O W N E R ' S M A N U A L
ENSEMBLE PA 4180
Portable Stereo Sound System

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 4180 and is the answer not in the manual?

Questions and answers

Related Manuals for Nady Audio 4180

Summary of Contents for Nady Audio 4180

  • Page 1 O W N E R ’ S M A N U A L ENSEMBLE PA 4180 Portable Stereo Sound System...

  • Page 2: Table Of Contents

    1) INSPECTION ... 4 2) SETUP ... 4 FRONT PANEL CONTROLS & CONNECTIONS ... 5 REAR PANEL CONTROLS & CONNECTIONS ... 7 SPECIFICATIONS ... 7 ENSEMBLE PA 4180 Portable Stereo Sound System FEATURES TABLE OF CONTENTS Date of Purchase ____________________________________ Dealer’s Name ______________________________________...

  • Page 3: Warning

    ATTENTION RISQUE DE CHOC ELECTRIQUE NE PAS OUVRIR IMPORTANT SAFETY INSTRUCTIONS When using this electronic device, basic precautions should always be taken, including the following: Read all instructions before using the product. Do not use this product near water (e.g., near a bathtub, washbowl, kitchen sink, in a wet basement, or near a swimming pool, etc.).

  • Page 4: Installation

    Lift off the mixer section in the same manner. Position the PA-4180 mixer section on a flat surface with the control panel facing front. Parts of the unit can become very warm during use. This is normal during operation.

  • Page 5: Front Panel Controls & Connections

    FRONT PANEL CONTROLS & CONNECTIONS FRONT PANEL Note: 1 through 9 below are referenced to Channel 1. The other 3 Channels are identical. (1) GAIN CONTROL The channel gain controls determine the signal level input to each channel. (2) HIGH EQ Turn this control to the right to boost high frequencies on the channel, adding...
  • Page 6 (21) EFFECT LOOP RETURN This input can be used to return the effected signal into the PA-4180 or it can be used as a auxiliary input. The input signal can be adjusted by the Master Volume and the unit the return jack is connected to.

  • Page 7: Rear Panel Controls & Connections

    (25) VOLTAGE cabinets. The connected speaker impedance must be 4 SELECTOR SWITCH ohms or greater. The PA-4180 delivers 90W RMS of power For selecting the @ 4 Ohms per each speaker output. proper voltage (115/...
  • Page 8 DO NOT ATTEMPT TO SERVICE THIS UNIT YOURSELF AS IT CAN BE DANGEROUS AND WILL ALSO VOID THE WARRANTY. NADY SYSTEMS, INC. • 6701 SHELLMOUND STREET, EMERYVILLE, CA 94608 Tel: 510.652.2411 • Fax: 510.652.5075 • www.nady.com...
