NDC comm NWA0518 Specifications

High Gain Panel Directional Antenna
for 5.2 / 5.6 / 5.8 GHz
Electrical Specification
Frequency range
Gain
VSWR
Polarization
HPBW / horizontal
HPBW / vertical
Front to back ratio
Power handling
Impedance
Connector
Environmental & Mechanical Characteristics
Survival wind speed
Temperature - 40
Humidity
Radome color Gray-white
Radome material ABS, UV resistant
Weight
Dimensions 215 x 200 x 48.5 mm
5.25 GHz - 5.875 GHz
18 dBi
2.0 : 1 Max.
Linear, vertical
o
18
o
18
25 dB
10W (cw)
50 ohms
N jack
216 km/hr
o o
C to +80 C
o
C
95% @ 25
0.825 kg
