Summary of Contents for Craig CTFT750
Page 1
7 INCH PORTABLE DVD/CD PLAYER 7 INCH PORTABLE DVD/CD PLAYER Owner's Manual PLEASE READ BEFORE OPERATING THIS EQUIPMENT. Model: CTFT750 Size: 148.5(W) x 210(H)mm (A5)
Page 7
DC IN jack Panel POWER ON/OFF switch AV (Audio/Video) OUT jack Speaker Speaker EARPHONE jack PLAY/PAUSE button SETUP button MODE button UP/PREV button DOWN/NEXT button STOP button MENU button LEFT/FB button VOL (Volume)- button RIGHT/FF button VOL (Volume)+ button ENTER button OPEN 1 .
Page 8
1 2 . R I G H T / F F ( F a s t F o r w a r d ) b u t t o n ~ I n d i s c p l a y b a c k , p r e s s r e p e a t e d l y t o s e t t h e s e a r c h s p e e d a n d f a s t s e a r c h i n g t h e d e s i r e d s e c t i o n f o r w a r d . P r e s s t h e P L AY / PA U S E b u t t o n t o r e s u m e n o r m a l p l a y b a c k .
Page 9
SUBTITLE button MUTE button TFT button POWER button ANGLE button ZOOM button REPEAT button DISPLAY button PLAY/PAUSE ( ) button SETUP button Direction button ENTER button MENU button STOP button PROG ( Program ) button TITLE button AUDIO button VOL (Volume) button VOL (Volume) button Numeric buttons (0-9 and 10+)
Battery installation: 1. Press the tabs on the battery door and lifting it off. 2. Install two (2) x AAA size batteries (included) into the battery compartment as the figure below and the polarity markings inside battery compartment. 3. Replace the battery door. BATTERY PRECAUTIONS: Follow these precautions when using a battery in this device: 1.
Page 11
AC CONNECTION The unit has a built-in rechargeable Li-polymer battery, recharge it before use as below: AC/DC Adaptor: ~ Insert the small plug from the AC/DC Adaptor into the DC IN jack on the side of the unit. ~ Insert the AC/DC Adaptor into a conveniently located AC outlet having AC 100-240V~;...
Page 12
Connecting to a TV with supplied AV connection cable: Video input jack Yellow Audio left channel input jack White Audio right channel input jack EARPHONES JACK: For private listening, insert the supplied Earbuds into the EARPHONES jack. The sound from speakers will turned off.
Page 13
The viewing angle of the swivel panel can adjust as below as desire...
BASIC OPERATION Disc Playback: ~ Lift up the panel and turn to desired angle. Slide the POWER ON/OFF switch to "ON" position to power on the unit, the Green indicator on front of the unit will light. ~ Press the OPEN area on the disc door to open it.
Page 15
BASIC OPERATION (CONT.) POWER Slide the POWER ON/OFF switch to ON position to power on the unit. Slide the POWER ON/OFF switch to OFF position to power off the unit. Press the POWER button on remote control to t rn on the unit from standby mode. Press the POWER button again to turn the unit to off (standby mode).
Page 16
BASIC OPERATION (CONT.) ANGLE During DVD playback, press repeatedly to select the available angle of recording as desired. NOTE: Function depends on the recording of the DVD disc, not all the DVD discs with this function. SUBTITLE During DVD playback, press repeatedly to select the available subtitles on the DVD as desired. NOTE: Function depends on the recording of the DVD disc, not all the DVD discs with this function.
Page 17
BASIC OPERATION (CONT.) In CD Playback: Select the desired establish time of the current disc, press the GOTO button once, the time selection table will appear on the screen. Using the Direction and Numeric buttons to enter the desired establish time. The unit will start plays the music from the selected establish time.
SYSTEM SETUP Setting Menu: In stop playback mode, press the SETUP button, the setting menu will appear on the screen as below. Using the Direction buttons to select and highlight the function you need to set or reset. Press the ENTER button to enter or confirm the selection.
FEATURES SETUP VIDEO SETUP 1. If the panel quality is selected, using the Direction and ENTER buttons to set the panel quality of screen such like Sharpness, Brightness, Contrast, Hue and Saturation. P EFERENCE SETUP 1. If TV Type is selected, using the Direction and ENTER buttons to set to PAL, AUTO or NTSC. (Note: The TV system in US, Canada and Mexico is NTSC.) 2.
TROUBLESHOOTING No power Power of built-in battery may consumed. Recharge it by the supplied AC/DC Adaptor. During charging, the unit can plays disc at the same time. No sound ~ Volume level too low. Rising it by press the VOL + button. Aspect ration of the screen incorrect Press the MODE button on unit repeatedly to change the aspect ration to 4 3 or 16:9 to match the aspect of the movie.
Page 21
Caring for Discs Treat the disc carefully. Handle the disc only by its edges. Never allow your fingers to contact with the shiny, unprinted side of the disc. Do not attach adhesive tape, stickers, etc. to the disc label. Clean the disc periodically with a soft, lint-free,dry cloth, Never use detergents of abrasive cleaners to clean the disc.
SPECIFICATIONS Power Source: Main Unit: Built-in rechargeable Li-polymer battery, recharge by DC 12V,1A, through DC IN Jack AC Adaptor Input: AC 100-240V~; 50/60Hz ,2500mAh Output: DC 12V,1A Car Adaptor Input Voltage:..DC 12V, 1A Output voltage:..DC 12V, 1A Built-in fuse:..F2AL, 250V Remote Control 3V, 2 x”AAA”...
Page 23
Under no circumstance shall Craig be liable for any loss or consequential damage arising out of the use of this product. This warranty gives specific legal rights. However, you may have other rights which may vary from state to state.
