Page 2: Table Of Contents
Appendix A: Cable Connections ... 10 RJ-45 Ethernet Network Ports ... 10 Appendix B: Troubleshooting ... 12 Appendix C: Technical Specifications ... 13 Appendix D: Registering your NetComm Product ... 14 Contact Information ... 14 Legal & Regulatory Information ... 14 Product Warranty ... 15... -
Page 3: Important Information
48 volts DC delivered by the PoE injector. If you do not check the POE compatibility and voltage required, you will damage the attached device, the Injector and any computer connected to the network. NetComm will not accept any responsibility for any loss or damage araising from the use of this product in the wrong manner. -
Page 4: Introduction
Introduction Thank you for purchasing NetComm’s Power-over-Ethernet Adapter Kit. Before you start installing the Power-over-Ethernet Adapter Kit, verify the following parts are included in your package. Package Contents The package contains the following: ■ One unit Power-over-Ethernet Injector, and one unit of Power-over-Ethernet Splitter ■... -
Page 5: Installation
Lights green to indicate that the power has been supplied to the device Connects the RJ-45 port of Splitter through Cat 5 Ethernet cable Connects to the power adapter for receiving power - 48 Volts DC. Connects to other network devices NetComm NPPOE1001 Power over Ethernet Kit... -
Page 6: The Poe Splitter
Splitter PWR LED Power and Data In Port Cat 5 Ethernet Cable Power Cable Voltage Selector NetComm NPPOE1001 Power over Ethernet Kit Splitter Figure 2 Description Lights green to indicate that the power has been supplied to the device Connects the RJ-45 port of Injector through Cat 5... -
Page 7: Connecting The Power-Over-Ethernet Adapter Kit
Select the voltage output on the splitter, either 5Volts or 12Volts. Please check the voltage required by your device in your device manual. Step 7 Turn the power on to the injector at the 240Volt Power Point. YML720 Rev1 www.netcomm.com.au Figure 3 NetComm NPPOE1001 Power over Ethernet Kit... - Page 8 The following figure illustrates connection of an NP5400 Access Point using Power Over Ethernet. Please Note: The total distance from the NB1300+4 ADSL Modem/Router to the NP5400 Access Point (as used in this example) should be less than 100 metres (i.e. 328 feet). NetComm NPPOE1001 Power over Ethernet Kit Figure 4 YML720Rev1 www.netcomm.com.au...
- Page 9 The following figure illustrates the connection of a Network Camera using Power Over Ethernet. Please Note: The total distance from the NB1300+4 ADSL Modem/Router to the Network Camera (as used in this example) should be less than 100 metres (i.e. 328 feet). YML720 Rev1 www.netcomm.com.au Figure 5 NetComm NPPOE1001 Power over Ethernet Kit...
-
Page 10: Appendix A: Cable Connections
If you are unsure about which cable to use or which socket to connect it to, please refer to the hardware installation section in this manual. If you are still not sure about cable connections, please contact a professional computer technician or NetComm for further advice. RJ-45 Ethernet Network Ports RJ-45 Network Ports can connect any networking devices that use a standard LAN interface, such as a Hub/Switch Hub or Router. - Page 11 Straight-Through Cabling Becomes Cross-Over Cabling Becomes RJ-45 Connector Pin Assignment Normal Assignment Input Receive Data + Input Receive Data - Output Transmit Data + Output Transmit Data - 4,5,7,8 Power - PoE pins NetComm NPPOE1001 Power over Ethernet Kit...
-
Page 12: Appendix B: Troubleshooting
My network device still does not work. If you have followed the above tips and your device (i.e. Access Point, Network Camera, etc) is still not working, please refer to the troubleshooting section of your device’s manual. NetComm NPPOE1001 Power over Ethernet Kit YML720Rev1 www.netcomm.com.au... -
Page 13: Appendix C: Technical Specifications
PSE Adapter: 64g 0°C to 40°C (32°F to 122°F) -55°C to 105°C (-67°F to 221°F) 10% to 90% relative humidity, non-condensing 20% to 95% relative humidity, non-condensing DC 48V FCC Class B, CE, C-Tick (N367) NetComm NPPOE1001 Power over Ethernet Kit... -
Page 14: Appendix D: Registering Your Netcomm Product
The power supply that is provided with this unit is only intented for use with this product. Do not use this power supply with any other product or do not use any other power supply that is not approved for use with this product by NetComm. Failure to do so may cause damage to this product, fire or result in personal injury. -
Page 15: Product Warranty
The cost of transporting product to and from NetComm's nominated premises is your responsibility; and, NetComm does not have any liability or responsibility under this warranty where any cost, loss, injury or damage of any kind, whether direct, indirect, consequential, incidental or otherwise arises out of events beyond NetComm's reasonable control. -
Page 16: Technical Specifications
EMC Certification FCC Class B, CE, C-Tick (N367) NetComm is Australia’s dynamic data communications and networking solutions provider. For more information on this and other NetComm products, please visit www.netcomm.com.au NetComm Limited ABN 85 002 490 486 PO Box 1200, Lane Cove NSW 2066 Australia.
