Newcon Optik LRB 4000CI Operation Manual
  1. Manuals
  2. Brands
  3. Newcon Optik Manuals
  4. Binoculars
  5. LRB 4000CI
  6. Operation manual

Newcon Optik LRB 4000CI Operation Manual

Laser range finder binocular
Hide thumbs Also See for LRB 4000CI:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Operating Manual
Enlarged version
10. QUALITY CERTIFICATE
LRB 4000CI is suited for usage.
Production date ____________________________
Serial number _____________________________
Operation Manual
Device performance:
Actual data Measured data
Reflective object, m
Non-reflective object, m
Azimuth, °
Elevation, °
RS-232 interface
Pass
Quality Inspector signature___________________
Purchase date _____________________________
Salesman ________________________________
LRB 4000CI
Quality Assurance Seal_____________________
LASER RANGE FINDER BINOCULAR
Newcon International ltd. © 2005
Printed in Canada
In USA: 3310 Prospect Ave. Cleveland, OH 44115
In Canada: 105 Sparks Ave., Toronto, ON M2H 2S5

Advertisement

Table of Contents
loading

Related Manuals for Newcon Optik LRB 4000CI

Summary of Contents for Newcon Optik LRB 4000CI

  • Page 1 10. QUALITY CERTIFICATE LRB 4000CI is suited for usage. Production date ____________________________ Serial number _____________________________ Operation Manual Device performance: Actual data Measured data Reflective object, m Non-reflective object, m Azimuth, ° Elevation, ° RS-232 interface Pass Quality Inspector signature___________________ Purchase date _____________________________...

  • Page 2: Important Information

    IMPORTANT INFORMATION Read prior to activation You have just purchased a complicated electronic device. To operate it properly, please read this manual carefully. Here are some common precautions that must be noted. • NEVER subject the unit to impact while operating or being transported •...
  • Page 3 NEWCON product for warranty service are your responsibility. Please include a check or money order made out to NEWCON OPTIK for the amount of $15.00 to cover shipping and handling. This covers products shipped in USA or Canada only.

  • Page 4: Table Of Contents

    CONTENTS 1. Brief description 2. Appearance of the device 3. Supplied accessories 4. Technical characteristics 5. Operation instructions 5.1. Preparing the device for operation 5.2. Measuring procedure 5.3. Mode switching procedure 5.4. Gating distance selection 5.5. Additional display information 5.6. Computer interconnectivity 5.7.

  • Page 5: Brief Description

    FAILURE TO OBEY THE INSTRUCTIONS WILL VOID THE WARRANTY 1. BRIEF DESCRIPTION LRB 4000CI Laser Rangefinder Binocular is the advanced Laser Range Finder system that provides instant distance, speed, and angular measuring consistently and accurately. The outstanding optics provides a sharp, clear image under all conditions.

  • Page 6: Appearance Of The Device

    2. APPEARANCE OF THE DEVICE 1 – Eyepieces; 2 – Objective lens – receiving lens; 3 – Objective lens - emitting lens; 4 – Dioptric correction rings; 5 – Mode button; 6 – Action button; 7 – Body of the device; 8 – Rubber grip Fig.

  • Page 7: Supplied Accessories

    There are four statistical qualifications of the reflected signal: • NO TARGET REFLECTION – when a steady reflected signal isn’t received. Numerical display shows four dashes at the distance displaying area; • TARGET REFLECTION LOW – when the number of steady received reflected signals is just enough to make acceptable conclusion about the measured distance;...

  • Page 8: Technical Characteristics

    4. TECHNICAL CHARACTERISTICS 1. Optics 2. Range Finder 3. Speed Detection Measured speed range, kmh / mph 4. Compass 5. Inclinometer 6. Misc. Magnification, x Objective Lens, mm Exit Pupil Diameter, mm Field of View 5° Type of Coating Fully multi-coated optics Interpupilary distance, mm 58-72 Diopter adjustment range...
  • Page 9 M/° - units of angular measurement: mils or degrees Shape of the reticle: cross shape or rectangular shape (2). rEC1 - recall function. Upon pressing the Action button (6) (fig. 1) the Display will sequentially show results of last 10 measurements, starting from the latest one.

  • Page 10: Operation Instructions

    5. OPERATION INSTRUCTIONS Liquid Crystal Display (LCD) 1 – Low battery indicator; 2 – Reticle (cross or rectangular selectable); 3 – Units of measurement (Yards, Meters, KMH, MPH, Mils or Degrees); 4 – Measurement result; 5 – Target quality indicator; 6 – Laser active indicator 7 –...
  • Page 11 override reticle type and target selection with the sub selection code. For example, Standard 1 mode implies cross reticle. If you choose rectangular reticle (sub selection code 10), you change the reticle shape and leave all other parameters of this mode intact.

  • Page 12: Mode Switching Procedure

    The mode selection logic allows choosing the nearest (‘first’), the farthest (‘last’) or the most reflective (‘auto’) target. Besides, you can exclude all targets that are closer than the predefined distance (gating distance selection, see below). 5.3. Mode switching procedure By pressing M button (5) (Fig.1) when the System is in READY mode, you enter the Mode selecting state.
  • Page 13 Mode Screen display Select 1) Standard 1 Meter this mode Go to next mode Select 1) Standard 2 Meter this mode Go to next mode Select this mode Codes Go into sub menu Code 1 Select Meter this mode Go to next mode Code 2 Select...
