product introduction

FEATURES
This product is a fi ngerprint recognition reader that is compatible with the proximity reader. This product can be
synchronized with the controller, and is featured by reliable fi ngerprint recognition, all of which enables you to perform a
high level management of security and time and attendance. Integrated with the proximity reader and the fi ngerprint
recognition functions, this product will allow access to a user only if the card number matches the fi ngerprint of the user.
Easily installed on a doorframe or a fl at wall (simply replace the existing reader, if any), this product gives you high
satisfaction apart from the elegant looking appearance. The product's reliable fi ngerprint recognition will keep you safe
from unauthorized access.
Reader Mode
RF Only Mode
- As soon as the card is authenticated, the corresponding card ID will be transferred to the controller.
RF+FINGER Mode
- As soon as the fi ngerprint is authenticated, the corresponding card ID will be transferred to the controller.
- For a person whose fi ngerprint is not registered, the product will automatically switch to RF Only mode.
Error Signal Output
If the product fails to authenticate a fi ngerprint or unregistered card, it will produce an error signal for 500 ms.
(However, if set to the Wiegand output format) The output format is of the open collector.
Output Format of Card Number
When a fi ngerprint is authenticated, the corresponding card number will be transferred in 26bit/34bit Wiegand.
Master Card
Used to switch between registration/deletion mode and reader mode.
Switching Operation Mode by External Input
This product can switch between RF Only and RF +Finger, according to the input setting of the product's
system mode control line (gray with red stripes).
Card Number Input Format
The user ID read by the external reader or using the card or keypad will be transferred in 26bit Wiegand/34bit
Wiegand.
Englis_ English _ 5
