Nady Audio TTV-2 Owner's Manual

Specifications

OUTPUT .................................. 1/4" jack (unbalanced)
OUTPUT LEVEL (max, nominal) ......... 0dBv / -10dBv
OUTPUT IMPEDANCE ................ 10K min - 70K max
INPUT ...................................... 1/4" jack (unbalanced)
INPUT LEVEL (max, nominal) ...... -30dBv / >+20dBv
INPUT IMPEDANCE ........................................... 1MΩ
AUDIO RESPONSE
(controls adjusted) ................ 50Hz-16kHz @ +/-3dB

General Notes

Although the TTV-2 is very ruggedly housed in heavy gauge steel, care should be taken in handling
the unit as the tube utilized is made from glass. Avoid physical abuse. The footswitch is all that is
needed to switch the unit.

Service for your Nady Audio Product

(U.S.) Should your NADY AUDIO product require service, please contact the Nady Service
Department via telephone at (510) 652-2411, or e-mail at service@nady.com.
(International) For service, please contact the NADY AUDIO distributor in your country
through the dealer from whom you purchased this product.
DO NOT ATTEMPT TO SERVICE THIS UNIT
YOURSELF AS IT CAN BE DANGEROUS AND
WILL ALSO VOID THE WARRANTY.
NADY SYSTEMS, INC. • 6701 SHELLMOUND STREET, EMERYVILLE, CA 94608
Tel: 510.652.2411 • Fax: 510.652.5075 • www.nady.com
THD .................................................................... 1.5%
S/N RATIO .......................................................... 85dB
NOISE FLOOR ................................................... 34uV
AC/AC ADAPTER ....................................... 95V-130V
Tube Type ............................................... (2x) 12AX7A
Dimensions ... 5.5" x 5.7" x 1.5" (14 x 14.5 x 3.75 cm)
Weight ................................................ 2.6 lbs (1.8 Kg)
OWNER'S MANUAL
Dual Tube Vibrato and
Tremolo Effects Pedal
TTV-2
