Millivolt system vented gas fireplace natural and propane gas model
Hide thumbs Also See for BGNV42N:
Table of Contents

Advertisement

Quick Links

Download this manual
CERTIFIED UNDER CANADIAN AND AMERICAN NATIONAL STANDARDS, CSA 2.22, AND ANSI Z21.50 RESPECTIVELY FOR VENTED GAS FIREPLACES.
WARNING: If the information in these instructions is not followed exactly, a fire or
explosion may result causing property damage, personal injury or death.
Do not store or use gasoline or other flammable vapours and liquids in the vicinity
• Do not try to light any appliance.
• Do not touch any electrical switch.
• Do not use any phone in your building.
Installation and service must be performed by a qualified installer, service agency or
the gas supplier.
R-2000

MILLIVOLT SYSTEM

INSTALLATION AND OPERATION INSTRUCTIONS FOR
VENTED GAS FIREPLACE
NATURAL GAS MODEL
PROPANE GAS MODEL
CERTIFIED FOR CANADA AND UNITED STATES USING ANSI / CSA METHODS
FOR YOUR SAFETY
of this or any other appliance.
WHAT TO DO IF YOU SMELL GAS:
BGNV42N
BGNV42P
• Immediately call your gas supplier from
a neighbour's phone. Follow the gas
supplier's instructions.
•If you cannot reach your gas supplier,
call the fire department.
1
W415-0377 / C / 09.23.05
