  • Page 1 CORE Outdoor Power CB 420 Handheld Blower Troubleshooting/Service Guide Servicing Dealers / Technicians...
  • Page 2 FOR DEALERS:  Communication is key When servicing CORE Product, it is helpful to have any information on the  behavior of the returned product.  When the product is returned, the person  responsible for accepting the product back can greatly assist the service  technician by asking a few questions.  Some suggested questions are written  below: Is it a satisfaction guarantee return?   Is the product, itself, not functioning correctly? If so, please describe. Is the charger not charging the Power Cell? Is the Power Cell not functioning properly?   ...
  • Page 3 Most Common Issues ‐ Solutions Symptoms Initial Initial Solution Alternate  Alternate Diagnosis Diagnosis Solutions Blower doesn’t rotate or   Motor  See Pages 9‐10 Controller Page 14 See Pages 9‐10 Page 14 bounces with no rotation No Function when trigger is  Controller See Page 14 Motor Pages 9-10 Page 14 engaged  Grip Handle Page 12 Power Cell  Pages 4-6 Product runs Intermittently Motor See Pages  9‐10...
  • Page 4 Basic Power Cell and Charger Troubleshooting Issue Diagnosis Verification Charger lights do not illuminate Defective Charger N/A – Replace Charger Charger lights do not change when  Defective Charger Plug a  known functional Power Cell into  Power Cell is engaged in Charger Defective Power Cell Charger to test Charger. If problem persists, Charger is defective, and  should be replaced. If plugging in known functional Power Cell  changes lights, then returned Power Cell is  bad and should be replaced Power Cell will not run Product Defective Power Cell Plug Power Cell into a known functional Defective Charger Product. If problem persists, Power Cell is defective,  and should be replaced. If known functional Product runs, Power Cell  is good, and  returned product should be  further diagnosed.
  • Page 5 Basic Power Cell and Charger Operation CRC 6500 Rapid Charger Charging Fully Charged Green...
  • Page 6 Basic Power Cell and Charger Operation CSC 6500 Standard Charger Charging Fully Charged Green...
  • Page 7 CB 420 Handheld Blower Assembly / Disassembly Guide...
  • Page 8 Replacement Parts  CB‐420‐Handheld Blower ITEM QTY DESCRIPTION 1 CLAMP, SHAFT 1 TUBE, STRAIGHT, BLOWER 1 TUBE, SWEEPER, BLOWER 1 IMPELLER ASSEMBLY, BLOWER 1 BLOWER WIRE COVER 1 BLOWER HOUSING MOTOR SIDE 1 BLOWER HOUSING INLET SIDE 1 MOTOR ASSEMBLY, BLOWER 1 SCREW, MACH, PH TORX, ZPS, 10-32 X .750 7 SCREW, PLASTITE, PH TORX, ZPS, #8 X .500 2 SCREW, PLASTITE, PH TORX, ZPS, #8 X 1.000 4 SCREW, PLASTIC, PH TORX, ZPS, #10 X .500...
  • Page 9: Motor Disassembly And Assembly

    Motor Disassembly and Assembly Hardware and Tools Required ‐ Electric Drill ‐ T20,T25 BITS ‐ Shaft Fork/Wrench - 4 SCREW, PLASTIC, PH TORX, ZPS, #10 X .500 - 4 SCREW, PLASTITE, PH TORX, ZPS, #8 X .500 - 2 SCREW, PLASTITE, #8 x 1” 1. Remove Blower Cover as shown in  pictures 1 and 2 2.    Remove Phase and Hall Wires  as shown in pic 3 3.    Use fork or similar tool to grip shaft and spin Impeller off clockwise.
  • Page 10: Motor Assembly

    Motor Assembly Hardware/Parts Required Blower Housing Impeller Blower Cover Motor Washer Tools Required ‐ Electric Drill/ T25‐T20 Bits  ‐ Shaft Fork/Wrench Insert washer on motor, positioned under Housing. Using Shaft Fork or similar tool, spin  Impeller on to motor counter‐clockwise. Reverse disassembly instructions on    page 9 ...
  • Page 11: Hardware Required

    Blower Tube Replacement Hardware Required Blower Tube Tools Required Electric Drill/T25 and T20 BITS Unscrew four closest screws to Tube. Pull Tube out of slot. Replace with new and insert screws.
  • Page 13 Power Housing / Grip Handle Disassembly Take apart the power housings  using a T20 bit.   Disconnect the wire connector  on the controller leading to the  grip handle.  Dis‐assemble the grip handle  using a T18 torque bit on the  little screws, and a T25 on the  clamps. ...
  • Page 14 Power Housing Assembly / Controller Install HARDWARE AND PARTS REQUIRED: (8) 8‐32 STANDARD NUTS (4) 8‐32 1 ¼” BOLTS  (4) 8‐32 1 ¾” BOLTS TOOLS NEEDED: ELECTRIC/SCREW GUN  W/ T20 BIT‐ NEEDLE NOSE PLIERS 1. Plug Wires into Controller as Shown in Picture 1 and Slide controller  into slot in Power Housing 2. Route Wires through Power Housing as shown in  Picture 2.  Make sure  Wires are clear of Power Housing Areas that may lead to pinching. 3. Place Power Sleeve into Power Housing and lower opposite Power  Housing on as shown in picture 3.  Make sure Controller, Wires and  Power Sleeve are all aligned in  there respective slots. 4. Bolt the housings together, starting with the 1 ¼” bolts in the front  four locations, and finishing with the remaining four in the rear.
