- Page 1 NETWORK 1275 Danner Dr TECHNOLOGIES Aurora, OH 44202 INCORPORATED VOPEX-USBV-2 USB Keyboard, Video, and Mouse Installation and Operation Manual Tel:330-562-7070 Fax:330-562-1999 www.nti1.com VOPEX Series Splitter/Hub MAN034 Rev Date 10/7/2004...
-
Page 2: Warranty Information
A return authorization number is required for all repairs/returns. COPYRIGHT Copyright © 2004 by Network Technologies Inc. All rights reserved. No part of this publication may be reproduced, stored in a retrieval system, or transmitted, in any form or by any means, electronic, mechanical, photocopying, recording, or otherwise, without the prior written consent of Network Technologies Inc, 1275 Danner Drive, Aurora, Ohio 44202. -
Page 3: Table Of Contents
INTRODUCTION... 1 LIMITATIONS ... 1 MATERIALS ... 1 FEATURES AND FUNCTIONS... 2 INSTALLATION... 3 Monitor Connection... 3 Mouse Connection... 3 Keyboard Connection ... 3 CPU Connection ... 4 Hub Ports ... 4 Power-Up ... 4 OPERATION ... 5 Keyboard Command Mode... 5 Mice and Trackballs with MACs ... -
Page 4: Introduction
NTI BRANDNAME AND DESCRIPTON INTRODUCTION The VOPEX-USBV-2-HUB (VOPEX) is a USB KVM Splitter and 3-Port Hub. It enables the control of one USB enabled CPU through two separate USB keyboards, USB mice, and VGA monitors and it enables the connection of 3 additional USB devices (other than keyboards or mice). -
Page 5: Features And Functions
DEVICE 2 DEVICE 1 FEATURES AND FUNCTIONS Power Switch- to power up or power down the VOPEX-USBV-2. Power LED- for visual indication of splitter's power status Mode Status LEDs- for visual indication of splitter's operating mode Mode Switch- press to manually switch between operating modes... -
Page 6: Installation
NTI BRANDNAME AND DESCRIPTON INSTALLATION FYI: It is not necessary to disconnect power to the CPU and monitor(s) before installation. Monitor Connection Disconnect the monitor cable at the CPU and reconnect it to the "MONITOR 1" port on the VOPEX. (See Fig. 1) Plug a second monitor (or optional VEXT-xx extension cable) into the "MONITOR 2"... -
Page 7: Cpu Connection
NTI BRANDNAME AND DESCRIPTON CPU Connection Connect the male USB type A connector end of the USB-AB-1M-ST cable into the device port on the CPU. Connect the male USB type B connector of the same cable to the "CPU" port on the VOPEX. Connect the male 15HD connector end of the VEXT-3 into the CPU’s video port. -
Page 8: Operation
ESC on the keyboard. ) The mouse will not operate while in Command Mode. NOTE: While in Command Mode, when a proper programming key is pressed and recognized by the switch, the LEDs on the keyboard will flash once to indicate acceptance. The user must exit Command Mode (by pressing ESC) to see a change take effect in the switch operation. -
Page 9: Mice And Trackballs With Macs
NTI BRANDNAME AND DESCRIPTON Mice and Trackballs with MACs The VOPEX can be configured to enable full functionality between mice and trackballs having two or more buttons and a USB MAC CPU. By default, the CPU port on the VOPEX is configured for use a WINDOWS or SUN CPU and has no special translation for using multi-function mice and trackballs when a MAC CPU is connected. -
Page 10: Specifications
NTI BRANDNAME AND DESCRIPTON SPECIFICATIONS Size: Each unit is 8.5”W x 6”D x 2.6”H Power: Powered by 120 or 240VAC @ 50 or 60Hz-5VDC/2.0A AC Adapter Connections: 15HD VGA & SGA compatible USB Type A female device connectors USB Type B female CPU connector TROUBLESHOOTING PROBLEM •...
