Summary of Contents for Nady Audio SRA 2150
-
Page 2: Table Of Contents
SRA SERIES Professional Power Amplifiers Contents Features ... 1 Warning ... 2 Controls and Connections ... 3, 4 Typical Set-up ... 5 Specifications ... 6... -
Page 3: Warning
INSTRUCTIONS PER TAINING TO A RISK OF FIRE, ELECTRIC SHOCK, OR INJUR Y TO PERSONS. IMPOR TANT SAFETY INSTRUCTIONS SA VE THESE INSTRUCTIONS W ARNING – (For use in the U.S.A.) IMPOR TANT (For use in Europe) - Page 4 REAR PANEL FRONT PANEL POWER SWITCH: To turn the unit ON or OFF, press the upper or lower portion of this button. The LED in the switch will light to indicate that the unit is ON. CAUTION: Always turn on your power amplifier last, after all your other connected equipment, and always turn off your power amplifier before your other connected equipment.
-
Page 5: Controls And Connections
10. STEREO/BRIDGE SELECT SWITCH: This is used to select "STEREO" or "BRIDGE" mode operation. Before switching, verify that the output’s connection is correct. The connections should be as follows: STEREO MODE: MONO BRIDGED MODE: a. Mixer or EQ right channel line output to amplifier right channel line input b. -
Page 6: Typical Set-Up
STEREO SPEAKER STEREO Ground Unbalanced Balanced Input Input MONO BRIDGED MONO BRIDGED 2 SPEAKERS Ground Unbalanced Balanced Input Input 1 SPEAKER Ground Unbalanced Balanced Input Input Typical Set-up Speaker Output Channel 2 120V Impedance LINE OUT SPEAKER 1 Speaker Output Channel 2 120V Impedance... -
Page 7: Specifications
ONE 1/4” PHONE JACK & ONE PAIR BINDING POST SCREW TERMINALS FOR EACH CHANNEL SRA 2150: RMS 150W X 2 @ 4 OHMS / BRIDGED RMS 250W @ 8 OHMS SRA 2250: RMS 250W X 2 @ 4 OHMS / BRIDGED RMS 350W @ 8 OHMS... - Page 8 SERVICE FOR YOUR NADY AUDIO PRODUCT...
