- Page 1 T524 ® DVD / CD / MP3 Player Owner’s Manual Manuel de l'utilisateur Bedienungsanleitung Gebruikershandleiding Manual del Usuario Manuale delle Istruzioni Manual do Proprietário Bruksanvisning...
-
Page 2: Introduction
89/336/EEC, 93/68/EEC and 73/23/EEC. NAD is a trademark of NAD Electronics International, a division of Lenbrook Industries Limited Copyright 2004, NAD Electronics International, a division of Lenbrook Industries Limited NOTES ON COPYRIGHT It is forbidden by law to copy, broadcast, show, broadcast via cable, play in public, or rent copyrighted material without permission. -
Page 3: Table Of Contents
Setting up the Player ........10 DVD Player Connections .......10 Audio Connection to Optional Equipment . -
Page 4: Before Use
To ensure proper use of this product, please read this owner’s manual carefully and retain for future reference. This manual provides information on the operation and maintenance of your DVD player. Should the unit require service, contact an authorized service location. SYMBOL USED IN THIS MANUAL... -
Page 5: Types Of Playable Discs
NOTES ON REGIONAL CODES • Most DVD discs have a globe with one or more numbers in it clearly visible on the cover. This number must match your DVD player’s regional code or the disc cannot play. • If you try to play a DVD with a different region code from your player, the message “Check Regional Code”... -
Page 6: Disc-Related Terms
DivX is the name of a revolutionary new video codec which is based on the new MPEG-4 compression standard for video. You will be able to play DivX movies using this DVD player. PBC: PLAYBACK CONTROL (VIDEO CD ONLY) Playback control is available for Video CD (VCD) version 2.0 disc formats. -
Page 7: Front Panel And Display Window
CD TRK FRONT PANEL AND DISPLAY WINDOW Disc Tray Insert a disc here. Display window Shows the current status Point the DVD Player remote control here. Indicates total playing time/elapsed time Introduction of the player Remote Sensor Indicates repeat mode... -
Page 8: Rear Panel
VIDEO OUT Connect to a TV with video inputs. 12V TRIGGER IN By connecting this DVD player to another NAD audio component or system controller equipped with a 12V trigger output, you can remotely operate the T524C power ON/OFF. COMPONENT/PROGRESSIVE SCAN VIDEO OUT Connect to a TV with Y Cb/Pb Cr/Pr inputs. -
Page 9: Remote Control
Switches DVD Player ON. AUDIO Selects an audio language (DVD). SUBTITLE Selects a subtitle language. ANGLE Selects a DVD camera angle if available REPEAT Repeat chapter, track, title, all. RPT A-B Repeat sequence. RANDOM Plays tracks in random order. MARKER Marks any point during playback. -
Page 10: Installation And Setup
(See “TV Output Select” on page 14.) Video and Audio Connections to Your TV Make sure the DVD player is connected directly to the TV and not to a VCR, otherwise the DVD image could be distorted by the copy protection system. -
Page 11: Audio Connection To Optional Equipment
Amplifier equipped with 2-channel analogue stereo or Dolby Pro Logic ll / Pro Logic Connect the left and right AUDIO OUT jacks on the DVD player to the audio left and right IN jacks on your amplifier, receiver, or stereo system, using the audio cables (A). -
Page 12: On-Screen Display
Installation and Setup BEFORE OPERATION ON-SCREEN DISPLAY You can display the general playback status on the TV screen. Some items can be changed using the menu. To use the on-screen display: 1 Press DISPLAY during playback. 2 Press to select an item. The selected item is highlighted. 3 Press to change the setting. -
Page 13: Initial Settings
INITIAL SETTINGS By using the Setup menu, you can make various adjustments to items such as picture and sound. You can also set a language for the subtitles and the Setup menu, among other things. For details on each Setup menu item, see pages 13 to 16. -
Page 14: Audio
NOTE If your TV does not accept the Progressive Scan format, the picture will appear scrambled if you try Progressive Scan on the DVD Player. 4 When the confirm menu appears on your screen Cancel is highlighted as default. Use the buttons to highlight Enter. -
Page 15: Others
You can set up the DVD Player so a DVD disc automatically starts playing whenever the DVD is inserted. If Auto Play mode is set to On, this DVD player will search for the title that has the longest playback time and then play back the title automatically. -
Page 16: Lock (Parental Control)
Installation and Setup BEFORE OPERATION LOCK (PARENTAL CONTROL) LOCK Rating Unlock Password Country Code Move RATING DVD-V Some movies contain scenes that may not be suitable for children to view. Many of these discs contain parental control information that applies to the complete disc or to certain scenes on the disc. Movies and scenes are rated from 1 to 8, depending on the country. -
Page 17: Operation
DVD player. 2 Turn on the audio system (if applicable) and select the input source connected to the DVD player. 3 Press OPEN/CLOSE to open the disc tray and load your chosen disc in the tray, with the playback side down. - Page 18 DVD-V DVD-A SLOW MOTION 1 Press PAUSE/STEP ( ) during playback. The DVD player will now go into PAUSE mode. 2 Use the SCAN ( ) to select the required speed: 1/8, 1/4, or...
-
Page 19: Special Dvd Features
ZOOM DVD-V DVD-A DivX Use zoom to enlarge the video image. 1 Press ZOOM during playback or still playback to activate the Zoom function. The square frame appears briefly in the right bottom of the picture. 2 Each press of the ZOOM button changes the TV screen in the sequence: 100% size ➜... -
Page 20: Dvd Audio Discs
To enjoy maximum sound quality and surround effect of DVD Audio, you must use 5.1 channel analogue audio output (5.1CH AUDIO OUT jacks on the DVD Player). If you use the DIGITAL OUT (OPTICAL or COAXIAL) for your audio connection, the sound will only be similar to CD-quality sound even though you’re playing a DVD Audio disc. -
Page 21: Operation With Audio Cd And Mp3 / Wma Disc
(see above) to ensure compatible playback. Customers should note that permission is required in order to download MP3 / WMA files and music from the Internet. NAD ELECTRONICS INTERNATIONAL has no right to grant such permission. Permission should always be sought from the copyright owner. -
Page 22: Audio Cd And Mp3 / Wma Disc Features
Operation OPERATION WITH AUDIO CD AND MP3 / WMA DISC AUDIO CD AND MP3 / WMA DISC FEATURES PAUSE 1 Press PAUSE/STEP during playback. 2 To return to playback, press PLAY, ENTER or press PAUSE/STEP again. MOVING TO ANOTHER TRACK 1 Press SKIP ( ) briefly during playback to go to the next track or to return to the beginning of the current track. -
Page 23: Programmed Playback
The program function enables you to store your favourite tracks from any disc in the player memory. A program can contain 30 tracks. 1 Insert a disc. Audio CD or MP3/WMA Discs: AUDIO CD or MUSIC menu appears. 2 Press PROGRAM. mark will appear to the right of the word“... -
Page 24: Operation With Jpeg Disc
• Depending upon the size and number of JPEG files, it could take a long time for the DVD player to read the disc’s contents. If you don’t see an on- screen display after several minutes, some of the files may to select the be too large —... -
Page 25: Operation With A Dvd Vr Format Disc
Do not use strong solvents such as alcohol, benzine, or thinner, as these might damage the surface of the unit. Maintaining the Unit The DVD player is a high-tech, precision device. If the optical pick-up lens and disc drive parts are dirty or worn, the picture quality could be diminished. -
Page 26: Operation With A Divx Movie Disc
Operation OPERATION WITH A DIVX MOVIE DISC Using this DVD Player you can play DivX discs. 1 Insert a disc and close the tray. The MOVIE menu appears on the TV screen. MOVIE 0:00:00 List Movie Folder 1 Movie Folder 2... -
Page 27: Additional Information
SCREEN SAVER The screen saver appears when you leave the DVD player in Stop mode for about five minutes. If the Screen Saver is displayed for five minutes, the DVD Player automatically turns itself off. -
Page 28: Speaker Setup
DISTANCE If you connected speakers to your DVD Player, setting the Distance lets the speakers know how far the sound has to travel to reach your set listening point. This allows the sound from each speaker to reach the listener at the same time. -
Page 29: Reference
Check the following guide for the possible cause of a problem before contacting service. SYMPTOM No power. The power is on, but the DVD player does not work. No picture. No sound. The DVD player does not start playback. The remote control does not work properly. -
Page 30: Table Of Languages And Their Codes
Reference TABLE OF LANGUAGES AND THEIR CODES Language Code List Use this list to input your desired language for the following initial settings: Disc Audio, Disc Subtitle, Disc Menu. Code Language Code Language 6566 Abkhazian 7074 Fiji 6565 Afar 7073 Finnish 6570 Afrikaans 7082 French 8381 Albanian... -
Page 31: Country Codes List
Choose a country code from this list. Code Country Code Country Andorra Eritrea United Arab Emirates Spain Afghanistan Ethiopia Antigua and Barbuda Finland Anguilla Fiji Albania Falkland Islands Armenia Micronesia Netherlands Antilles Faroe Islands Angola France Antarctica France (European Argentina Territory) American Samoa Gabon... -
Page 32: Specifications
Reference SPECIFICATIONS GENERAL Power requirements Power consumption Dimensions (approx.) Weight (approx.) Operating temperature Operating humidity SYSTEM Laser Signal system Frequency response Signal-to-noise ratio Harmonic distortion Dynamic range OUTPUTS VIDEO OUT S-VIDEO OUT COMPONENT VIDEO OUT AUDIO OUT DIGITAL OUT (COAXIAL) DIGITAL OUT (OPTICAL) ACCESSORIES Video cable... - Page 33 ©2004 NAD ELECTRONICS INTERNATIONAL A DIVISION OF LENBROOK INDUSTRIES LIMITED All rights reserved. No part of this publication may be reproduced, stored or transmitted in any form without the written permission of NAD Electronics International T 524 Manual C Version 12/04...
