TCP/IP Communication Port Connection
To enable TCP/IP communications with the host PC, you must have connected the RJ45 jack to CON4 (8-PIN
connector). Please follow the steps below:
Hub
RJ45
RJ45
1. Connect the RJ45 jack of the product to the RJ45 plug of the network system.
2. Install and launch the application (SAMS).
RJ45 RJ45
Host PC
