Table Of Contents - Sanyo Vcc-4110P Instruction Manual

Depending on the conditions of use, installation and environment,
please be sure to make the appropriate settings and adjustments. If you
need help with installation and/or settings, please consult your dealer.
CONTENTS
PRECAUTIONS........................................................................................ 2
PARTS NAMES ....................................................................................... 3
CONCERNING AUTO-IRIS LENSES ........................................................ 5
MOUNTING THE LENS........................................................................... 6
CONNECTIONS....................................................................................... 8
SETTINGS................................................................................................ 9
TROUBLESHOOTING .............................................................................13
SPECIFICATIONS ....................................................................................14
ACCESSORIES
1
Clamping core A .......................................................................1 pc.
2
Clamping core B........................................................................1 pc.
1
1
English
2
FEATURES
• Built-in interline transfer method 1/4" CCD, approx. 320,000
picture elements
• Equipped with a DSP (Digital Signal Processor) function
• Horizontal resolution, more than 350 TV lines
• High sensitivity, minimum required illumination is 0.3 lux
(Gain up: HI position, F1.2)
• Two types of backlight compensation functions (multi-spot
photometry and center focus photometry)
• Low smear, anti-blooming, low lag, no burning and no geometric
distortion using the CCD solid state image device.
• 100% solid state components giving excellent immunity to shock
and vibration
• Not subject to interference from magnetic or electrostatic fields
• Power supply: 220 - 230 V AC operation
