Mvix MV-4000U User Manual

Mvix multimedia player
Hide thumbs
Table of Contents

Advertisement

Quick Links

MviX Multimedia Player
MV5000U & MV4000U
MviX Multimedia Player
Model NO. MV-4000U
Model NO. MV-5000U
USERS
MANUAL
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MV-4000U and is the answer not in the manual?

Questions and answers

Related Manuals for Mvix MV-4000U

Summary of Contents for Mvix MV-4000U

  • Page 1 MviX Multimedia Player MV5000U & MV4000U MviX Multimedia Player Model NO. MV-4000U Model NO. MV-5000U USERS MANUAL...

  • Page 2: Table Of Contents

    Connection to S-Video output Connection to component output Connection to 2ch of normal TV Connection to coaxial output Connection to optical output Connection to computer MviX Setup Menu Audio/Video Setup Misc Setup Firmware Setup Play all kinds of Media File Play Video File...
  • Page 3 You can now enjoy your favorite movies, home videos, digital music and digital photos on TV or Home-theater System. Mvix Player brings all digital media to your living room so that you can now enjoy with your near and dear ones.

  • Page 4: Package Contents

    Package Contents MV5000U & MV4000U MviX Multimedia Player MV-5000U MV-4000U Stand 12V Adapter Adapter Cable Remote control USB Data Cable A/V Cable Driver CD User Manual Bag (Only for MV-5000U)

  • Page 5: Front And Rear Panel

    Front and Rear Panels MV5000U & MV4000U MviX Multimedia Player FRONT [Only for MV-5000U] BACK VIEW...
  • Page 6 USB2.0 interface and enjoy a slide show without using a computer Portable HDD Storage MviX uses 3.5" HDD and it works just like an external USB2.0 hard drive when connect it to a PC. The USB2.0 interface supports data transfer rates of 480Mbps.

  • Page 7: Specification

    Supported Various languages 'smi, sub, srt' file Languages Dimensions 5.71 x 6.3 x 2.05 (inches) or 145 x 160 x 52 (mm) MVIX Media Player (MV-5000U/MV-4000U), AC Power Adapter RCA 2-CH, AV Cables, Retail Kit USB Cable (for PC), Includes...

  • Page 8: Safety Instructions

    Unplug your Media player during lightning storms or when unused for long periods of time. Do NOT touch your MviX Media Player with wet hands. It may cause electric shock. Clean only with dry cloth. Do not place any sources of danger on your Media Player (e.g. liquid filled objects, vases, lighted candles etc.).

  • Page 9: Remote Control

    Remote Control MV5000U & MV4000U MviX Multimedia Player 1. Power ON or OFF 2. Setup 3. Change the VIDEO OUT mode 4. Mute 5. Number Keys 6. Function Key 7. Goto 8. Title for DVD 9. Show the info for file playing 10.

  • Page 10: How To Assemble & Insert Hdd

    How to Assemble & Insert HDD Warning: It is of utmost importance that the installation process be conducted in a non-static environment. Always ground yourself by touching any metal object before opening your MVIX Multimedia player. 1. Slide the lock toward the “UNLOCK” direction Open here 3.
  • Page 11 7. Once inserted, the HDD should snugly fit between the brackets as shown. MV5000U & MV4000U MviX Multimedia Player 6. Carefully insert the HDD inside the MviX case as shown above. 8. Prepare and fasten the HDD to the bracket with two screws (supplied).
  • Page 12 How to Assemble & Insert HDD MV5000U & MV4000U MviX Multimedia Player 9. Once secured, slide the top-cover as shown above 10. Slide and close the lock toward the “LOCK” direction...

  • Page 13: Installation And Connection

    TV, you only need to make one video connection from these options. To hear sound through your TV, use audio connectors (RCA 2-CH) to connect the MviX multimedia player to the corresponding AUDIO-IN jacks on your TV or Hi-Fi Device.

  • Page 14: Connection To Component Output

    Installation and Connection Connection to Component Output Green, Blue, Red Cable Connect the MviX media player to your TV using a component cable as shown in the image above. Turn on the MviX and TV. Select appropriate video input mode on your TV (in this case, Component input mode) (cable not supplied).

  • Page 15: Connection To Coaxial Output

    When you have a multi channel decoder/amplifier with optical input, you can enjoy 5.1CH high quality sound via optical cable. The above illustration shows how to connect with optical cable. (cable not supplied). MV5000U & MV4000U MviX Multimedia Player Optical Cable...

  • Page 16: Connection To Computer

    MviX Multimedia Player Connection to Computer To transfer data or files from pc to your Mvix Multimedia Player. Connect MviX Multimedia Player to your computer using the USB cable (cable supplied). Ensure that your MviX player is powered- on. Upon connection your PC (Win-ME/2000/XP) should recognize the new USB connected drive without installing driver.

  • Page 17: Mvix Setup Menu

    MviX Setup Menu Audio/Video Setup 1) Video Out : Supports NTSC/S-Video, YPbPr/480i, YPbPr/480p, YPbPr/720p, YPbPr/1080i, PAL/S-Video, YPbPr/PAL 2) TV Type : Supports 4 X 3 Letter Box (Ordinary TV), 16:9 (HDTVs) 3) Audio Out : Supports Analog, or Digital Audio 4) FM Transmit : Supports Off, Even Band : 88.0MHz, 88.4MHz, 88.8MHz, 89.2MHz channels...

  • Page 18: Misc Setup

    4) Bookmark : You can turn On/Off bookmark while you playback or load a file 5) Language: Select the language you prefer to use with your MviX Multimedia player. Currently it supports English and Korean 6) LCD Bright : You can control the LCD bright in the range 0~100 7) Sys Default : You can change the setting of the sys default MV5000U &...

  • Page 19: Firmware Setup

    MviX Setup Menu MV5000U & MV4000U MviX Multimedia Player Firmware Setup Firmware Upgrade : STEP 1: Create an “UPGRADE” folder at root directory STEP 2: Download and Save the upgrade file in the “UPGRADE” folder. STEP 3: Browse to this file at setup F/W menu (more info, at page 19).
  • Page 20 Playing All kinds of Media Files [Default] 1. You will see a full list of all kinds media files saved on your Mvix 2. Use UP / DOWN key on your remote to select the files you would like play and press “OK”...

  • Page 21: Playing Video Files

    1. Press the ‘MEDIA” key on Remote Control. 2. You will see a list of only VIDEO file saved on your Mvix 3. Use UP / DOWN key on your remote to select the video you would like watch and press “OK”...
  • Page 22 1. Press the “MEDIA” key again on Remote Control 2. You will see a list of only AUDIO / MUSIC files saved on your Mvix 3. Use UP / DOWN key on your remote to select the video you would like watch and press “OK”...

  • Page 23: Playing Photo Files

    1. Press the “MEDIA” key again on Remote Control 2. You will see a list of only PHOTO / PICTURE files saved on your Mvix 3. Use UP / DOWN key on your remote to select the video you would like watch and press “OK”...

  • Page 24: Firmware Upgrade

    4. Make “upgrade” folder at root directory. 5. Copy firmware files into “upgrade” folder at the MviX hard drive. 6. Turn off MviX and bring it back to your TV for firmware upgrade. How to upgrade firmware 1. Connect the MviX Multimedia Player to your TV and turn on MviX.

  • Page 25: Windows 98Se Driver Installation

    1. Windows ME/2000/XP operating systems contain pre-installed driver software. No driver installation is required. 2. The PC will automatically recognize your MviX media player as soon as it is connected via the USB interface. (please ensure that your MviX player is powered-on during connection).
  • Page 26 Partition and Formatting the HDDs MV5000U & MV4000U MviX Multimedia Player Partitioning and Formatting the HDDs under Windows 98SE/ME Click “Start” and select “Run” and the “Run” window will appear as shown below. Type “fdisk” in the text box of the “Run”...
  • Page 27 Partition and Formatting the HDDs MV5000U & MV4000U MviX Multimedia Player 2) Type the last Disk number in 0% usage. 3) Select “1. Create DOS partition or Logical DOS Drive” and press [Enter].
  • Page 28 Partition and Formatting the HDDs MV5000U & MV4000U MviX Multimedia Player 4) Select “ 1. Create Primary DOS Partition ” and press [Enter] 5) Wait until finishing verifying the drive integrity.
  • Page 29 7) Type the capacity or % which you want to use and press [Enter]. 8) Drive integrity verification will start again. After finishing that, press [ESC] key when the “Primary DOS Partition created, drive letters changed or added” message displays. MV5000U & MV4000U MviX Multimedia Player...
  • Page 30 10) Type “ exit ” command at “ C:₩WINDOWS> ” and press [Enter] for returning to windows screen. 11) Unplug the MviX and plug again. New volume will be appeared at [My Computer]. Click mouse right button at the new volume and select [Format]...
  • Page 31 “Disk Management” folder. 3) The disk list will appear on the right side of the “Computer Management” windows. Right click the MviX HDD from the list and from the pop up menu choose “make partition” to make partitions on the chosen disk.
  • Page 32 Partition and Formatting the HDDs MV5000U & MV4000U MviX Multimedia Player 5) Choose the partition type and format the HDD. If you want the several partition, Select the Extended Partition. 6) Select the partition Size. If you want one partition, Press the “Next”. For the FAT32, it is limited under 32000MB...
  • Page 33 Partition and Formatting the HDDs MV5000U & MV4000U MviX Multimedia Player 7) Select the Driver letter. We recommend to press the “Next”. 8) Select the partition Format. If you want the FAT32, it is limited under 32GB.
  • Page 34 Partition and Formatting the HDDs MV5000U & MV4000U MviX Multimedia Player 9) When it is completed, detailed information will appear as shown below. Click the “OK” button to complete the work.

  • Page 35: Troubleshooting

    – Check if the TV is switched on. – Adjust the volume. – Check the audio cables and make sure both are connected secured to the TV or Stereo Audio In jacks. MV5000U & MV4000U MviX Multimedia Player...

  • Page 36: Warranty Information

    - Product repair and/or part replacement because of improper installation, connections to improper voltage supply, abuse, neglect, misuse, accident, unauthorized repair or other cause not within our control. - Damage occurring to product during shipping when improperly packaged or cost associated with packaging. MV5000U & MV4000U MviX Multimedia Player...

  • Page 37: Contact Information

    Contact Information Manufacturer: Unicorn Information Systems Co. Ltd Unbo b/d 226-16, Sukchon-dong, Songpa-gu, Seoul, Korea www.eunicorn.co.kr Branch (USA): MVIX (USA) Inc. 14102 Sullyfield Circle, Suite 100 Chantilly, Virginia 20151 sales@mvixusa.com support@mvixusa.com www.mvixusa.com MV5000U & MV4000U MviX Multimedia Player...

This manual is also suitable for:

Mv-5000u
