Summary of Contents for Nextar MA110
-
Page 1: Instruction Manual
MA110 | Digital MP3 Player Instruction Manual... -
Page 2: Table Of Contents
Contents 1. Feature summary...1 2. Introduction...2 3. Getting to know the player...3 4. Basic functions...4 5. A-B repeat...6 6. Menu selections...7 7. Settings submenu...8 8. Voice recording...9 9. Deleting files...10 10. Line-in function...10 11. Internal memory...11 12. Equalizer...11 13. Repeat play...12 14. -
Page 3: Feature Summary
Thank you for purchasing our Digital MP3 Player. This uniquely designed device combines an MP3 Player, voice recorder; Removable Flash Memory drive all in one unit. You can move and store files between computers and enjoy your MP3 music collection anytime and anywhere. -
Page 4: Introduction
WMA (Windows Media Audio) for greater compatibility and compression options 2. InTroDuCTIon Thank you for purchasing our MP3 player. Before using the unit please read this manual carefully to obtain the best possible performance from your player. Keep this manual for... -
Page 5: Getting To Know The Player
Appearance and Controls Hook Power on Play/Pause Power off 3. GeTTInG To know The PLAYer Earphone Line in Mode Next Prev Vol+ Vol- Hold... -
Page 6: Basic Functions
4. BASIC FunCTIonS Start up/Shutdown Start up or shutdown player by pressing and holding the “PLAY” button. entering Menu Modes Menus: Main menu (entered by momentarily holding Mode key when not playing), Play submenu (entered by pressing Mode key while playing), and Stop submenu (entered by pressing Mode key when not playing). - Page 7 Adjusting Volume Decrease volume by pressing the “ - “ side of the - VOLUME + button. Increase volume by pressing the “+” side of the switch. (hoLD) Function Move the HOLD switch to the position showing the closed lock (left). When Hold is ON, all controls are locked out and a lock icon appears in the center top of the LCD display.
-
Page 8: A-B Repeat
5. A-B rePeAT using the A-B repeat Function Press the Mode button to enter the repeat function while playing. The LCD display will show “A-”(start point). Press the Mode button again at the end of the section you want to repeat, and it shows “A-B”(end point). -
Page 9: Menu Selections
Menu operation Press the PLAY button to power on. Press the MODE button to open the main menu, the function menu options will be shown. The various selections are shown below: Music Voice MIC Record LINE IN Settings Delete Information Browser Exit Making Selections... -
Page 10: Settings Submenu
Submenu operation Press the PLAY button to power on. Press the MODE button to open the main menu, the function menu options will be shown. Scroll through the menus with the PREV or NEXT buttons until you reach the SETTINGS submenu. Press MODE again to access this submenu: Repeat Contrast... -
Page 11: Voice Recording
Voice recording operation In MENU mode, scroll to the “MIC Record” selection and press the PLAY/PAUSE/ STOP button to start recording The LCD will display the recorded time and the recording time remaining Press the PLAY/PAUSE/STOP button to stop the recording Press the MODE button to quit 5) To listen to the recorded file, you can press the MODE button and select VOICE. -
Page 12: Deleting Files
Delete Files operation In MENU mode, select DELETE and press the Mode button to enter Press the PREV or NEXT buttons to select the file you want to delete Press the Play button to delete 4) The LCD display will indicate the track number and file name you selected. After it is finished, it will indicate that the file has been deleted Press the Mode button and select Exit to quit. -
Page 13: Internal Memory
To View Internal Memory You can view the capacity of the player by connecting to computer or view capacity of the player as follows: 1) Press the Mode button to enter the MENU mode. 2) Press the PREV or NEXT buttons to select INFO and press the Mode button 3) The memory capacity and firmware version of the player will be displayed 3). -
Page 14: Repeat Play
If you want to repeat a single song or groups of songs, use the following directions: Press and hold the Mode button to enter MENU directory and select scroll to SETTINGS (using the PREV or NEXT buttons). Press the Mode button to enter the sub-menu. Press the PREV or NEXT buttons to select REPEAT mode and press the Mode button to enter. -
Page 15: Backlight Settings
Backlight Time The backlight (the colored light that illuminates the LCD display) can be set to various “on” times. To change the backlight on settings: Press the Mode button, and scroll to the SETTINGS submenu. Press the PREV or NEXT buttons to select the BACKLIGHT mode and press the Mode button to enter. -
Page 16: Auto Power Settings
Auto Power off To save battery power, the unit can be set to shut off by itself (if no buttons are pushed) according to a number of presets: Press the Mode button, and scroll (using the PREV or NEXT button) to the SETTINGS menu. -
Page 17: Screen Saver Settings
Screen Savers Users can select a variety of screen savers to customize the look of their LCD when not in In SETTINGS mode, press the PREV or NEXT buttons to select SCREEN SAVE mode and press the Mode button to enter. Press the PREV or NEXT buttons to select the desired screen saver and press the Mode button to confirm the screen saver you like. -
Page 18: Exiting Menus
To exit from the menu system, press the PREV or NEXT buttons and select the EXIT option. Press the Mode button to select and EXIT menus Note: Depending upon the firmware version of your unit, some of these functions and/or their exact descriptions may vary slightly from that shown in this manual The Folder Mode This mode allows easy access to your music via folder style navigation... -
Page 19: Multimedia Card
how to use the MMC/SD Card Function MMC/SD cards allow for significant memory expansion for this unit - either for additional music, files or both Insert the SD/MMC card in correct orientation while the unit is powered off. 2) Select the external card in menu mode, and then you can access the files on the SD/ MMC card conveniently. -
Page 20: Troubleshooting
Setup Software (cont.) Warning Windows 98 users please install the drivers on the install CD before connecting the unit to your PC. If your Windows version is Windows 2000 or Windows XP or later, INSTALL THE INCLUDED WIN98 DRIVER! install the included driver. - Page 21 1) Using the Recover Mode: In cases where your player cannot be turned on and it cannot be found by your PC (when connected), you can recover your player using the following instructions: a) Take out the battery first, press and hold the play button of the player. b) connect to your PC, and run firmware download program.
- Page 22 IMPORTANT Please read the following carefully: 1) The drivers on the CD are just for Win98. Normally you do not need to install drivers if you are running Windows 2000 SP3 or later. If your PC still does not recognize your player, install the included drivers.
-
Page 23: Specifications
Memory Battery Support OS Audio output PC interface Record format Download speed 24. SPeCIFICATIonS 64MB/128MB/256MB/512MB/1GB/2GB AAA battery 128x32 Windows98/me/2000/xp/2003 90dB USB2.0 full speed 1Mbps... -
Page 24: Precaution
1). When not using the player for an extended period of time, remove the batteries to avoid damage due to leakage Do not use the player in extremely hot, cold, dusty or damp environments. 3). Make sure the HOLD key is in the unlock position before using the player (otherwise controls will not function). - Page 25 Nextar is a registered trademark of Tofasco, Inc. Nextar may find it necessary to modify, amend or otherwise change or update this manual. We reserve the right to do this at any time, without any prior notice. All specifications and features are subject to change without notice.
