Mustek V560 Specifications

DVD PLAYER
DVD V560
State-of-the-Art Multimedia Centres
with Good Design and Lots of Versatility.
Product Positioning:
Mustek GmbH presents a new generation of DVD players, which
are full of promise under their attractive casings: the DVD-V560
• Home entertainment for all
as a versatile model for the connoisseur
contemporary video and
audio formats
The DVD V560 is compatible with all DVD video formats and
media for MP3, DTS, CD-R, CD-RW, SVCD and DVCD formats. It
Target Customer:
supports the PAL and NTSC video formats and are fitted with
• All design conscious users
outlets for Composite Video and S-Video. There is also an outlet
requiring high-quality
for analogue as well as digital audio. With integrated Dolby
reproduction
Virtual Surround fitted, there is perfect audio quality with cinema
quality. But of course the machines can run the common picture
formats 16:9 and 4:3 as well as the MPEG 1 & 2 norms.
Package Contents:
With all this there is an assurance that you will be able to enjoy
• User guide
perfection listening to music or watching your favourite film.
• Remote control
Using the infrared remote control and the convenient on-screen
display, DVD player can be configured and used in complete
comfort without a bundle of cables lying around.
DVD V560 – The Multimedia Centre for
the Discriminating Customer.
The DVD V560 is Mustek's flagship in the DVD fleet: a piece of
equipment for the demanding, design conscious user. Its success
lies in its excellent optics and high-quality technology, which
afford perfect satisfaction for your film or audio enjoyment. It is
fitted with a AC3 audio decoder with digital and analogue
interfaces. These features fulfil all that one could wish for with a
DVD player.
Features
• DVD/CD/VCD/MP3/DTS/CD-R/CD-RW/SVCD/DVCD
• Support NTSC/PAL dual system and 16:9/4:3 format
• 5.1 channel analogue output
• AC 3 decoder for 5.1 digital output
• 32 X real-time play and display
• Composite Video, S-Video and Scart output
• Infra-red remote control and OSD (On-Screen-Display)
Subject to error and technical modification. The actual products supplied may differ in technical features and design from the ones shown here.
Mustek Computer GmbH, Hansemannstrasse 63, D-41468 Neuss · Tel. +49 (0) 21 31-16 26-0 · Fax +49 (0) 21 31-10 38 30
Playback compatible
WWW.MUSTEK-EUROPE.COM
Reliability
In addition to the quality DVD-Player and the on-line help-system,
this product package also includes a detailed manual and its glo-
bal access to Mustek's technical support department. It features
a standard warranty, outstanding technical support and is
manufactured under strict ISO-9001 guidelines.
About Mustek
Mustek was established in 1988 and made the very first and
unique hand-held scanner with a PCMCIA interface for PCs and
Notebooks. This innovative and dynamic scanner pioneer has
matured and diversified their products offerings from scanners to
digital still cameras , LCD projectors, DVD players and UPS
systems for the global market. All production follows ISO9001,
9002 regulation and adheres to most international industry
standard. They serve the IT community with headquarter in Tai-
wan and offices in the USA, China, Japan and Germany.

Technical Specifications

Supported Formats: ...... DVD, CD, MP3, DTS, CD-R, CD-RW,SVCD,DVCD
TV System: ............................................................... NTSC, PAL
Video Norms: ...................... MPEG-1, MPEG-2 (ISO/IEC-13818)
Picture Formats: ........................................................... 16:9; 4:3
Video Signal: ................................ 1.0V pp/75 Ohm Sync, minus
S-Video Output: . (Y) 1.0V pp/75 Ohm (Sync and Minus Polarity)
...... (C) 0,28 V pp/75 Ohm (Sync and Minus Polarity)
Audio System: ........................................... 5.1-channel analogue
................. 5.1-channel Dolby Surround Digital output
DVD Frequency Range: ................ 48 KHz Sampling: 4Hz~22KHz
.................................. 96 KHz Sampling: 4Hz~44 KHz
Dynamic Range: ............................................................. > 95dB
Harmonic Distortion: .................................................. < 0,004%
Analogue Audio Output: ......................... 2.9V/330 Ohm (1 KHz)
Digital Audio Output: ...................................... 0,5 V pp/75 Ohm
Headphone Output: .......................... 32 Ohm (32 mW), > 8 Ohm
Video Interface: .... 1 x SCART, 1 x Composite Video, 1 x S-Video, 1 x RGB
Audio Interface: ........................ 1 x 5.1-channel analogue output
.................... 1 x Digital PCM/AC3, coaxial, 1 x optical
Power: ............................................. 100/240 Volt, 50/60 Hz
Power Consumption: ...................................................... 20 Watt
Dimensions (W x H x D): .................. 430 mm x 68 mm x 300 mm
Weight: ........................................................................ < 4 kg
