New Holland 702D (78-inch) Specifications

New Holland
Front Blades – Bolt-on Specifications
702D
MODEL
Moldboard width, in. (mm)
Moldboard height, in. (mm) .........................................................................................................20 (508).................................................................................................................
Moldboard thickness, in. (mm).....................................................................................................0.25 (6) .................................................................................................................
Cutting edge - reversible, in. (mm).......................................................................................0.5 x 6 (13 x 152) .........................................................................................................
Blade lift height, in. (mm).............................................................................................................10 (254).................................................................................................................
Digging depth, in. (mm)..............................................................................................................4.25 (108) ...............................................................................................................
Max. angle blade (degrees) ...............................................................................................................30......................................................................................................................
Hydraulic angle blade kit ..............................................................................................................standard.................................................................................................................
Weight, lbs. (kg.)
Visit our Web site at www.newholland.com/na. Or, call toll-free 866-NEW-HLN (866-639-4563).
Design, materials and/or specifications are subject to
change without notice and without liability therefor.
Specifications are applicable to units sold in Canada, the
United States, its territories and possessions, and may
var y outside these areas.
© 2008 CNH America LLC
New Holland is a registered trademark of CNH America LLC.
702D (78-inch)
78 (1981)
588 (267)
Safety begins with a thorough understanding of
the equipment. Always make sure you and
your operators read the Operator's Manual
before using the equipment. Pay close
attention to all safety and operating
decals and never operate machinery
without all shields, protective devices
and structures in place.
702D (84-inch)
84 (2134)
641 (291)
