Description
The Series 1400 is a microprocessor based fault
annunciator. It tells in alphanumeric characters
which protective device has signaled an alarm or
caused equipment shutdown. Basic programming
for each application is completed at Murphy and
can be changed in the field by simply plugging in
a new preprogrammed microchip. Information is
called up and adjustments are made on a six-but-
ton keypad on the face of the unit.
Four SPDT relays are available for alarm and/or
shutdown functions. A digital output version
(S1400-SP) port interfaces with micro-controllers
(7 bit straight binary code).
The S1400 and S1400-SP are powered from a
120 VAC or 12/24 VDC Class I, Division 1
explosion-proof power supply. The monitor is
rated intrinsically safe.
Applications
Although designed primarily as an intrinsically
safe annunciator for gas compressors, the Series
1400 can be programmed to monitor most engine
or motor driven process applications, such as:
Air compressors
Process control
Gas compressors
Water treatment
Fire pumps
Burner systems
Sewage pumps
Natural gas refueling
Generators
®
MFR.
®
Annunciator
Features
32 sensor inputs (N.O. and/or N.C.) for
alarm or shutdown
Six-button keypad for easy operation and
adjustments
Digital output for interface with micro-con-
trollers (optional)
Adapter for CD ignition interface with opto-
isolator input (optional)
Relay board expansion, provides 7 additional
control relay outputs or binary representa-
tion of alarm/shutdown terminal number
(specify)
Start-run timer
Four control relay outputs
Pre/Post lube time delay
Typical standard program or customized*
These options are NOT approved by CSA.
*
Murphy provides various standard preprogrammed
configurations. If a customer sensor input configu-
ration is needed, Murphy will custom program
your unit at the time you order. Call for quote.

Specifications

Power Consumption: 120 VAC (8 watts),
24 VDC (7.2 watts) or 12 VDC (2.5 watts).
Sensor Inputs: For up to 32 N.O. and/or N.C.
inputs such as Murphy SWICHGAGE
ments. Each input is factory programmed as a
class A, B or C shutdown, alarm, or control
function (specify).
Series 1400
32 N.O. or N.C. Sensors
for Alarm or Shutdown
Alphanumeric Display
Start/Run Timer
Pre/Post Lube Timer
Four Control Relay Outputs
Field Adjustable
EPROM Memory
Approved for Class I,
®
Division 1, Group D
Outputs: 4-SPDT relays, 4 A,
NOTE: An isolation barrier (such as the Murphy
LCDT-ISB) must be used between the sensor
switch and input terminals if the sensor output
comes from any energy storing device such as a
relay or transistor.
Timers: 4 adjustable for: lockout at start-up, test,
Time Delay: Up to 0.9 minutes before ignition
Memory: Memory held in EPROM, 4k,
192 bytes of RAM.
Backup Battery: Rechargeable during normal
Run Sensing: Either ignition or switch input.
Operating Temperatures: 32 to 122°F (0 to 50°C).
Storage Temperatures: -4 to 158°F
Case: ABS plastic,
Interface Output: Digital, 7 bit straight bina
Display: Alphanumeric dot matrix, 2 line
Power Supply
®
instru-
S14-8908B
Revised 08-93
Catalog Section 50
1
/
HP,
20
125/250 VAC/3A, 30 VDC.
prelube and postlube.
grounds or electric motor stops.
operation. Provides up to 5 hours backup time.
(-20 to 70°C).
1
/
DIN (90 x 90 mm).
4
32-character display.
Enclosure: Explosion-proof, Class I, Division 1.
Barrier: Intrinsically safe barrier built into
power supply, 120 VAC and 12 or 24 VDC
power supply barrier with dry contacts relay
functions such as:
Fuel valve
Alarm
Shutdown
Control (Pre/Post Lube).
ry
code.
