CAUTION: Repair the machine in accordance with "Instruction manual" or "Safety instructions".
Note: Some parts numbers and descriptions differ from model to model. Refer to the following list and replace the
descriptions in this technical information. (for example, Cam C/ A means Cam C or Cam A.)
Item No.
Description
1
Plate
23
Spindle M/ N
29
Ring 38
36
Compression spring 19
39
Cam C/ A
54
Armature
Clutch ass'y (as an option
43
for quick repair of Clutch
section) consists of Item Nos.
32 33 43 34 35 36 37
38 39 40 41 42 62
[1] NECESSARY REPAIR TOOLS
Code No.
1R004
Retaining ring S pliers ST-2
1R035
Bearing setting plate 15.2
1R036
Bearing setting plate 17.2
1R145
L type Torx wrench set
1R219
Torx wrench shaft 7-23N.m
1R220
Ratchet head 9.5 (1R219)
1R222
Socket adapter (1R219)
1R237
Round bar for arbor 8-100
1R269
Bearing extractor
Screwdriver magnetizer
1R288
1R291
Retaining ring S and R pliers
1R311
Retaining ring pliers with long bent nails
1R314
Torx bit VT-25
Torque adjust tool
765027-4
Model No.
BFT043F
Plate G
Either Spiindle M or Spindle N is used. It differs from country to country.
Ring 38G
Compression spring 19D Compression spring 19E Compression spring 19C
Clutch ass'y D
Description
BFT083F
Ring 38H
Cam C
Part No.619265-9
Clutch ass'y F
removing/installing Ring spring 11
installing Ball bearing 6801LLB and Ring 12
assembling Spindle section to Clutch case
removing M5x10 Torx countersunk head screw from Spindle
tightening M5x10 Torx countersunk head screw to Spindle
assembling Spindle section to Clutch case
removing Ball bearing 6801LLB and Ring 12 from Spindle
removing Steel balls
removing/installing Ring spring 10 from/on Spindle M/ N
removing Retaining ring R-21
assembling M5x10 Torx countersunk head screw to Spindle
disassembling Clutch section
BFT125F
Plate H
Cam A
Part No.619267-5
Clutch ass'y G
Use for
P 2/ 14
Plate I
Ring 38I
