9. ACCEPTANCE CERTIFICATE
Image Intensifier Tube
Gen. 2+
Resolution, lines/mm
Photocathode sensitivity, integral, µA/ lm
Light amplification
Gen. 3
Resolution, lines/mm
Photocathode sensitivity, integral, µA/ lm
Light amplification
Image Intensifier Tube Serial Number: ____________
Date of production: __________ Quality Inspector Signature: ____________
NIGHT VISION DEVICE NVS7-2/4x / NVS7-2/4xHD
Serial Number_________ corresponds to all technical specifications and is
admitted for use.
Date of production: _____________ Quality Inspector Signature: _____________
Quality assurance seal
Newcon International ltd. © 2007 Printed in Canada
Required
Measured
30
400
20,000
35
1,000
25,000
OPERATION MANUAL
NIGHT VISION BINOCULARS
NVS7-2/4x / NVS7-2/4xHD
In USA: 2331 Superior Ave. Cleveland, OH 44114
In Canada: 105 Sparks Ave., Toronto, ON M2H 2S5
Tel: (416) 663-6963 Fax: (416) 663-9065
Advertisement
Table of Contents
Related Manuals for Newcon Optik NVS7-2/4x
Summary of Contents for Newcon Optik NVS7-2/4x
- Page 1 25,000 Image Intensifier Tube Serial Number: ____________ Date of production: __________ Quality Inspector Signature: ____________ NIGHT VISION DEVICE NVS7-2/4x / NVS7-2/4xHD Serial Number_________ corresponds to all technical specifications and is admitted for use. Date of production: _____________ Quality Inspector Signature: _____________ Quality assurance seal Newcon International ltd.
-
Page 2: Warranty
NEWCON Authorized Service. Postage, insurance, or shipping costs incurred in presenting your NEWCON product for warranty service are your responsibility. Please include a cheque or money order made out to NEWCON OPTIK for the amount of $10.00 to cover shipping and handling. -
Page 3: Troubleshooting
2+ or 3 image intensifier, which amplifies available moonlight, starlight or man- made light The binoculars were designed to be easy to use, and provide many years of operation. Some of the typical activities where the binoculars will be useful: •... -
Page 4: Operation At Night
Note: The illuminator will be activated only if the unit has been already switched on by switch. Note: When looking directly in front of the binoculars operational illuminator appears as a red dot. The illuminator can be also detected using night vision device. -
Page 5: Pre-Starting Procedures
NVS7-2/4X / NVS7-2/4XHD NAME QUANTITY BN5-2M Head Set (optional) Lens caps Manual Warranty Registration Card 3. SPECIFICATIONS OF NVS7-2/4x / NVS7-2/4xHD Image Intensifier Generation 2+ or 3 Magnification: Field of View 40° Focus range, m 0.25-∞ Interpupillary distance... -
Page 6: Spatial Frequency-Contrast Characteristic
IMAGE INTENSIFIER TUBE SPECIFICATIONS The unit is utilizing a small size image intensifier with direct image transfer. The tube contains a microchannel plate, multi-alkaline metal cathode, yellow-green color screen, built in electronics high voltage DC to DC converter and flat surface glass input-output windows.
