ABB-Welcome
Pos: 55 /DinA4 - Anleitungen Online/Ueberschriften/4./Datum - Uhrzeit @ 20\mod_1323862082869_15.docx @ 112283 @ 4 @ 1
5.2.7. 4

Date / time

Pos: 56 /DinA4 - Anleitungen Online/Inhalt/KNX/DoorEntry/83220-AP-xxx/Einstellungen Datum-Uhrzeit - 83220-AP-xxx @ 20\mod_1323862147113_15.docx @ 112291 @ @ 1
With the change to "Date and time" the following functions become available:
No. F unc tion
1 Time
– Set the time via the "Plus / minus" buttons.
– Before the adjustment tip on ""Hours", "Minutes" or "Seconds". The active area is marked with a frame.
2 Date
– Set the date via the "Plus / minus" buttons.
– Before the adjustment tip on "Day", "Month" or "Year". The active area is marked with a frame.
3 OK
– By tipping on this button you activate the settings.
4 Back
– By tipping on this button you return to the start page without saving the settings.
5 Summertime
– Activate or deactivate the summertime by tipping on the checkbox (automatic switchover).
6 Time
– Select the format of the displayed time via the fold-down menu.
– Available are 12 h am/pm / 12 h / 24 h.
7 Date
– Select the format of the displayed date via the fold-down menu.
Pos: 57 /Busch-Jaeger (Neustruktur)/Modul-Struktur/Online-Dokumentation/Steuermodule - Online-Dokumentation (--> Für alle Dokumente <--)/++++++++++++ Seitenumbruch ++++++++++++ @ 9\mod_1268898668093_0.docx @ 52149 @ @ 1
| 0073-1-7516
Fig. 14: Settings of the date and time
Operation
— 21 —
