NI PCI-8254R Quick Start Guide

What You Need to Get Started

The NI PCI-8254R is an IEEE 1394a interface device for PCI with
reconfigurable I/O (RIO). The following sections describe how to install
and configure the NI 8254R.
You need the following items to set up and use the NI 8254R:
❑
NI Vision Acquisition Software 8.0 or later
❑
NI Vision Acquisition Software Release Notes
❑
Computer running Windows 2000/XP with at least one PCI slot
❑
IEEE 1394 camera
❑
IEEE 1394a cable
❑
Cable for digital I/O
❑
External power supply to support powering isolated outputs
❑
Optional software packages and documentation:
–
NI Vision for LabVIEW, LabWindows
Studio (Visual Basic)
–
Vision Builder for Automated Inspection
–
LabVIEW
–
LabVIEW FPGA Module
–
LabWindows/CVI
–
Measurement Studio
™
™
/CVI
, or Measurement

Advertisement

Table of Contents
loading

Related Manuals for National Instruments Interface Device NI PCI-8254R

Summary of Contents for National Instruments Interface Device NI PCI-8254R

  • Page 1: What You Need To Get Started

    NI PCI-8254R Quick Start Guide The NI PCI-8254R is an IEEE 1394a interface device for PCI with reconfigurable I/O (RIO). The following sections describe how to install and configure the NI 8254R. What You Need to Get Started You need the following items to set up and use the NI 8254R: ❑...

  • Page 2: Optional Equipment

    Optional Equipment National Instruments offers a variety of products for use with the NI 8254R, including the following: • • • • • • • • For specific information about these products, refer to the National Instruments catalog, visit Instruments office nearest you.
  • Page 3 Remove power from signal lines before connection to or disconnection from the device. Caution National Instruments measurement products may be classified as either Measurement Category I or II. Operate products at or below the Measurement Category level specified in the hardware specifications.
  • Page 4 occur in electrical distribution systems. The following is a description of Measurement (Installation • • • • Unpacking The NI 8254R ships in an antistatic package to prevent electrostatic discharge from damaging device components. To avoid such damage in handling the device, take the following precautions: •...

  • Page 5: Installation

    Remove the device from the package and inspect it for loose components or any other signs of damage. Notify National Instruments if the device appears damaged in any way. Do not install a damaged device in the computer. Store the NI 8254R in the antistatic package when not in use.
  • Page 6 10. Connect the IEEE 1394a cable to your camera. Refer to your camera 11. Connect the IEEE 1394a cable to an IEEE 1394a connector on the 12. Plug in and power on the computer. The NI 8254R is now installed and your camera is connected. Refer to Figure 1 for information about placement of the connectors on the NI 8254R.
  • Page 7 2 V Position 1 2-Position Isolated Outputs Power Connector 2 C Position © National Instruments Corporation If you are using the NI desktop power supply, remove the 4-position power connector connected to the power supply, shown in Figure 2. Reconnect the wire that was connected to the V position on the 4-position power connector to the V position on the 2-position isolated outputs power connector, shown in Figure 3.
  • Page 8 1 Power Supply Output Cable 2 Ferrite 1 Power Supply Output Cable 2 Ferrite NI PCI-8254R Quick Start Guide (Optional) To suppress electromagnetic interference, install a ferrite on the power supply cable as close to the connection to the NI 8254R as possible.
  • Page 9 Phoenix Contact (part number 3200519). 1 2-Position Power Connector Figure 7. Wiring a Third-Party Power Supply to the 2-Position Power Connector © National Instruments Corporation 3 NI Desktop Power Supply 4 Power Supply Cord (to Outlet) Figure 6. Wiring Power to the NI 8254R...

  • Page 10: Related Documentation

    After you have installed the NI 8254R and powered on your computer, Windows will recognize the device and assign resources to it. Use Measurement & Automation Explorer (MAX), the National Instruments configuration utility, to configure the IEEE 1394 camera connected to the NI 8254R for acquisition.

  • Page 11: Specifications

    Do not draw more than 500 mA combined from the V from 30 V isolated outputs. Do not draw more than 50 mA from 5 V isolated outputs. © National Instruments Corporation ... 18 W, maximum (shared by both ports) ...

  • Page 12: Ieee 1394

    Maximum pulse rate ...2 MHz Optically Isolated Inputs and Outputs Isolated (Current Sinking) Inputs Number of channels...13 Input voltage range ...0 V to 30 V Turn-on current...7.1 mA, typical Maximum pulse rate ...100 kHz Minimum pulse detected ...10 μs Reverse polarity protection...Yes, –30 V Isolated (Current Sourcing) Outputs Number of channels...4 On-state voltage range ...5 V to 30 V, maximum...

  • Page 13: Physical Characteristics

    For UL and other safety considerations, refer to the product label, or visit Note ni.com/certification appropriate link in the Certification column. © National Instruments Corporation IEC 61010-1, EN 61010-1 UL 61010-1, CSA 61010-1 , search by model number or product line, and click the (4.2 in.

  • Page 14: Electromagnetic Compatibility

    Waste Electrical and Electronic Equipment (WEEE) EU Customers At the end of their life cycle, all products must be sent to a WEEE recycling center. For more information about WEEE recycling centers and National Instruments WEEE initiatives, visit NI PCI-8254R Quick Start Guide EN 61326 EMC requirements;...

  • Page 15: Where To Go For Support

    Where to Go for Support The National Instruments Web site is your complete resource for technical support. At troubleshooting and application development self-help resources to email and phone assistance from NI Application Engineers. A Declaration of Conformity (DoC) is our claim of compliance with the Council of the European Communities using the manufacturer’s...
  • Page 16 Instruments trademarks. Other product and company names mentioned herein are trademarks or trade names of their respective companies. For patents covering National Instruments products, refer to the appropriate location: Help»Patents in your software, the patents.txt file on your CD, or ni.com/patents.
