Murphy S10 Series Specification Sheet

S10 series
AUTOMATIC BATTERY CHARGERS
RATINGS TO 10 AMPS
The S10 is a constant potential, open-chassis battery
charger, suitable for use with either 12V DC or 24V DC,
lead acid or Ni-Cd systems. Although primarily designed
for the diesel generator market, the charger may be
configured for use in a wide range of unattended industrial
applications where standby power is required at all times.
Each unit consists of a transformer, rectifier and control
circuitry. The charger monitors the battery voltage and
delivers as much current as the cells require up to the
current limited maximum, giving a rapid recovery of charge.
Once the battery is fully charged, the charger provides a
low trickle charge to maintain the cells for an indefinite
period at a pre-set float voltage, without overcharging, plus
any additional current required to support a static load.
Also included is a range of on-board fault monitors
complete with volt free relay contacts for remote
alarm signalling.
Standard Features
Boost function, operated by remote link.
Indication by amber LED.
Adjustable float and boost voltage levels to meet with
a range of battery types, static loads and operating
conditions. Standard calibrations are:-
BATTERY TYPE
Lead acid (6 cells)
12 V Ni-Cd (9 cells)
Ni-Cd (10 cells)
Lead acid (12 cells)
24 V Ni-Cd (18 cells)
Ni-Cd (20 cells)
Adjustable current limit. Standard versions have a
10 Amp limit, but this may be adjusted downwards
where required (e.g. for lower capacity batteries).
Output short circuit protection.
Protection against reverse polarity battery connection
via fuse and red warning LED.
3 alarm monitoring circuits: 'charge fail', 'low battery
voltage' and 'high battery voltage', complete with
volt-free relay outputs and LED indicators. The low
battery voltage alarm features a fixed time delay of
approx. 60 secs. to inhibit the signalling of a fault
during normal battery loading (e.g. engine cranking).
Electrical connection of the battery, boost and charge
monitoring relays is via ¼" blade terminals. The AC supply
is connected through separately mounted screw terminals.
When ordering, please specify:-
a) Product type (S10 series)
b) Nominal output voltage (12 or 24 V DC)
c) AC supply voltage (240 or 110 V)
d) Battery type (Lead-acid, or Ni-Cd and number of cells,
or special calibration requirements).
Since 1939
Frank W. Murphy Manufacturer
PO Box 470248, Tulsa, Oklahoma 74147, USA
Tel: + 1 918 627 3550 Fax: + 1 918 664 6146
email: sales@fwmurphy.com
web: http://www.fwmurphy.com
The Generator Controls Division of
FLOAT
VOLTAGE VOLTAGE
(V DC)
13.6
12.8
14.2
27.2
25.6
28.4
Frank W. Murphy Ltd. Frank W. Murphy Ltd. en France
Incorporating Modex Automation
Tel: +33 (1) 30 76 26 26 Fax: +33 (1) 30 76 39 89
Church Road, Laverstock, Salisbury U.K. Direct usine Tel: + 44 1722 410697
Tel: + 44 1722 410055 Fax + 44 1722 410088 email: sales@fwmurphy.co.uk
Pour service en Français, tél: + 44 1722 410697
Frank W. Murphy Pte, Ltd.
email: sales@fwmurphy.co.uk
No. 2 Tuas South Street 2, Sprintecs Building
web: http://www.fwmurphy.co.uk
02-01/02, Singapore 637895
Tel: + 65 863 1398 Fax: + 65 863 0208
email: fwmsales@fwmurphy.com.sg
Product Specification
Power supply:
operating voltages
Charging output:
nominal output voltage
voltage stability
current limit
current stability
Relay outputs:
charge fail and low battery volts
high battery volts
BOOST
General:
(VDC)
operating temperature
overall dimensions (h x l x d)
14.1
weight
14.0
EMC emission/immunity
15.6
28.4
28.1
Connection
31.2
F1, fuse type T, rating:
S1012, 240V: 1.5A
S1024, 240V: 3.15A
AC
supply
Dimensions (mm)
Frank W. Murphy Southern Division
PO Box 1819, Rosenberg, Texas 77471, USA
Tel: + 1 281 342 0297 Fax: + 1 281 341 6006
email: sales@fwmurphy.com
Murphy Switch of California
PO Box 900788, Palmdale, California 93590, USA
Tel: + 1 805 272 4700 Fax: + 1 805 947 7570
email: sales@murphyswitch.com
web: http://www.murphyswitch.com
R
240 V AC or 110 V AC (specify),
1 – 10 Amps, factory set
(ratings for resistive load)
volt free SPNO contacts
all rated 5 A @ 30 V DC
to EN50081-2/EN50082-2
high
charge battery
fail volts
110V: 3.15A
110V: 6.3A
1 2 3 4
L
F1
N
BCS
9 10
E
Overall
Murphek Pty. Ltd.
1620 Hume Highway, Campbellfield, Vic. 3061 Australia
Tel: + 61 3 9358 5555 Fax: + 61 3 9358 5558
email: murphy@macquarrie.com.au
Murphy de Mexico S.A. de C.V.
Blvd. Antonio Rocha Cordero 300, Fracción del Aguaje
San Luis Potosí, S.L.P. México 78384
Tel: + 52 48 206264 Fax: + 52 48 206336
email: murmexsl@sanluis.podernet.com.mx
M020301
Issue 5, revised 07/98
Catalogue section 75
+/– 10%, 50/60 Hz.
see chart left
+/– 1% of nominal
+/– 2% of nominal
volt free SPNC contacts
–10 to +55 o C
185 x 145 x 155 mm
approx. 8.0 Kg
low
battery
volts
5 6 7
+
battery
–
8
Boost
switch/timer
Fixing Base
