- Page 1 T515 ® DVD / CD / MP3 Player Owner’s Manual Manuel de l'utilisateur Bedienungsanleitung Gebruikershandleiding Manual del Usuario Manuale delle Istruzioni Manual do Proprietário Bruksanvisning...
-
Page 2: Introduction
Your local administrative office can advise you of the responsible waste disposal point. NAD is a trademark of NAD Electronics International, a division of Lenbrook Industries Limited Copyright 2006, NAD Electronics International, a division of Lenbrook Industries Limited CAUTION... - Page 3 CAUTION: PLEASE READ AND OBSERVE ALL WARNINGS AND INSTRUCTIONS IN THIS OWNER’S MANUAL AND THOSE MARKED ON THE PRODUCT. RETAIN THIS MANUAL FOR FUTURE REFERENCE. This product has been designed and manufactured to assure personal safety. Improper use can result in electric shock or fire hazard.
- Page 4 Introduction IMPORTANT SAFETY INSTRUCTIONS...
-
Page 5: Table Of Contents
Setting up the Player ........10 DVD Player Connections .......10 HDMI Connection . -
Page 6: Before Use
To ensure proper use of this product, please read this owner’s manual carefully and retain for future reference. This manual provides information on the operation and maintenance of your DVD player. Should the unit require service, contact an authorized service location. SYMBOL USED IN THIS MANUAL... -
Page 7: Types Of Playable Discs
• Do not attach any seal or label to either side (the labelled side or the recorded side) of a disc. • This DVD player requires discs and recordings to meet certain technical standards in order to achieve optimal playback quality. Pre- recorded DVDs are automatically set to these standards. -
Page 8: Disc-Related Terms
DivX is the name of a revolutionary new video codec which is based on the new MPEG-4 compression standard for video. You will be able to play DivX movies using this DVD player. PBC: PLAYBACK CONTROL (VIDEO CD ONLY) Playback control is available for Video CD (VCD) version 2.0 disc formats. -
Page 9: Front Panel And Display Window
Display window Shows the current status Shows the current status of the player. of the player. Remote Sensor Remote Sensor Point the DVD Player Point the DVD Player remote control here. remote control here. Introduction Display window Display window Shows the current status Shows the current status of the player. -
Page 10: Rear Panel
IR IN IR IN By connecting this DVD player to another By connecting this DVD player to another NAD audio NAD audio component or system component or system controller equipped with an IR controller equipped with an IR output, output, you can remotely operate the T515. -
Page 11: Remote Control
Switches DVD Player ON. AUDIO Selects an audio language (DVD). SUBTITLE Selects a subtitle language. ANGLE Selects a DVD camera angle if available REPEAT Repeat chapter, track, title, all. RPT A-B Repeat sequence. RANDOM Plays tracks in random order. MARKER Marks any point during playback. -
Page 12: Installation And Setup Connections
Rear of DVD player Video and Audio Connections to Your TV Make sure the DVD player is connected directly to the TV and not to a VCR, otherwise the DVD image could be distorted by the copy protection system. Video Connect the VIDEO OUT jack on the DVD player to the video in jack on the TV using the video cable (V). -
Page 13: Hdmi Connection
• If a distorted or abnormal colour picture appears on the monitor, switch Off and then back On the T515 via front panel power switch. • When you use HDMI, the other connections (Yellow VIDEO OUT, S-Video and Component Video (Y Cb/Pb Cr/Pr)) will not work. -
Page 14: Audio Connection To Optional Equipment
Amplifier equipped with 2-channel analogue stereo or Dolby Pro Logic ll / Pro Logic Connect the left and right AUDIO OUT jacks on the DVD player to the audio left and right IN jacks on your amplifier, receiver, or stereo system, using the audio cables (A). -
Page 15: Before Operation
ON-SCREEN DISPLAY You can display the general playback status on the TV screen. Some items can be changed using the menu. To use the on-screen display: 1 Press DISPLAY during playback. 2 Press to select an item. The selected item is highlighted. 3 Press to change the setting. -
Page 16: Initial Settings
Set the player’s TV Output Select options according to the TV connection type. YPbPr – When your TV is connected with the COMPONENT VIDEO OUT/(576p/720p/1080i) jacks on the DVD player. RGB – When your TV is connected with the SCART (RGB signal) jack English... -
Page 17: Audio
Move DVD-A DOLBY DIGITAL / DTS / MPEG BITSTREAM: Select “Bitstream” if you connect the DVD Player’s DIGITAL OUT jack to an amplifier or other equipment with a Dolby Digital, DTS or MPEG decoder. PCM (FOR DOLBY DIGITAL / MPEG): Select when connected to a two-channel digital stereo amplifier. -
Page 18: Others
You can set up the DVD Player so a DVD disc automatically starts playing whenever the DVD is inserted. If Auto Play mode is set to On, this DVD player will search for the title that has the longest playback time and then play back the title automatically. -
Page 19: Lock (Parental Control)
LOCK (PARENTAL CONTROL) LOCK Rating Unlock Password Country Code Move DVD-V RATING Some movies contain scenes that may not be suitable for children to view. Many of these discs contain parental control information that applies to the complete disc or to certain scenes on the disc. Movies and scenes are rated from 1 to 8, depending on the country. -
Page 20: Operation
DVD player. 2 Turn on the audio system (if applicable) and select the input source connected to the DVD player. 3 Press OPEN/CLOSE to open the disc tray and load your chosen disc in the tray, with the playback side down. -
Page 21: Slow Motion
STILL PICTURE AND FRAME-BY-FRAME PLAYBACK DVD-V DVD-A DivX 1 Press PAUSE/STEP on the remote control during playback. Advance the picture frame-by-frame by pressing PAUSE/STEP repeatedly. 2 To exit still motion mode, press PLAY. NOTE When using a DVD audio disc that includes pictures, this operation may be permitted in some picture segments. -
Page 22: Special Dvd Features
Operation OPERATION WITH DVD AND VIDEO CD DVD-V DivX ZOOM Use zoom to enlarge the video image. 1 Press ZOOM during playback or still playback to activate the Zoom function. The square frame appears briefly in the right bottom of the picture. -
Page 23: Dvd Audio Discs
TV screen, enter the password (sometimes you’ll find it on the disc’s jacket cover or on a web site). This password control isn’t dictated by your DVD Player — it is a function of the disc. Since the authoring of DVD Audio Discs varies, some of the on-screen display choices might not be available for the disc you’re playing. -
Page 24: Operation With Audio Cd And Mp3 / Wma Disc
(see above) to ensure compatible playback. Customers should note that permission is required in order to download MP3 / WMA files and music from the Internet. NAD ELECTRONICS INTERNATIONAL has no right to grant such permission. Permission should always be sought from the... -
Page 25: Audio Cd And Mp3 / Wma Disc Features
AUDIO CD AND MP3 / WMA DISC FEATURES PAUSE 1 Press PAUSE/STEP during playback. 2 To return to playback, press PLAY, ENTER or press PAUSE/STEP again. MOVING TO ANOTHER TRACK 1 Press SKIP ( ) briefly during playback to go to the next track or to return to the beginning of the current track. -
Page 26: Programmed Playback
Operation PROGRAMMED PLAYBACK The program function enables you to store your favourite tracks from any disc in the player memory. A program can contain 30 tracks. 1 Insert a disc. Audio CD or MP3/WMA Discs: AUDIO CD or MUSIC menu appears. 2 Press PROGRAM. -
Page 27: Operation With Jpeg Disc
• Depending upon the size and number of JPEG files, it could take a long time for the DVD player to read the disc’s contents. If you don’t see an on- screen display after several minutes, some of the files may be too large —... -
Page 28: Operation With A Dvd Vr Format Disc
Do not use strong solvents such as alcohol, benzine, or thinner, as these might damage the surface of the unit. Maintaining the Unit The DVD player is a high-tech, precision device. If the optical pick-up lens and disc drive parts are dirty or worn, the picture quality could be diminished. -
Page 29: Operation With A Divx Movie Disc
Using this DVD Player you can play DivX discs. 1 Insert a disc and close the tray. The MOVIE menu appears on the TV screen. MOVIE 0:00:00 List Movie Folder 1 Movie Folder 2 Movie Folder 3 Movie Folder 4... -
Page 30: Additional Information
SCREEN SAVER The screen saver appears when you leave the DVD player in Stop mode for about five minutes. If the Screen Saver is displayed for five minutes, the DVD Player automatically turns itself off. - Page 31 Operation NOTES...
-
Page 32: Reference Troubleshooting
TROUBLESHOOTING Check the following guide for the possible cause of a problem before contacting service. SYMPTOM No power. The power is on, but the DVD player does not work. No picture. No sound. The DVD player does not start playback. -
Page 33: Table Of Languages And Their Abbreviations
Language Code List Use this list to input your desired language for the following initial settings: Disc Audio, Disc Subtitle, Disc Menu. Code Language Code Language 6566 Abkhazian 7074 Fiji 6565 Afar 7073 Finnish 6570 Afrikaans 7082 French 8381 Albanian 7089 Frisian 6577 Ameharic 7176 Galician... -
Page 34: Country Codes List
Reference COUNTRY CODE LIST Choose a country code from this list. Code Country Code Country Andorra Eritrea United Arab Emirates Spain Afghanistan Ethiopia Antigua and Barbuda Finland Anguilla Fiji Albania Falkland Islands Armenia Micronesia Netherlands Antilles Faroe Islands Angola France Antarctica France (European Argentina... -
Page 35: Specifications
GENERAL Power requirements Power consumption Dimensions (approx.) Weight (approx.) Operating temperature Operating humidity SYSTEM Laser Signal system Frequency response Signal-to-noise ratio Harmonic distortion Dynamic range OUTPUTS VIDEO OUT S-VIDEO OUT COMPONENT VIDEO OUT AUDIO OUT DIGITAL OUT (COAXIAL) DIGITAL OUT (OPTICAL) DIGITAL OUT (HDMI) HDMI VIDEO OUT ACCESSORIES... - Page 36 ©2006 NAD ELECTRONICS INTERNATIONAL A DIVISION OF LENBROOK INDUSTRIES LIMITED All rights reserved. No part of this publication may be reproduced, stored or transmitted in any form without the written permission of NAD Electronics International T 515 Manual 05/06...
