at 847-870-7027 x121 for assistance. NOTE: Opening the Nighthawk Chassis system will void your warranty! Tickets Owed Icon The tickets owed icon (pictured right) will appear in the game's attract mode to warn you that the ticket dispenser is not dispensing tickets.
  • Page 50 Silver Strike Bowling™ Version 08/04 Page 48 © Copyright 2004 Incredible Technologies, Inc. All Rights Reserved. Unauthorized duplication is a violation of applicable law. All other marks are the properties of their respective owners. All rights reserved.

  • Page 51: Trackball Mounting Template

    Silver Strike Bowling™ Version 08/04 Page 49 © Copyright 2004 Incredible Technologies, Inc. All Rights Reserved. Unauthorized duplication is a violation of applicable law. All other marks are the properties of their respective owners. All rights reserved.
  • Page 52 Silver Strike Bowling™ Version 08/04 Page 50 © Copyright 2004 Incredible Technologies, Inc. All Rights Reserved. Unauthorized duplication is a violation of applicable law. All other marks are the properties of their respective owners. All rights reserved.

  • Page 53: Trackball Orientation Diagram

    Silver Strike Bowling™ Version 08/04 Page 51 © Copyright 2004 Incredible Technologies, Inc. All Rights Reserved. Unauthorized duplication is a violation of applicable law. All other marks are the properties of their respective owners. All rights reserved.
  • Page 54 Silver Strike Bowling™ Version 08/04 Page 52 © Copyright 2004 Incredible Technologies, Inc. All Rights Reserved. Unauthorized duplication is a violation of applicable law. All other marks are the properties of their respective owners. All rights reserved.

  • Page 55: Right Buttons Template

    Silver Strike Bowling™ Version 08/04 Page 53 © Copyright 2004 Incredible Technologies, Inc. All Rights Reserved. Unauthorized duplication is a violation of applicable law. All other marks are the properties of their respective owners. All rights reserved.
  • Page 56 Silver Strike Bowling™ Version 08/04 Page 54 © Copyright 2004 Incredible Technologies, Inc. All Rights Reserved. Unauthorized duplication is a violation of applicable law. All other marks are the properties of their respective owners. All rights reserved.

  • Page 57: Replacement Part Numbers

    APPENDIX D Replacement Part Numbers Please refer to these IT part numbers when placing orders. Silver Strike Bowling Dedicated (Part # 925000265D) and Silver Strike Bowling Kit (Part# 925000265): Quantity Part Description Silver Strike Bowling Cabinet Nighthawk Chassis (System Box)

  • Page 58: Contact Information

    In our replacement part numbers section is a list of parts you can get from these vendors including the vendor's part numbers. SILVER STRIKE BOWLING™, ITS®, INCREDIBLE TECHNOLOGIES®, IT®, ITNet®, and IT incredible TECHNOLOGIES® are the properties of © Copyright 2004 Incredible Technologies, Inc. All Rights Reserved. Unauthorized duplication is a violation of applicable law.
  • Page 59 Phone (847) 870-7027 Fax (847) 870-0120 www.itsgames.com SILVER STRIKE BOWLING™, ITS®, INCREDIBLE TECHNOLOGIES®, IT®, ITNet®, and IT incredible TECHNOLOGIES® are the properties of Incredible Technologies, Inc. All Rights Reserved. © Copyright 2004 Incredible Technologies, Inc. All Rights Reserved. Unauthorized duplication is a violation of applicable law.
