Portable Projector
NP62/NP61/NP52/NP41
User's Manual
• The projector's model name indicated on the projector's label is NP62,
NP61, NP41, NP62G, NP61G, NP52G, and NP41G respectively.
All the models are referred to as NP62, NP61, NP52, and NP41 throughout
the user's manual except some of the specification pages.
• The NP52 is not distributed in North America.

Advertisement

Table of Contents
loading

Related Manuals for NEC NP41G

Summary of Contents for NEC NP41G

  • Page 1 Portable Projector NP62/NP61/NP52/NP41 User’s Manual • The projector's model name indicated on the projector's label is NP62, NP61, NP41, NP62G, NP61G, NP52G, and NP41G respectively. All the models are referred to as NP62, NP61, NP52, and NP41 throughout the user's manual except some of the specification pages. • The NP52 is not distributed in North America.
  • Page 2 • VESA is a registered trademark of Video Electronics Standards Association. • MicroSaver is a registered trademark of Kensington Computer Products Group, a division of ACCO Brands. • Other product and company names mentioned in this user’s manual may be the trademarks or registered trade- marks of their respective holders. • The Bluetooth® registered trademark is owned by Bluetooth SIG, Inc. • Contains the software (UBQ-Blue Bluetooth protocol stack 2.0+EDR (QD ID : B010586)) from Canon i-tech,Inc & Canon Information Technologies Philippines,Inc. NOTES (1) The contents of this user’s manual may not be reprinted in part or whole without permission. (2) The contents of this user’s manual are subject to change without notice. (3) Great care has been taken in the preparation of this user’s manual; however, should you notice any question- able points, errors or omissions, please contact us. (4) Notwithstanding article (3), NEC will not be responsible for any claims on loss of profit or other matters deemed to result from using the Projector.

  • Page 3: Safety Cautions

    Important Information Safety Cautions Precautons Please read this manual carefully before using your NEC NP62/NP61/NP52/NP41 projector and keep the manual handy for future reference. Your serial number is located on the bottom of your projector. Record it here: CAUTION To turn off main power, be sure to remove the plug from power outlet. The power outlet socket should be installed as near to the equipment as possible, and should be eas- ily accessible. CAUTION TO PREVENT SHOCK, DO NOT OPEN THE CABINET. THERE ARE HIGH-VOLTAGE COMPONENTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. This symbol warns the user that uninsulated voltage within the unit may be sufficient to cause electrical shock. Therefore, it is dangerous to make any kind of contact with any part inside of the unit. This symbol alerts the user that important information concerning the operation and maintenance of this unit has been provided. The information should be read carefully to avoid problems. WARNING: TO PREVENT FIRE OR SHOCK, DO NOT EXPOSE THIS UNIT TO RAIN OR MOISTURE. DO NOT USE THIS UNIT’S PLUG WITH AN EXTENSION CORD OR IN AN OUTLET UNLESS ALL THE PRONGS CAN BE FULLY INSERTED.

  • Page 4: Important Safeguards

    • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio / TV technician for help. For UK only: In UK, a BS approved power cable with moulded plug has a Black (five Amps) fuse installed for use with this equipment. If a power cable is not supplied with this equipment please contact your supplier. Important Safeguards These safety instructions are to ensure the long life of your projector and to prevent fire and shock. Please read them carefully and heed all warnings. Installaton • Do not place the projector in the following conditions: - on an unstable cart, stand, or table. - near water, baths, or damp rooms. - in direct sunlight, near heaters, or heat radiating appliances. - in a dusty, smoky or steamy environment. - on a sheet of paper or cloth, rugs or carpets. • If you wish to have the projector installed on the ceiling: - Do not attempt to install the projector yourself. - The projector must be installed by qualified technicians in order to ensure proper operation and reduce the risk of bodily injury. - In addition, the ceiling must be strong enough to support the projector and the installation must be in accor- dance with any local building codes. - Please consult your dealer for more information. Place the projector n a horzontal poston The tilt angle of the projector should not exceed 10 degrees, nor should the projector be installed in any way other than the desktop and ceiling mount, otherwise lamp life could decrease dramatically. 10˚ Important Informaton...
  • Page 5 • Do not try to touch the ventilation outlet on the right front (when seen from the front) as it can become heated while the projector is turned on and immediately after the projector is turned off. • Prevent foreign objects such as paper clips and bits of paper from falling into your projector. Do not attempt to retrieve any objects that might fall into your projector. Do not insert any metal objects such as a wire or screw- driver into your projector. If something should fall into your projector, disconnect it immediately and have the object removed by a qualified service personnel. • Do not place any objects on top of the projector. • Do not touch the power plug during a thunderstorm. Doing so can cause electrical shock or fire. • The projector is designed to operate on a power supply of 100-240V AC 50/60 Hz (NP62/NP61/NP41) or 200-240V AC 50/60 Hz (NP62G/NP61G/NP52G/NP41G). Ensure that your power supply fits this requirement before attempting to use your projector. • Do not look into the lens while the projector is on. Serious damage to your eyes could result. • Keep any items such as magnifying glass out of the light path of the projector. The light being projected from the lens is extensive, therefore any kind of abnormal objects that can redirect light coming out of the lens, can cause unpredictable outcome such as fire or injury to the eyes. • Do not cover the lens with the black lens cap or equivalent while the projector is on. Doing so can lead to melt- ing of the cap and possibly burning your hands due to the heat emitted from the light output.

  • Page 6: Lamp Replacement

    CAUTION: • DO NOT TOUCH THE LAMP immediately after it has been used. It will be extremely hot. Turn the projector off and then disconnect the power cable. Allow at least one hour for the lamp to cool before handling. • When removing the lamp from a ceiling-mounted projector, make sure that no one is under the projector. Glass fragments could fall if the lamp has been burned out. Note for US Resdents The lamp in this product contains mercury. Prease dispose according to Local, State or Federal Laws.
  • Page 7 About Hgh Alttude mode • Set [FAN MODE] to [HIGH ALTITUDE] when using the projector at altitudes approximately 5000 feet/1500 me- ters or higher. • Using the projector at altitudes approximately 5000 feet/1500 meters or higher without setting to [HIGH ALTI- TUDE] can cause the projector to overheat and the protector could shut down. If this happens, wait a couple minutes and turn on the projector. • Using the projector at altitudes less than approximately 5000 feet/1500 meters and setting to [HIGH ALTI- TUDE] can cause the lamp to overcool, causing the image to flicker. Switch [FAN MODE] to [AUTO]. • Using the projector at altitudes approximately 5000 feet/1500 meters or higher can shorten the life of optical components such as the lamp. About Copyrght of orgnal projected pctures: Please note that using this projector for the purpose of commercial gain or the attraction of public attention in a venue such as a coffee shop or hotel and employing compression or expansion of the screen image with the fol- lowing functions may raise concern about the infringement of copyrights which are protected by copyright law.

  • Page 8: Table Of Contents

    Table of Contents Important Information 1. Introduction ➊ What's in the Box? ... 1 ➋ Introduction to the Projector ... 2 ➌ Part Names of the Projector ... 4 Top Features ... 6 Terminal Panel Features ... 6 ➍ Part Names of the Remote Control... 7 Battery Installation ... 8 Remote Control Precautions ..8 Operating Range for Wireless Remote Control ... 8 2. Installation and Connections ➊ Setting Up the Screen and the Projector ... 9 Selecting a Location ..9 Throw Distance and Screen Size ..10 ➋ Making Connections ...
  • Page 9 5. Using the Viewer (NP62/NP52) ➊ What you can do with the Viewer ... 35 ➋ Projecting images stored in a USB memory device (Basic operation) ... 37 ➌ Operating the slide screen ..40 ➍ Operating the thumbnail screen ... 40 ➎ Using the Bluetooth® wireless technology to transmit images ... 45 6. Using On-Screen Menu ➊ Using the Menus ..48 ➋ Menu Elements ..49 ➌ List of Menu Items ... 50 ➍ Menu Descriptions & Functions [SOURCE] ... 52 [COMPUTER] ... 52 [VIDEO] ... 52 [S-VIDEO] ..52 ➎ Menu Descriptions & Functions [ADJUST] .

  • Page 10: Important Information

    1. Introduction ➊ What's in the Box? Make sure your box contains everything listed. If any pieces are missing, contact your dealer. Please save the original box and packing materials if you ever need to ship your projector. Projector Lens cap (24FT9983) Power cable (US: 7N080228) (EU: 7N080017) Quick Setup Guide (7N8P8881) Important Information (7N8P8891) VGA signal cable (7N520052) CD-ROM User’s manual (7N951221) Soft case (24BS7901) Remote control Batteries (AAA•2)

  • Page 11: ➋ Introduction To The Projector

    ➋ Introduction to the Projector This section introduces you to your new projector and describes the features and controls. Congratulatons on Your Purchase of the Projector This DLP™ projector is one of the very best projectors available today. The projector enables you to project pre- cise images up to 300 inches (measured diagonally) from your PC or Macintosh computer (desktop or notebook), VCR, DVD player or document camera. You can use the projector on a tabletop or cart, you can use the projector to project images from behind the screen, and the projector can be permanently mounted on a ceiling* Do not attempt to mount the projector on a ceiling yourself. The projector must be installed by qualified technicians in order to ensure proper operation and reduce the risk of bodily injury. In addition, the ceiling must be strong enough to support the projector and the installation must be in accor- dance with any local building codes. Please consult your dealer for more information.
  • Page 12 . Introducton About ths user's manual The fastest way to get started is to take your time and do everything right the first time. Take a few minutes now to review the user's manual. This may save you time later on. At the beginning of each section of the manual you'll find an overview. If the section doesn't apply, you can skip it. In this user's manual the drawings of the projector show an example of NP61.

  • Page 13: ➌ Part Names Of The Projector

    ➌ Part Names of the Projector Front/Top Zoom Lever (→ page 22) Lens Lens Cap Focus Sensor (→ page 22) Adjustable Tilt Foot Button (→ page 21) Rear Terminal Panel (→ page 6) Ventilation (inlet) AC Input Connect the supplied power cable's three-pin plug here, and plug the other end into an active wall outlet.
  • Page 14 Bottom Rear Feet (→ page 21) Lamp Cover (→ page 72) Cooling Pump Cover (→ page 74) . Introducton...

  • Page 15: Top Features

    3. S-VIDEO IN Connector (Mn DIN  Pn) (→ page 14) . AUDIO IN Mn Jack (Stereo Mn) (→ page 12, 13, 14) . PC CONTROL Port (Mn DIN 8 Pn) (→ page 84) Use this port to connect a PC or control system. This enables you to control the projector using se- rial communication protocol. If you are writing your own program, typical PC control codes are on page LAMP STATUS AUTO...

  • Page 16: ➍ Part Names Of The Remote Control

    ❹ Part Names of the Remote Control . Infrared Transmtter (→ page 8) . POWER ON Button (→ page 16) 3. POWER OFF Button (→ page 27) . MAGNIFY (+) (–) Buttons (→ page 29) . AV-MUTE Button (→ page 29) . PAGE (UP) / (DOWN) Buttons* (→ page 34) 7. MENU Button (→ page 48) 8.

  • Page 17: Battery Installation

    • Ensure that you have the batteries' polarity (+/–) aligned correctly. • Do not use new and old batteries together, or use different types of batteries together. • Dispose of used batteries according to your local regulations. Operatng Range for Wreless Remote Control Remote control Remote control • The infrared signal operates by line-of-sight up to a distance of about 22 feet/7 m and within a 60-degree angle of the remote sensor on the projector cabinet. • The projector will not respond if there are objects between the remote control and the sensor, or if strong light falls on the sensor. Weak batteries will also prevent the remote control from properly operating the projector. Install new batteries (AAA). En- sure that you have the batteries' polarity (+/–) aligned correctly. 30° 30° 22 feet / 7 m...

  • Page 18: Installation And Connections

    2. Installation and Connections This section describes how to set up your projector and how to connect video and audio sources. ➊ Setting Up the Screen and the Projector Selectng a Locaton The further your projector is from the screen or wall, the larger the image. The minimum size the image can be is 33" (0.84 m) measured diagonally when the projector is roughly 57 inches (1.44 m) from the wall or screen. The largest the image can be is 300" (7.6 m) when the projector is about 484 inches (12.3 m) from the wall or screen. Use the chart below as a rough guide. 487.7(W)×365.8(H) / 192(W)×144(H) 406.4(W)×304.8(H) / 160(W)×120(H) 365.8(W)×274.3(H) / 144(W)×108(H) 304.8(W)×228.6(H) / 120(W)×90(H) 243.8(W)×182.9(H) / 96(W)×72(H) 203.2(W)×152.4(H) / 80(W)×60(H) 162.6(W)×121.9(H) / 64(W)×48(H) 121.9(W)×91.4(H) / 48(W)×36(H)

  • Page 19: Throw Distance And Screen Size

    Throw Dstance and Screen Sze The following shows the proper relative positions of the projector and screen. Refer to the table to determine the position of installation. Dstance Chart Projector bottom Screen Size Diagonal Width Height wide - inch inch inch inch inch 104 - 116 - 122 - 130 - 100 145 - 120 174 - 150 120 219 -...
  • Page 20 Note that [ECO] mode will be selected automatically at 86°F to 104°F/30°C to 40°C when used in [HIGH ALTITUDE].) • Do not expose the projector to moisture, dust, or smoke. This will harm the screen image. • Ensure that you have adequate ventilation around your projector so heat can dissipate. Do not cover the vents on the side or the front of the projector.

  • Page 21: ➋ Making Connections

    Enablng the computer’s external dsplay Displaying an image on the notebook PC’s screen does not necessarily mean it outputs a signal to the projector. When using a PC compatible laptop, a combination of function keys will enable/disable the external display. Usually, the combination of the ‘Fn” key along with one of the 12 function keys gets the external display to come on or off. For example, NEC laptops use Fn + F3, while Dell laptops use Fn + F8 key combinations to toggle through external display selections. COMPUTER IN VGA signal cable (supplied) To mini D-Sub 15-pin connector on the projector.

  • Page 22: Connecting Your Dvd Player With Component Output

    Connectng Your DVD Player wth Component Output COMPUTER IN Optional 15-pin - to - RCA (female) ×3 cable (ADP-CV1E) Component video RCA×3 cable (not supplied) Component NOTE: Refer to your DVD player's owner's manual for more information about your DVD player's video output requirements. AUDIO IN COMPUTER IN VIDEO IN...

  • Page 23: Connecting Your Vcr

    Connectng Your VCR VIDEO IN S-Video cable (not supplied) Video cable (not supplied) AUDIO OUT NOTE: Refer to your VCR owner's manual for more information about your equipment's video output requirements. NOTE: An image may not be displayed correctly when a Video or S-Video source is played back in fast-forward or fast-rewind via a scan converter.

  • Page 24: Connecting The Supplied Power Cable

    Connectng the Suppled Power Cable Connect the supplied power cable to the projector. First connect the supplied power cable's three-pin plug to the AC IN of the projector, and then connect the other plug of the supplied power cable in the wall outlet. The projector will go into its stand- by mode and the POWER indica- tor will glow orange. To wall outlet CAUTION: Do not try to touch the ventilation outlet on the right front (when seen from the front) as it can become heated while the projector is turned on and immediately after the projector is turned off. LAMP STATUS POWER FOCUS V ID S -V ID E O IN D IO ON/STAND BY Make sure that the prongs are fully inserted into both the power plug and the wall outlet.

  • Page 25: Projecting An Image (Basic Operation)

    NOTE: Before turning on the projector, first connect the supplied power cable's three-pin plug to the AC IN of the projector, and then connect the other plug of the supplied power cable in the wall outlet. Make sure that the projector is in its standby mode and the power indicator is glowing orange.

  • Page 26: Note On Startup Screen (Menu Language Select Screen)

    NOTE: If you turn on the projector immediately after the lamp is turned off or when the temperature is high, the fans run without displaying an image for some time and then the projector will display the image.

  • Page 27: ➋ Selecting A Source

    - The selected signal will be displayed. TIP: Detecting the Signal Automatically Press and hold the SELECT ▶ button for a minimum of 2 seconds, the projector will search for the next available input source. Detecting the signal automatically is not available for the Viewer source on the NP62 and NP52.

  • Page 28: Enter Button

    7. restart the projector. The source you selected in step 5 will be displayed. TIP: When the projector is in Standby mode, applying an RGB signal from a computer connected to the COMPUTER IN input will power on the projector and simultaneously project the computer's image.

  • Page 29: ➌ Adjusting The Picture Size And Position

    3. Projectng an Image (Basc Operaton) ➌ Adjusting the Picture Size and Position Manual Operaton Place your projector on a flat level surface and ensure that the projector is square to the screen. [Adjust the Tilt Foot] Lift the front edge of the projector to center the image verti- cally. (→ page 21) [Zoom] Use the ZOOM lever to adjust the image size on the screen. Automatc Operaton [AUTO FOCUS] Just placing the projector on a flat level surface makes a fo- cused image. (→ page 22)
  • Page 30 Do not try to touch the ventilation outlet during Tilt Foot adjust- ment as it can become heated while the projector is turned on and during its cool down period after it is turned off. 2. Push up and hold the adjustable tilt foot Button on the front of the projector to extend the adjustable tilt foot (maximum height). 3. release the adjustable tilt foot Button to lock the adjustable tilt foot.

  • Page 31: Auto Focus

    • When moving the projector so slowly that the focus sensor cannot detect the distance to the screen. • When moving the screen, not the projector, because the focus sensor cannot detect the distance to the screen TIP: To turn off the AUTO FOCUS function, from the menu select [SETUP] → [OPTIONS(1)] → [AUTO FOCUS] and select [OFF].
  • Page 32 Place the projector so that the lens surface is parallel to the screen. Also, adjust the height to keep the projector level by rotating the rear feet. TIP: To turn off the AUTO KEYSTONE function, from the menu select [SETUP] → [GENERAL] → [AUTO KEYSTONE] and select [OFF].

  • Page 33: ➍ Adjusting Focus Manually

    The focus adjustment screen will be closed if no button operation is made for 5 seconds. TIP: If the projector is placed within the effective focus range, pressing and holding the FOCUS for a minimum of 2 seconds starts the AUTO FOCUS func- tion.

  • Page 34: ➎ Correcting Keystone Distortion Manually

    ➎ Correcting Keystone Distortion Manually You can also correct the vertical keystone distortion manually. NOTE: • Keystone correction by using the SELECT ▲/▼ button is not possible when [VIEWER] is selected for the source. • The vertical keystone angle can be corrected between 40 degrees upward and 40 degrees downward from level. Adjust the keystone distortion manually in the following cases: • To fine tune Keystone correction even after performing the [AUTO KEYSTONE] adjustment • When the menu setting for [AUTO KEYSTONE] is turned off...

  • Page 35: ➏ Optimizing Rgb Picture Automatically

    Performing the [HORIZONTAL], [VERTICAL], [CLOCK] or [PHASE] function will store the adjustment values of the currently projected source into the projector’s memory. • The next time the same source (same resolution, horizontal and vertical frequencies) is projected; the projector will call up from memory the stored values for the source. •...

  • Page 36: ➐ Adjusting Volume Up & Down

    Parts of the projector will become heated during operation. Use caution when picking up the projector immedi- ately after it has been operating. NOTE: Do not turn off the projector using the "Direct Power Off" function within 10 seconds of making adjustment or setting changes and closing the menu. Doing so can cause loss of adjustments and settings. 3. Projectng an Image (Basc Operaton)

  • Page 37: ❾ After Use

    4. Cover the lens with the lens cap. 5. Put the projector and its accessories in the supplied soft case. Place the projector in the soft case as shown below. This is to prevent the lens from damage. Lens NOTE: When placing the projector in the soft case, retract the tilt foot and the rear feet.

  • Page 38: Convenient Features

    4. Convenient Features ➊ Turning Off the Image and Sound Press the AV-MUTE button to turn off the image and sound for a short period of time. Press again to restore the image and sound from the speaker. NOTE: Even though the image is turned off, the menu still remains on the screen. ➋ Freezing a Picture Press the FREEZE button to freeze a picture. Press again to resume motion. NOTE: • The image is frozen but the original video is still playing back. •...

  • Page 39: ➍ Changing Lamp Mode

    Brightness, NP52NP41: approx. 85% Brightness). • The [LAMP MODE] can be changed by using the menu. Select [SETUP] → [GENERAL] → [LAMP MODE] (→ page 61) ➎ Preventing the Unauthorized Use of the Projector A keyword can be set for your projector using the Menu to avoid operation by an unauthorized user. When a key- word is set, turning on the projector will display the Keyword input screen. Unless the correct keyword is entered, the projector cannot project an image. To enable the Securty functon: 1. Press the MenU button.
  • Page 40 The SECURITY function has been enabled. To turn on the projector when [SECURITY] s enabled: When the SECURITY function is enabled and the projector is turned on, the projector will display a blue back- ground. To display an image at this time, press the MENU button to display the Keyword input screen.
  • Page 41 To dsable the SECURITY functon: 1. Press the MenU button. The menu will be displayed. 2. select [setUP] → [installatiOn] → [seCUritY] and press the enter button. The OFF/ON menu will be displayed. 3. select [Off] and press the enter button. The KEYWORD CONFIRMATION screen will be displayed.

  • Page 42: ➏ Using The Optional Remote Mouse Receiver (Np01Mr)

    . Convenent Features ➏ Using the Optional Remote Mouse Receiver (NP01MR) The optional remote mouse receiver enables you to operate your computer’s mouse functions from the remote control. It is a great convenience for clicking through your computer-generated presentations. Connectng the remote mouse recever to your computer If you wish to use the remote mouse function, connect the mouse receiver and computer. The mouse receiver can be connected directly to the computer’s USB port (type A). NOTE: Depending on the type of connection or OS installed on your computer, you may have to restart your computer or change your computer settings.

  • Page 43: About Drag Mode

    Operatng your computer’s mouse from the remote control You can operate your computer's mouse from the remote control. PAGE UP/DOWN Button ... scrolls the viewing area of the window or to move to the previous or next slide in PowerPoint on your computer. SELECT ▲▼◀▶ Buttons ... moves the mouse cursor on your computer. MOUSE-L Button ...

  • Page 44: Using The Viewer (Np62/Np52)

    5. Using the Viewer (NP62/NP52) ❶ What you can do with the Viewer The NP62 and NP52 have the Viewer. The Viewer has the following features. • When a commercially available USB memory that stores image files is inserted into the USB port (Type A) of the projector, the Viewer allows you to view the image files on the USB memory. Even if no computer is available, presentations can be conducted simply with the projector. • Image formats such as GIF, JPEG, PNG, and BMP can be projected. • The Viewer displays the thumbnail screen on which you can jump to any specific image you wish to project. • There are two ways of playback for slideshow: manual playback and auto playback. The interval time can be changed in auto playback. • The order of displaying images can be set by name, extension, date or size. Ascending or descending order can be selected. • Images can be rotated by 90 degrees during playback. • Connecting the optional Bluetooth you to transmit images wirelessly from your computers or mobile phones with Bluetooth wireless technology to the projector. Operation of the optional Bluetooth® USB adaptor (NP01BA) is subjected to the regulations of the countries listed below, and may be prohibited to use outside the country where you purchased.
  • Page 45 • The USB port of the NP62 and the NP52 does not support USB hub. Both a USB memory and the Bluetooth cannot be used at the same time. • The following operations by using the buttons on the projector are not possible when the VIEWER screen such as the slide screen and the thumbnail screen is displayed.

  • Page 46: ➋ Projecting Images Stored In A Usb Memory Device (Basic Operation)

    1. turn on the projector. (→ page 16) 2. insert the UsB memory into the UsB port of the pro- jector. - To remove the USB memory from the projector, select "REMOVE USB DEVICE" from the OPTIONS menu. (→ Step 5 on page 39) 3.
  • Page 47 • To return the slide screen from the thumbnail screen, select the image you wish to display in slide and press the ENTER button. Removng the USB memory from the projector 1. Press the MenU button with the thumbnail screen displayed.
  • Page 48 The confirmation message will be changed. 5. remove the UsB memory from the projector. NOTE: If you remove the USB memory from the projector without using [REMOVE USB DEVICE] from the menu, the projector may not operate correctly. If this happens, turn off the projector and unplug the power cable.

  • Page 49: ➌ Operating The Slide Screen

    ❸ Operating the slide screen The slide screen allows you to perform the following operations. SELECT ▶ button...Displays the next image. SELECT ◀ button...Displays the previous image. ENTER button ...Displays the pointer ( Press the ENTER button again to close the pointer. EXIT button ...Switches to the thumbnail screen. MENU button ...Displays the control bar.
  • Page 50 • When the folder is highlighted: Displays the last date and time of the folder. • When the drive is highlighted: Displays the free space of the drive. Menu item Selects to start slideshow. Deletes the images received with Bluetooth wireless technology. (Note) The submenu of [DELETE] or [DELETE ALL FILES] is displayed. Stops the USB memory inserted into the projector. Execute this menu item before removing the USB memory from the projector. Displays [OPTIONS] menu. (→ this page) [MANUAL] AUTO [5 SECONDS] - 300 SECONDS [SLIDE] THUMBNAILS [ON] [ON] .
  • Page 51 BD ADDRESS FIRMWARE VERSION DATA FONT Note 1: The [SORT] setting will be returned to [NAME(ABC..)] when the projector is turned off and then back on. Note 2: These items will be displayed when the optional Bluetooth page 45) (Note 1) [NAME (ABC..)] NAME (ZYX..)
  • Page 52 Enterng Characters To enter or change [DEVICE NAME] and [PASSKEY] at the use of Bluetooth® USB adaptor, use the character en- try screen (software keyboard). This section uses an example of entering a passkey to describe how to enter characters. When you select [CHANGE] of [PASSKEY] from the [OPTIONS] menu, the character entry screen will be dis- played. Enterng characters 1. Press the seleCt ▼ button. The cursor will move to the character type section. 2.
  • Page 53 Changng characters n the entry field 1. Press the seleCt ▲ or ▼ button to move the cur- sor to select will be changed to dark gray. 2. Press the seleCt ◀ or ▶ button. The cursor (I) in the entry field will be moved from side to side.

  • Page 54: ➎ Using The Bluetooth® Wireless Technology To Transmit Images

    Bluetooth wireless technology to the projector. [Important] • If you remove the Bluetooth® USB adaptor from the projector, all the images that the projector received will be deleted. • When the projector goes into the standby mode or when the AC power supply is turned off, all the re- ceived images will be deleted. • Received images cannot be stored to the projector. • The maximum available space for received images in all is 6MB. One image must not exceed 2.5MB in size.
  • Page 55 4. transmit images wirelessly from your Bluetooth computers or mobile phones to the projector • Select the device name of the projector and enter your passkey on your transmission device. The default device name of the projector is “BD address of inserted Bluetooth® USB adaptor”. The default passkey is “0000”. •...
  • Page 56 Wait until data transmission from another transmission device is completed. • Check if a passkey is set on the projector. If so, the passkey is also required to be correctly set on your transmission device. (→ page 42) •...

  • Page 57: Using On-Screen Menu

    2. Press the seleCt ◀▶ buttons on the remote control or the projector cabinet to display the submenu. 3. Press the enter button on the remote control or the projector cabinet to highlight the top item or the first tab.

  • Page 58: ➋ Menu Elements

    ➋ Menu Elements Highlight Available buttons Source High Altitude symbol Thermometer symbol Key Lock symbol Menu wndows or dalog boxes typcally have the followng elements: Highlight ...Indicates the selected menu or item. Solid triangle ...Indicates further choices are available. A highlighted triangle indicates the item is active. Tab ...Indicates a group of features in a dialog box.

  • Page 59: ➌ List Of Menu Items

    ➌ List of Menu Items Some menu items are not available depending on the input source. Menu Item COMPUTER VIDEO SOURCE S-VIDEO VIEWER (NP62/NP52) PRESET BASIC CONTRAST BRIGHTNESS SHARPNESS COLOR ADJUST VOLUME RESET CLOCK PHASE HORIZONTAL VERTICAL IMAGE ASPECT RATIO OPTIONS CINEMA POSITION NOISE REDUCTION TELECINE AUTO KEYSTONE KEYSTONE KEYSTONE SAVE WALL COLOR GENERAL LAMP MODE LANGUAGE ORIENTATION CONTROL PANEL LOCK SETUP SECURITY MENU COLOR SELECT...
  • Page 60 OFF TIMER STANDBY MODE AUTO POWER ON (AC) OPTIONS SETUP AUTO POWER ON (COMP.) AUTO POWER OFF DEFAULT SOURCE SELECT LAMP LIFE REMAINING USAGE TIME LAMP HOURS USED HORIZONTAL FREQUENCY VERTICAL FREQUENCY SIGNAL TYPE VIDEO TYPE SOURCE SYNC TYPE INFO. SYNC POLARITY SCAN TYPE PRODUCT SERIAL NUMBER VERSION FIRMWARE DATA CONTROL ID CURRENT SIGNAL RESET ALL DATA CLEAR LAMP HOURS . Usng On-Screen Menu OFF/0:30/1:00/2:00/4:00/8:00/12:00/16:00 NORMAL NORMAL, POWER-SAVING OFF, ON OFF, ON OFF/0:05/0:10/0:20/0:30 LAST, AUTO, COMPUTER, VIDEO, S-VIDEO, LAST...

  • Page 61: ➍ Menu Descriptions & Functions [Source]

    　 COMPUTER Selects the computer connected to your COMPUTER input connector. NOTE: • When the component input signal is connected to the COMPUTER IN connector, select [COMPUTER]. • The projector will determine if the input signal is RGB or component signal. VIDEO Selects what is connected to your VIDEO input-VCR, DVD player or document camera. S-VIDEO Selects what is connected to your S-VIDEO input-VCR or DVD player. NOTE: A frame may freeze for a brief period of time when a video is played back in fast-forward or fast-rewind with a Video or S-Video source.

  • Page 62: ➎ Menu Descriptions & Functions [Adjust]

    ➎ Menu Descriptions & Functions [ADJUST] [BASIC] [PRESET] This function allows you to select optimized settings for your projected image. You can adjust neutral tint for yellow, cyan or magenta. There are six factory presets optimized for various types of images. You can also use [DETAIL SETTINGS] to set user adjustable settings to customize each gamma or color. Your settings can be stored in [PRESET 1] to [PRESET 6]. HIGH-BRIGHT ... Recommended for use in a brightly lit room. PRESENTATION ... Recommended for making a presentation using a PowerPoint file. VIDEO ... Recommended for typical TV program viewing. MOVIE ...

  • Page 63: Detail Settings

    [DETAIL SETTINGS] Storng Your Customzed Settngs [REFERENCE] This function allows you to store your customized settings in [PRESET 1] to [PRESET 6]. First, select a base preset mode from [REFERENCE] , then set [GAMMA CORRECTION], [COLOR TEMPERA- TURE], and [BrilliantColor]. HIGH-BRIGHT ... Recommended for use in a brightly lit room. PRESENTATION ... Recommended for making a presentation using a PowerPoint file. VIDEO ... Recommended for typical TV program viewing. MOVIE ... Recommended for movies. GRAPHIC ...
  • Page 64 CONTRAST Computer (RGB) Component Video, S-Video Viewer (NP62/NP52) Yes=Adjustable, No=Not adjustable, Yes* = depending on the signal [VOLUME] Adjusts the volume of the projector speaker. NOTE: • The volume level is set to "16" at the factory. • Volume can be also adjusted by using the VOLUME (+/-) button on the remote control. [RESET] The adjustments for [CONTRAST], [BRIGHTNESS], [SHARPNESS], [COLOR], [HUE], and [VOLUME] will be re- turned to the factory setting values. BRIGHTNESS SHARPNESS .

  • Page 65: [Image Options]

    [IMAGE OPTIONS] Adjustng Clock and Phase [CLOCK/PHASE] This allows you to manually adjust CLOCK and PHASE. CLOCK ... Use this item to fine tune the computer image or to remove any vertical banding that might appear. This function adjusts the clock frequencies that eliminate the horizontal banding in the image. This adjustment may be necessary when you connect your computer for the first time.
  • Page 66 Adjustng Horzontal/Vertcal Poston [HORIZONTAL/VERTICAL] Adjusts the image location horizontally and vertically. - An image can be distorted during the adjustment of [CLOCK] and [PHASE]. This is not malfunction. - The adjustments for [CLOCK], [PHASE], [HORIZONTAL], and [VERTICAL] will be stored in memory for the current signal. The next time you project the signal with the same resolution, horizontal and vertical frequen- cy, its adjustments will be called up and applied. To delete adjustments stored in memory, from the menu, you select [RESET] → [CURRENT SIGNAL] or [ALL DATA] and reset the adjustments. (→ page 70) . Usng On-Screen Menu...
  • Page 67 NOTE: When a non- RGB is selected, you cannot select [NATIVE]. NOTE: When you are displaying an RGB image with a higher resolution than the projector's native resolution such as SXGA, the image will be displayed in the projector’s native resolution (XGA) even if [NATIVE] is selected.
  • Page 68 When [CINEMA] is selected in [ASPECT RATIO], the image is displayed with black borders on the top and bottom. You can adjust the vertical position from the top to the bottom of the black area. Turnng on Nose Reducton [NOISE REDUCTION] This function allows you to select the level of noise reduction. The projector is set to the optimized level for each signal at the factory. Select your preference item for your signal when video noise is noticeable. The options are [OFF], [LOW], [MEDIUM], and [HIGH]. NOTE: This feature is not available for the RGB signal. Noise reduction set to off gives best image quality by way of higher band- width. Noise reduction set to on softens the image.

  • Page 69: ➏ Menu Descriptions & Functions [Setup]

    ➏ Menu Descriptions & Functions [SETUP] [GENERAL] Enablng Auto Keystone [AUTO KEYSTONE] This feature allows the projector to detect its tilt and correct vertical distortion automatically. To turn on the AUTO KEYSTONE feature, select [ON]. To adjust the KEYSTONE feature manually, select [OFF]. Correctng Vertcal Keystone Dstorton Manually [KEYSTONE] You can correct vertical distortion manually. (→ page 25) TIP: When this option is highlighted, pressing the ENTER button will display its slide bar for adjustment. Savng Vertcal Keystone Correcton [KEYSTONE SAVE] This option enables you to save your current keystone settings.
  • Page 70 The projector will return to the [NORMAL] once a signal is accepted. • If the projector is overheated in [NORMAL] mode because of use in a high-temperature room , there may be a case where the [LAMP MODE] automatically changes to [ECO] mode to protect the projector. This mode is called "forced ECO mode". When the projector is in [ECO] mode, the picture brightness decreases.

  • Page 71: [Installation]

    NOTE: • This CONTROL PANEL LOCK does not affect the remote control functions. • When the control panel is locked, pressing and holding the EXIT button on the projector cabinet for about 10 seconds will change the setting to [OFF].
  • Page 72 . Usng On-Screen Menu Selectng Menu Color [MENU COLOR SELECT] You can choose between two options for menu color: COLOR and MONOCHROME. Selectng Menu Dsplay Tme [MENU DISPLAY TIME] This option allows you to select how long the projector waits after the last touch of a button to turn off the menu. The preset choices are [MANUAL], [AUTO 5 SEC], [AUTO 15 SEC], and [AUTO 45 SEC]. The [AUTO 45 SEC] is the factory preset. Selectng a Color or Logo for Background [BACKGROUND] Use this feature to display a blue/black screen or logo when no signal is available. The default background is [LOGO].
  • Page 73 Optional remote control NP01RC does not have the CONTROL ID function and therefore cannot operate the projector once a Control ID is set. • Pressing and holding the ENTER button on the projector cabinet for 10 seconds will display the menu for canceling the Con- trol ID.

  • Page 74: [Options(1)]

    • Using the projector at altitudes approximately 5000 feet/1500 meters or higher without setting to [HIGH ALTITUDE] can cause the projector to overheat and the protector could shut down. If this happens, wait a couple minutes and turn on the projector.

  • Page 75: [Options(2)]

    • To cancel the preset time, set [OFF] for the preset time or turn off the power. • When the remaining time reaches 3 minutes before the projector is turned off, the [THE PROJECTOR WILL TURN OFF WITHIN 3 MINUTES] message will be displayed on the bottom of the screen.
  • Page 76 To use this function, first connect a computer to the projector and the projector to an active AC input. NOTE: • Disconnecting an RGB signal from the computer will not power off the projector. We recommend using this function in com- bination of the AUTO POWER OFF function. • This function will not be available under the following conditions:...

  • Page 77: ➐ Menu Descriptions & Functions [Info.]

    TIP: Pressing the HELP button on the remote control will show the INFORMATION menu items. [USAGE TIME] [LAMP LIFE REMAINING] (%)* [LAMP HOURS USED] (H) * The progress indicator shows the percentage of remaining bulb life. The value informs you of the amount of lamp usage. When the remaining lamp time reaches 0, the LAMP LIFE REMAINING bar indicator changes from 0% to 100 Hours and starts counting down. If the remaining lamp time reaches 0 hours, the projector will not turn on regardless of whether the LAMP MODE is set to NORMAL or ECO. • The message to the effect that the lamp should be replaced will be displayed for one minute when the projec- tor is turned on and when the POWER button on the projector or the remote control is pressed. To dismiss this message, press any button on the projector or the remote control. Product NP62/NP61...

  • Page 78: [Source]

    [SOURCE] [HORIZONTAL FREQUENCY] [SIGNAL TYPE] [SYNC TYPE] [SCAN TYPE] [VERSION] [PRODUCT] [SERIAL NUMBER] [FIRMWARE] Version [DATA] Version [CONTROL ID] (optional) [VERTICAL FREQUENCY] [VIDEO TYPE] [SYNC POLARITY] . Usng On-Screen Menu...

  • Page 79: ➑ Menu Descriptions & Functions [Reset]

    NOTE: Elapsed time of the lamp use will not be affected even when [RESET] is done from the menu. NOTE: The projector will turn off and go into standby mode when you continue to use the projector for another 100 hours after the lamp has reached the end of its life.

  • Page 80: Maintenance

    Cleanng the focus sensor Use a blower or lens paper to clean the focus sensor. Keep finger prints off the focus sensor. Leaving finger prints in the focus sensor might cause poor focus or short auto focus range. ➋ Cleaning the Cabinet 1. turn off the projector before cleaning. 2. Vacuum the ventilation inlet of the cabinet. CAUTION: When cleaning the speaker us- ing a vacuum cleaner, do not force the brush of the vacuum cleaner into the slits of the cabi- net.

  • Page 81: ➌ Replacing The Lamp And The Cooling Pump

    • Replacement lamp with cooling pump: NP09LP (NP62/NP61) or NP08LP (NP52/NP41) • Phillips screwdriver or equivalent 1. Place the projector on a soft cloth and turn it over to access the lamp cover on the bottom. 2. loosen the lamp cover screw until the screwdriver goes into a freewheeling condition and remove the lamp cover.
  • Page 82 • If the used packing ring is stuck inside the projector (Fig. B), remove it from inside the projector before install- ing the new lamp housing. To remove the packing ring, simply pull it off of the stud. * In other cases where the lamp is removed (other than lamp replacement), pulling out the lamp housing may also cause the packing ring to stay stuck inside the projector. If this happens, make sure to insert the lamp housing back in its original position. CAUTION • Before removing the used packing ring, be sure to turn off the projector, wait for the cooling fan to stop, dis- connect the power cable, and allow at least one hour for the lamp to cool. The projector can become very hot when it is turned on and stay hot immediately after it is turned off. • Do not install a new lamp with the used packing ring stuck inside the projector as it requires excessive force to install the new lamp which then may cause damage to the projector. Fig. B Fig. C 7. Mantenance...
  • Page 83 4. Push the part as shown on the drawing and insert a new lamp housing until it is plugged into the socket. CAUTION Do not use a lamp other than the NEC replacement lamp NP09LP (NP62/NP61) or NP08LP (NP52/NP41). Order this from your NEC dealer. secure it in place with the two screws. NOTE: Tighten the two screws alternately until both screws are completely tightened. Failure to do this can result in air leak from the cooling pump, causing the pump error.
  • Page 84 9. finally, select the menu → [reset] → [Clear laMP hOUrs] to reset the lamp usage hours. NOTE: When the lamp exceeds 2600 hours (up to 3600 hours in ECO mode) of service, the projector cannot turn on and the menu is not displayed.

  • Page 85: Appendix

    Normal Lamp has reached its end of life. Lamp replacement message will be displayed. Lamp has been used beyond its limit. The projector will not turn on until the lamp is replaced. Lamp mode is set to ECO mode. Note –...
  • Page 86 • Check to see if you continue to use the projector for another 100 hours after the lamp has reached the end of its life. If so, replace the lamp.
  • Page 87 In most cases the output signal from the notebook PC is not turned on unless connected to the projector be- fore being powered up. NOTE: You can check the horizontal frequency of the current signal in the projector’s menu under Information. If it reads “0kHz”, this means there is no signal being output from the computer. See page • Enabling the computer’s external display. Displaying an image on the notebook PC’s screen does not necessarily mean it outputs a signal to the projec- tor. When using a PC compatible laptop, a combination of function keys will enable/disable the external dis-...

  • Page 88: ➋ Specifications

    NP62/NP62G: 300W in Lamp NORMAL mode, 235W in Lamp ECO mode, 5W in STANDBY MODE (POWER-SAVING) NP61/NP61G: 285W in Lamp NORMAL mode, 225W in Lamp ECO mode, 5W in STANDBY MODE (POWER-SAVING) NP52G: 275W in Lamp NORMAL mode, 235W in Lamp ECO mode, 5W in STANDBY MODE (POWER-SAVING) NP41/NP41G: 265W in Lamp NORMAL mode, 225W in Lamp ECO mode, 5W in STANDBY MODE (POWER-SAVING) 8. Appendx...
  • Page 89 For Unted States: UL Approved (UL 60950-1) Meets FCC Class B requirements For Canada: UL Approved (CSA 60950-1) Meets DOC Canada Class B requirements For Australa/New Zealand: Meets AS/NZS CISPR.22 Class B For Europe: Meets EMC Directive (EN55022, EN55024, EN61000-3-2, EN61000-3-3) Meets Low Voltage Directive (EN60950-1, TÜV GS Approved) For additional information visit: US : http://www.necdisplay.com Europe : http://www.nec-display-solutions.com Global : http://www.nec-pj.com/ For information on our optional accessories, visit our website or see our brochure. The specifications are subject to change without notice. Orientation: Desktop/Front, Desktop/Rear, Ceiling/Front, Ceiling/Rear 9.7" (W) x 2.8" (H) x 7.0" (D) 246 mm (W) x 72 mm (H) x 177 mm (D) (not including protrusions) NP62/NP52: 3.75 lbs / 1.7 kg NP61/NP41: 3.5 lbs / 1.6 kg Operational Temperatures: 41°F to 104°F / 5°C to 40°C (ECO mode selected automatically at 95°F to 104°F/35°C to 40°C / ECO mode select- ed automatically at 86°F to 104°F/30°C to 40°C when used in HIGH ALTITUDE) 20% to 80% humidity (non-condensing) Storage Temperatures: 14°F to 122°F (-10°C to 50°C), 20% to 80% humidity (non- condensing) 8.

  • Page 90: ➌ Cabinet Dimensions

    ➌ Cabinet Dimensions 79 (3.1") Lens center CONTROL AUDIO CONTROL AUDIO NP62/NP52 ON/STAND FOCUS ADJ. POWER SOURCE SELECT AUTO STATUS LAMP 246 (9.7") 73 (2.9") Lens center 8. Appendx S-VIDEO VIDEO COMPUTER S-VIDEO VIDEO COMPUTER Unit: mm (inch)

  • Page 91: ➍ Pin Assignments Of D-Sub Computer Input Connector

    ➍ Pin Assignments of D-Sub COMPUTER Input Connector Mn D-Sub  Pn Connector Signal Level Video signal : 0.7Vp-p (Analog) Sync signal : TTL level Pin No. RGB Signal (Analog) Green or Sync on Green Blue Ground Ground Red Ground Green Ground Blue Ground No Connection Sync Signal Ground No Connection Bi-directional DATA (SDA) Horizontal Sync or Composite Sync Vertical Sync Data Clock 8. Appendx YCbCr Signal Cr Ground Y Ground Cb Ground...

  • Page 92: ➎ Compatible Input Signal List

    ➎ Compatible Input Signal List Horizontal: 15 kHz to 100 kHz (RGB: 24 kHz or over) Vertical: 50 Hz to 85 Hz Signal Resolution ( Dots ) NTSC – PAL – PAL60 – SECAM – VESA 640 × 480 IBM 640 × 480 MAC 640 × 480 VESA 640 × 480 VESA 640 × 480 VESA 640 × 480 VESA 800 × 600 VESA...

  • Page 93: ➏ Pc Control Codes And Cable Connection

    NOTE: Depending on the equipment, a lower baud rate may be recommended for long cable runs. PC Control Connector (DIN-8P) To TxD of PC To RxD of PC NOTE : Pins 2, 3, 5, 6 and 8 are used inside the projector. Code Data To GND of PC 8. Appendx...

  • Page 94: ➐ Troubleshooting Check List

    Video and Audio No image is displayed from your PC or video equipment to the projector. Still no image even though you connect the projector to the PC first, then start the PC. Enabling your notebook PC’s signal output to the projector.
  • Page 95  Sync on Green STATUS Indicator: Steady light  Orange  Green Flashing light Remote control model number: Projector Sgnal cable NEC standard or other manufacturer’s cable? Model number: Length: Distribution amplifier Model number: Switcher Model number: Adapter Model number:...

  • Page 96: ➑ Travelcare Guide

    Services offered with TravelCare This warranty allows customers to receive service on their product at the NEC and NEC-designated service stations in the countries listed herein when temporarily traveling internationally for business or plea- sure.
  • Page 97 +65 6 274 2226 Email Address: ncare@nec.com.sg WEB Address: http://www.nec.com.sg/ap (Regions Covered) Singapore NEC Corporation of Malaysia Sdn. Bhd. Address: 33rd Floor, Menara TA One, 22, Jalan P. Ramlee, 50250 Kuala Lumpur, Malaysia Telephone: +6 03 2178 3600 (ISDN) Fax Line:...
  • Page 98 Date: TO: NEC or NEC’s Authorized Service Station: (Company & Name with signature) Dear Sir (s), I would like to apply your TravelCare Service Program based on attached registration and qualification sheet and agree with your following conditions, and also the Service fee will be charged to my credit card account, if I don’t return the Loan units within the specified period.
  • Page 99 10 days to the customer, excluding transport time. There may have a case, repair and return can’t be done by NEC Authorized Service Station, because of shortage of spare parts due to same model is not sold in the territory.
  • Page 100 © NEC Display Solutions, Ltd. 2008 7N951221...
