PS9600 Power Supply User Guide Introduction This manual describes the field installation of a Multi-Tech PS9600 power supply into a CommPlete Communications Server CC9600 chassis. Installation and troubleshooting of the PS9600 should be performed only by qualified service personnel. Description The PS9600 is a universal input switching power supply for the CommPlete Communications Server.
Fuses Manual Organization Chapter 1 Introduction This chapter describes the PS9600, gives its technical specifications, and provides a guide to the organization of the manual. Chapter 2 Installation This chapter describes how to install the PS9600 into the CommPlete chassis Chapter 3 Operation This chapter describes briefly how to operate the PS9600 power supply.
6. Tighten the PS9600’s retaining screws. 7. Turn the PS9600 power switch on to the on (I) position. 8. Observe the PS9600 “outputs good” LED. If it is not lit, see Chapter 4. If it is lit, proceed with normal CommPlete Communications Server operation.
This chapter provides information about operating your PS9600 Power Supply after it is installed. Power Switch The PS9600 has a power switch on the front panel that is labeled with the international I (on) and O (off) symbols. For the most reliable operation, both power supplies should be turned on whenever the CommPlete Communications Server is operating.
Power Supply LED This LED goes out if one of the PS9600 power supply outputs goes low or fails altogether. In normal operation it is lit. The recovery procedure to be used depends on whether the CommPlete chassis has one or two PS9600 power supplies installed.
Important Safety Considerations Fuse Replacement There is one replaceable fuse in the PS9600 power supply. Qualified service personnel may replace the fuse with one of the same type and rating as indicated on the PS9600 Fuse Label. CommPlete Communications Server...
Insertion and Removal of a Power Supply Qualified service personnel may insert or remove a power supply without turning off the system. We recommend that you insert the power supply slowly. If the power supply is not replaced, a cover plate must be installed.
