- Page 1 LCD1280 10/29/99 9:25 AM Page 1 60191-1094 Illinois Dale, Wood U.S.A. Printed Drive Michael 1255 Part Inc. Technologies, Monitor Color True 13" 13" True Color TFT LCD Monitor User’s Manual...
-
Page 2: Table Of Contents
Rear Controls LCD1280, ErgoDesign, IPM, Reduced Magnetic Field, and FastFacts are trademarks of NEC Technologies, Inc. NEC is a registered trademark of NEC Corporation. Copyright ©1995 by NEC Technologies, Inc. All other brand or product names are trademarks or registered trademarks of their respective holders. -
Page 3: Introduction
Because the LCD1280 accepts an analog input, a graphics card with digital output is not required. The same graph- ics board can be used to drive the LCD1280 or a standard CRT monitor. The analog interface also provides the LCD with its true-color capability. -
Page 4: Low Power Consumption
The LCD1280 has been designed with NEC’s IPM™ (Intelligent Power Manager) System. When utilized with an Energy Star system or video card, the LCD1280's IPM System is an innova- tive power saving utility that complies with both the EPA’s Energy Star requirements and Europe’s NUTEK’s power man- agement requirements. -
Page 5: Installation
Connection to Graphics Cards using BNC cables The NEC LCD1280 color monitor complements a host of computing platforms. However, because the LCD1280 is a high resolution, full color analog monitor, it may require... -
Page 6: Controls
(Vertical Sync), connect it to the BNC connector on the moni- tor labeled VS. Please see Appendix 1 for pin assignments. 7. Connect one end of the power cable to the LCD1280 monitor and the other end to the power outlet. -
Page 7: Troubleshooting/Support
LCD1280 10/29/99 9:25 AM Page 7 Fine VGA Horizontal Adjust (V-H2): fine adjustment for horizontal position of VGA mode (2 pixel / 1 dot increment per operation). Rough VGA Vertical Adjust (V-V1): vertical position of VGA mode (32 pixel / 16 line increment per operation). -
Page 8: Technical Support
• Know the name of the graphics card you are using, and have its manual nearby. • If it is more convenient to fax a question to NEC’s Technical Support, the fax number is (508) 635-4666. The BBS e NEC Remote Bulletin Board System (BBS) is a great way to keep in touch with NEC. -
Page 9: Appendix 1
Consumers are cautioned that Product performance is affected by system configuration, software, the application, customer data, and operator control of the system, among other factors. While NEC TECHNOLOGIES, INC. Products are considered to be compatible with many systems, the specific functional implementation by the customers of the Product may vary. -
Page 10: Appendix 2
LCD1280 10/29/99 9:25 AM Page 10 Signal Timings Input Signal Timings (WS High Resolution Mode) Item Abbreviation Pixel frequency Horizontal frequency Line Time total Horizontal active display Horizontal sync pulse Horizontal baack porch Horizontal front porch Thrf H-sync Rise & Fall... -
Page 11: Appendix 2
LCD1280 10/29/99 9:25 AM Page 11 H-Video Horizontal Fig. A2-1: Horizontal Timing Signal levels Video Swing (White – Blank: W/O Sync process) Setup level (Black – Blank) White level (White – Black) Video input offset (V White Level Video swing Setup Fig. -
