  • Page 1 OPERATION MANUAL NIGHT VISION MONOCULAR PHANTOM 150 In USA: 3310 Prospect Ave. Cleveland, OH 44115 In Canada: 105 Sparks Ave, Toronto, ON. M2H 2S5 Canada Tel: (416) 663-6963 Fax: (416) 663-9065 Email: NEWCONSALES@NEWCON-OPTIK.COM Internet: www.newcon-optik.com NEWCON Optik™ 2005 Printed in Canada...
  • Page 2 IMPORTANT INFORMATION Read prior to activation You have just purchased a complicated electronic device. To operate it properly, please read this manual carefully. Here are some common Precautions that must be noted. • NEVER expose the opened objective lens of an active unit in daylight.
  • Page 3 9. ACCEPTANCE CERTIFICATE NIGHT VISION DEVICE PHANTOM 150 Serial Number _______________________________ Model Phantom 150_____________________ Corresponds to technical conditions ADSH 3.807.020 TU and is admitted for use. Date of production -___________________ Place for seal Quality inspector ____________________ (Signature) • NEVER connect the unit to external power sources •...

  • Page 4: Table Of Contents

    PLEASE READ ALL THE INSTRUCTIONS CAREFULLY BEFORE USING. 1. OVERVIEW Phantom 150 Night Vision monocular is a sophisticated optico- electronic observation device designed to allow observations of personnel and orientation in nighttime conditions. The unit is utilizing an image intensifier which amplifies available moonlight, starlight or man-made light.

  • Page 5: Warranty

    NEWCON OPTIK DISCLAIMS ANY WARRANTIES, EXPRESS OR IMPLIED, WHETHER OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR USE, EXCEPT AS EXPRESSLY SET FORTH HEREIN. Some of the typical activities where the Phantom 150 will be useful: boating, search and rescue, law enforcement, wildlife observation, security. Features •...

  • Page 6: Troubleshooting

    25°C (-13°F), the device must be warmed up to ambient temperature, from -20°C (-4°F) to +40°C (104°F) during 2-3 hours. Precaution Phantom 150 is a precision optical instrument equipped with electronics. Therefore, it should be handled with due care. • Keep your device away from direct sunlight, impacts, dust, moisture, and sudden changes of temperatures.

  • Page 7: Components

    Video adapter is 37 x 1mm. It will feet most Sony cameras and some other as well. If not, check with local camera store and/or camera manufacturer for proper step up/step down rings. 2. COMPONENTS Phantom 150 is supplied with the following components: NAME Phantom 150 Carrying strap Case Lenses (85/1.5, 300/4.5, 500/5.6, 1000/10 ) (optional)

  • Page 8: Construction

    NOTE : As the design is being continuously improved some descriptions may differ from those given above. 4. CONSTRUCTION 1- Body Lens Focusing Ring Eye-piece Switch Button for the Scope IR Illuminator Switch IR Illuminator Battery House Cover Lens Cover 9- Carrying Strap 10- Low battery indicator 5.
