Multi-Tech MultiMobile MT3410ZLX Owner's Manual

Pcmcia ethernet/fax/modem card
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Models MT3410ZLX
and MT3410ZLX-T/2
Owner's Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MultiMobile MT3410ZLX and is the answer not in the manual?

Questions and answers

Summary of Contents for Multi-Tech MultiMobile MT3410ZLX

  • Page 1 Models MT3410ZLX and MT3410ZLX-T/2 Owner’s Manual...
  • Page 2 Furthermore, Multi-Tech Systems, Inc. reserves the right to revise this publication and to make changes from time to time in the content hereof without obligation of Multi-Tech Systems, Inc.

  • Page 3: Table Of Contents

    Features ... 9 System Requirements ... 10 Ship Kit Contents ... 10 Chapter 2 - Installation Safety Warnings ... 12 Installing The MT3410ZLX or MT3410ZLX-T/2 Card(s) ... 13 Driver Software Installation ... 14 Novell NetWare Installation ... 14 Menu Installation ... 14 Manual Driver Installation ...
  • Page 4 MultiMobile Owner’s Manual Chapter 3 - Comprehensive Driver Notes Introduction ... 29 Factory Default Settings ... 29 Quick Start ... 29 PC Card Software - Manual Installation ... 29 Getting Started ... 31 Using DOS Extended Memory Managers ... 31 Driver Directory Structure ...
  • Page 5 ... 44 When I run CARDEN, “PC-Card is not enabled successfully” is displayed ... 44 Enabling the MT3410ZLX ... 45 Installing the Win 95 Driver over SystemSoft ... CardWorks ... 46 The NetWare driver runs successfully but fails to login to the Netware server ...
  • Page 6 MultiMobile Owner’s Manual Appendix A - Technical Specifications Appendix B - AT Commands, S-Registers & Result Codes Introduction ... 59 How To Use AT Commands ... 59 Basic AT Commands ... 60 AT& (Ampersand) Commands ... 64 AT% (Percent) Commands ... 67 AT\ (Back Slash) Commands ...

  • Page 7: Chapter 1 - Introduction And Description

    Group 3 fax machine. Using standard phone lines and 10BaseT Ethernet, the data communication functions of the MT3410ZLX permits you access the servers on a LAN and connect to the Internet, transmit E-Mail, send and receive information and communicate with...

  • Page 8: Specifications

    (to PC card); with the other end of the cable terminated with one RJ-11 receptacle connector for PSTN and one receptacle connector converting 10Base-T to 10Base2 BNC T- for LAN. Network IEEE 802.3 10BaseT (MT3410ZLX), 10Base2(MT3410ZLX-T/2)--10M bps NE2000 compatible...

  • Page 9: Modem Characteristics

    Modem Characteristics V.34bis 33600bps, V.34 28800bps, V.32bis 14400bps V.42 bis & MNP 2-5 data compression and error correction, AT Command Set Enhanced Throughput Cellular (ETC) protocol for mobile cellular connections Group 3, V.17 14400bps and V.29 9600bps Fax Service Class 1 and Class 2 compliant Features •...

  • Page 10: System Requirements

    • Driver software loaded on your PC • Data and/or Fax communications software Ship Kit Contents Your MT3410ZLX is shipped from the factory with the following: • an MT3410ZLX PCMCIA LAN/Fax/Modem Card • one cable with a 15-pin detachable connector (to PC card) terminated on one end;...
  • Page 11 • one 3-1/2” Software Drivers diskette • User’s Manual (this manual) • Fax/Modem communications software disk • one cable with a 15-pin detachable terminated connector (to PC card); with the other end of the cable terminated with one RJ-11 receptacle connector for PSTN and one receptacle connector converting 10Base-T to 10Base2 BNC T- for LAN.

  • Page 12: Chapter 2 - Installation

    MultiMobile Owner’s Manual Chapter 2 - Installation Safety Warnings Never install telephone wiring during a lightning storm. Never install telephone jacks in wet locations unless the jack is specifically designed for wet locations. This product is to be used with UL and CUL listed computers.

  • Page 13: Installing The Mt3410Zlx Or Mt3410Zlx-T/2 Card(S)

    T/2 is powered directly from the PC. Connect the MT3410ZLX to the network (LAN) using the RJ-45 (8-pin) plug. 3a . Connect the MT3410ZLX-T/2 to the network (LAN) using a “thin coax” cable. Allign the notches of the cable to that of the BNC T- connector, and twist clock wise approximately one-quarter turn.

  • Page 14: Driver Software Installation

    NDIS 2.x or Packet Drivers) onto the target disk. The NOS selection screen is displayed: Figure 2-1. NOS Selection Screen Novell NetWare Installation There are two methods to install the MT3410ZLX under NetWare: Menu Installation and Novell Client Installation (for NetWare versions 3.12 and 4.x). Menu Installation Run INSTALL.EXE from Driver diskette‘s root...

  • Page 15: Manual Driver Installation

    Move the cursor to highlight the settings you want to change and press Enter to select an appropriate value. When the configurations are set completely, press Enter on the OK field to exit the screen. The Installation program copies related files from the Drivers diskette to the destination directory and modifies the AUTOEXEC.BAT and NET.CFG files as specified.
  • Page 16 MultiMobile Owner’s Manual Use a text editor to edit the NET.CFG file for setting the Frame Type. On the NetWare server, the Frame Type default is 802.3 for NetWare 3.11, and 802.2 for NetWare 3.12 and 4.x. The Frame Type set in NET.CFG must match Frame Type set at the NetWare server, or the client will not attach to the server.

  • Page 17: Novell Client Installation

    BACKUP? (Y/N): No Answer accordingly and provide a path if necessary. Select a driver for your MT3410ZLX. From the driver list, select Other Drivers. Go to the Insert the Driver Disk dialog box and specify the path where the ODI driver and INS files reside.
  • Page 18 MultiMobile Owner’s Manual 10. Press F10 to save to new configuration. 11. Highlight Install press here and press <Enter> to install. The program copies the necessary files for NetWare Client. 12. Continue the installation procedure to completion. On completion, a new NET.CFG file is created in your DOS directory.

  • Page 19: Microsoft Lan Manager Installation

    Microsoft LAN Manager Installation View the README.TXT on the installation diskette in the \NDIS2 directory. Before installing the drivers, ensure that the Microsoft LAN Manager has been installed in the target path. The installation program will check and modify the PROTOCOL.INI file for LAN Manager.
  • Page 20 MultiMobile Owner’s Manual Figure 2-3. Microsoft LAN Manager Installation Screen A sample LAN Manager PROTOCOL.INI file: [PROTMAN] DRIVERNAME = PROTMAN$ DYNAMIC = YES PRIORITY = NETBEUI [NETBEUI_XIF] Drivername = netbeui$ SESSIONS = 6 NCBS = 12 BINDINGS = “LM28NDS2_NIF” LANABASE = 0 [LM28NDS2_NIF] ;...

  • Page 21: Packet Driver Installation

    Packet Driver Installation Run INSTALL.EXE from the root directory of the Drivers diskette. Select the Packet Driver item on the Menu screen. If the current settings are acceptable, select Start Installation and go to step 4. Otherwise, select Modify Parameters to make setting changed.
  • Page 22 MultiMobile Owner’s Manual In the Network Drivers dialog box, press Add Adapter... button to enter Add Network Adapter dialog box. Select Unlisted or Updated Network Adapter and press OK. Windows will prompt a Install Driver dialog box. Place the Drivers diskette into the floppy drive and press OK.

  • Page 23: Ndis2 Driver For Workgroup

    NDIS2 Driver for Workgroup Run Windows for Workgroups and click the Network Setup icon in the Network group. In the Network Settings dialog box, click the Networks... button to select the network operating system. In the Networks dialog box, check the radio button before Install Microsoft Windows Network and No Additional Network.

  • Page 24: Odi Driver For Workgroups

    MultiMobile Owner’s Manual 12. Move the cursor to the setting(s) you want to change and press Enter to select a new value. When the configuration is set completely, press Enter on the OK field to exit the screen and go back to step 11.
  • Page 25 Place the driver diskette in the floppy drive and press OK. Select the Netware ODI Driver ... string and press OK. Follow the on-screen Windows’ instructions to complete the installation, then exit Windows. Run INSTALL.EXE from the root directory of the Drivers diskette.

  • Page 26: Windows Nt 3.51 / Nt 4.0 Installation

    MultiMobile Owner’s Manual Windows NT 3.51 / NT 4.0 Installation Install the PCMCIA support for your particular make and model of laptop from the Service Packs. Note that: These must be verified to be working properly before continuing, and Support for this level of driver is from the laptop manufacturer only.

  • Page 27: Windows 95 Installation

    Any questions on this layer must be taken up with the computer’s manufacturer. Insert the MT3410ZLX into PCMCIA slot. Windows 95 will prompt New Hardware Found dialog box (shown below). In New Hardware Found dialog box, select Driver from disk provided by hardware manufacturer.

  • Page 28: Artisoft Lantastic 6.0 Installation

    MultiMobile Owner’s Manual For a first-time MT3410ZLX installation, click Network icon in Control Panel of the Main Group to add the desired Protocols, Client and Service. Reboot the computer; the card is now fully functional. Artisoft Lantastic 6.0 Installation Install LANTASTIC 6.0 first.

  • Page 29: Chapter 3 - Comprehensive Driver Notes

    MT3410ZLX software drivers, as well as specific information on the NDIS, Packet Driver, and Windows for Workgroups drivers. Factory Default Settings The MT3410ZLX was shipped from the factory with the following default settings: Modem COM Port LAN IRQ LAN I/O Base Addr.
  • Page 30 Phoenix DEVICE=C:\PCMPLUS\PCMSCD.EXE If one of these lines exists in your CONFIG.SYS, it can be used to enable the MT3410ZLX PC Card. Follow the PCMCIA driver installation instructions in the PC’s manual. If the PC Card drivers do not support multi-function cards, use the Multi-Tech supplied enabler.

  • Page 31: Getting Started

    3 - Comprehensive Driver Notes Getting Started For Novell, Lan Manager, and Packet Driver, first insert the MT3410ZLX PC Card into an open PCMCIA card slot, and remove all other PC Cards from your computer. Insert the MT3410ZLX driver disk into Drive A and type A:\INSTALL at the command prompt.

  • Page 32: Driver Directory Structure

    Each directory contains a README.TXT file which provides detailed installation instructions for the drivers in that directory: CARDEN.EXE LM28ODI.COM MT3410ZLX DOS/ODI Driver LM28NDS.DOS MT3410ZLX DOS real mode LM28PD.COM LM28NDS.386 Direct PCMCIA Card Enabler for DOS; supports MT3410ZLX and Intel compatible, Compaq and Databook controllers.

  • Page 33: Driver Upgrades

    If using the downloaded drivers does not get the MT3410ZLX working properly, our technical experts are always ready to help. Please be at your computer, have your MT3410ZLX, Driver Disk, and the following information available: • Version number of CARDEN.EXE and any drivers you are running, •...

  • Page 34: Notes For Ndis Driver

    MultiMobile Owner’s Manual Notes for NDIS Driver The following are examples of partial CONFIG.SYS and AUTOEXEC.BAT files for loading System Soft‘s Card Services and NDIS2 driver: Example of partial CONFIG.SYS file: device=c:\cardsoft \ss365sl.exe device=c:\cardsoft \cs.exe device=c:\cardsoft \csalloc.exe c:\cardsoft\csalloc.ini device=c:\lanman.dos\drivers\ethernet\lm28\carden.exe /iop=nnn /irq=n /com=n /mir=n device=c:\cardsoft \cardid.exe device=c:\lanman.dos\deivers\protman.dos/i:c:\lanman.dos device=c:\lanman.dos\drivers\ethernet\lm28\lm28nds.dos...

  • Page 35: Notes For Packet Driver

    [LM28NDS2_NIF] DRIVERNAME - LM28NDS$ (This line must always be present.) IOADDRESS - value where value is one of the following addresses: 0x300, 0x320, 0x340, 0x360. (The leading 0x for the hex notation is required.) (To have Card Services select the address base from it’s pool of available addresses, use a value of 0 .) INTERRUPT - value where values is one of the following...

  • Page 36: Notes For Windows For Workgroups

    MultiMobile Owner’s Manual Notes for Windows For Workgroups After installation of the MT3410ZLX drivers, the system will automatically update the CONFIG.SYS and AUTOEXEC.BAT files so that the driver will be loaded at system startup. When modifying the two files, the system will make a dual copy named CONFIG.ABO and AUTOEXEC.ABO in the system’s...

  • Page 37: Chapter 4 - Troubleshooting

    Below are a number of examples of Problems (in bold text:), Causes (C:), and Solutions (S:). If your MT3410ZLX is not working properly, look up the problem and solution here; if unsuccessful, call Tech Support (see Chapter 5). At the end of this chapter is some specific steps for resolving IRQ and COM port conflicts.

  • Page 38: The Modem Does Not Execute The Command Line

    C: Make sure the modem is not in Data Mode. Type +++ if necessary. C: Make sure your software is set to the same COMx port as your MT3410ZLX. The Modem Does Not Give a Response After an AT Command Was Executed C: The echo and/or responses may be turned off by the ATE0Q1 commands.

  • Page 39: The Modem Does Not Auto-Answer The Phone

    The Modem Does Not Auto-Answer the Phone C: If necessary, make sure the software is configured to auto-answer the phone. A: To set auto-answer mode on from AT command mode, type ATS0=n then press Enter. The n stands for which number of rings the modem answers.

  • Page 40: No Text Appears On The Screen In Data Mode

    MultiMobile Owner’s Manual No Text Appears on the Screen in Data Mode C: The remote modem is not echoing your typed characters. Type ATE0 then press Enter at the command line. Then turn the software echo feature on. C: Your software may not be set to use Full Duplex or the remote modem may not be set to use Full Duplex either.

  • Page 41: The Modem Connects With Some Modems, But Not Others

    The Modem Connects with Some Modems, but Not Others C : The remote modem may not support data compression or error correction, which might cause it to take too long to negotiate a link. You might try changing the way the modem negotiates by using the AT&Qn , ATNn , and ATS37=n commands.

  • Page 42: The Modem Does Not Connect With Another Modem

    MultiMobile Owner’s Manual The Modem Does Not Connect with Another Modem C: There may be a problem with the remote modem if you do not hear the high pitched tone from the remote modem. Run the Remote Digital Loopback Test ( &T4 command).

  • Page 43: After Downloading A File, The File Does Not Store On Your Disk Drive

    After Downloading a File, the File Does Not Store on Your Disk Drive If both modems are using MNP or V.42 protocol, then flow control may not be enabled. Configure your software to use RTS/CTS flow control to cause your computer to pause long enough for the file to be stored to disk.

  • Page 44: When Using V.42Bis Or Mnp5, Some Features Are Disabled

    C: Your computer does not have enough memory to map the attribute memory of your MT3410ZLX. If memory management software (e.g., EMM386) is installed, you must reserve an area in upper memory (C000:0 — EFFF:F) for MT3410ZLX attribute memory when enabling the card.

  • Page 45: Enabling The Mt3410Zlx

    Reserve D000 - D3FF for attribute memory. C: No free I/O space or interrupt request can be assigned to the MT3410ZLX. The MT3410ZLX needs 32 contiguous I/O ports and one interrupt request for its LAN connection. It also need 8 contiguous I/O ports and another interrupt request for Fax/Modem.

  • Page 46: Installing The Win 95 Driver Over Systemsoft

    MultiMobile Owner’s Manual Installing The Win 95 Driver Over SystemSoft CardWorks 1. Start Windows 95, then plug the MT3410ZLX into the PCMCIA slot. The SystemSoft Cardwizard window should appear. 2. Select the appropriate slot number containing the MT3410ZLX. 3. Select the View pull down menu 4.

  • Page 47: The Netware Driver Runs Successfully But Fails To Login To The Netware Server

    The NetWare Driver Runs Successfully but Fails to Login to The NetWare Server C: The client Frame type is incompatiable with the server Frame type. The default frame type for Netware 3.11 and below is 802.3 but it changed to 802.2 in Netware 4.x and 3.12.

  • Page 48: Windows 95

    MultiMobile Owner’s Manual address and/or interrupt. If you wish to use COM3 or COM4, note that COM3 shares an IRQ with COM1, as does COM4 with COM2, so you should change their IRQs to unused ones, if possible. Windows 95 My Computer Properties Device...

  • Page 49: Chapter 5 - Service

    5 - Service Chapter 5 - Service This chapter begins with the terms of your modem’s warranty. Read carefully the next section, Tech Support, if you have questions or problems with your modem. It includes the technical support telephone numbers and an explanation of how to send in your modem should you require service.

  • Page 50: On-Line Warranty Registration

    To register your Multi-Tech product on-line, click on the following link: http://www.multitech.com/support/register.htm Software User License Agreement The MT3410ZLX software is licensed by Multi-Tech Systems, Inc. to the original end-user purchaser of the product, hereafter referred to as “licensee”. The License includes the distribution diskette, other accompanying programs, and the documentation.
  • Page 51 Multi-Tech Systems, Inc. proprietary interests and not to allow the use, copying or transfer by any means, other than in accordance with this agreement. Licensee agrees that any breach of this agreement will be damaging to Multi-Tech Systems, Inc.

  • Page 52: Tech Support

    MultiMobile Owner’s Manual Tech Support Multi-Tech has an excellent staff of technical support personnel available to help you get the most out of your Multi-Tech product. If you have any questions about the operation of your Multi-Tech modem, please call 1-800-972-2439. Please fill in the modem information form (below), and have it available when you call.

  • Page 53: Service

    If your tech support specialist decides that service is required, you may send your modem to our factory (freight prepaid). Return shipping charges will be paid by Multi-Tech Systems (with North America). Include the following with your modem: • A description of the problem.

  • Page 54: About The Multi-Tech Bbs

    MultiMobile Owner’s Manual About the Multi-Tech BBS Multi-Tech Systems maintains a bulletin board system (BBS) for its customers. The information available via the BBS includes new product information, product upgrade data, problem-solving tips, and a message service you can use to request additional information.

  • Page 55: About Compuserve/Internet

    Files Menu: From the Main Menu, type F to display the Files Menu. If you want a list of directories, type L (list directory) and then type L again for a list of all directories. If you do not type the second L, you will list all of the files on the BBS.

  • Page 56: About The Multi-Tech Fax-Back System

    MultiMobile Owner’s Manual About the Multi-Tech Fax-Back System Multi-Tech’s fax-back system provides 24-hour access to sales/marketing and technical literature. Dial (612) 717-5888, follow the voice prompts, and enter the document number for either the “Sales and Marketing” catalog or the “Technical Support” catalog of available documents.

  • Page 57: Appendix A - Technical Specifications

    Fax: • G3, V.17 14.4K bps, V.29 9.6K bps, V.27ter 2.4K bps • Fax Service Class 1 and Class 2 Compliant LAN: • IIEEE 802.3 10BaseT (MT3410ZLX), • 10Base2 • 10Mbps speed • Internal buffer memory (no system memory used) •...
  • Page 58 Weight: 1.225 oz. (35 g) • Power: Sleep Mode: 400mW (80 mA) Operating Mode: 750mW (150 mA) • One 15-pin connector with RJ-11 and RJ-45 plugs (MT3410ZLX) • One 15-pin connector with RJ-11 and BNC-T receptacles (MT3410ZLX-T/2) +5V ±5%, @220mA...

  • Page 59: Appendix B - At Commands, S-Registers & Result Codes

    Appendix B - AT Commands, S-Registers & Result Codes Introduction This chapter describes how to use MT3410ZLX AT commands, S-Registers and Result Codes. How To Use AT Commands Usually, your fax and data comm software controls the modem for you. However, you may also want to use the AT commands.

  • Page 60: Basic At Commands

    MultiMobile Owner’s Manual For example, type: ATH0<Enter> AT&K3<Enter> to enable bi-directional CTS/RTS Most of the AT commands can be entered in “strings” (i.e., on the same command line) without spaces between the individual commands. For example: AT&K3H0<Enter> As shown above, it is not necessary to put spaces between the commands.
  • Page 61 Command B1 * * Factory default setting Options Function & Description Select Bell 212A for 1200 bps connection and Bell 103 for 300 bps Select V.23 1200 bps for receiving, 75 bps for transmitting in originate mode; 75 bps for receiving and 1200 bps for transmitting in answer mode Select V.23 75 bps for receiving, 1200 bps for transmitting in originate mode;...
  • Page 62 MultiMobile Owner’s Manual Command M1 * N1 * O3 to O14 Q0 * * Factory default setting Options Function & Description AT command echo options Echo disabled Echo enabled Switch-hook control Modem goes on-hook Modem goes off-hook Speaker control Speaker always off Speaker on until carrier present Speaker always on Speaker off during dialing and on until...
  • Page 63 Command V1 * W0 * X4 * * Factory default setting Options Function & Description Result code disabled Enable tone dialing Result code form Display result code in numeric form (see also the result code options table) Display result code in verbose form Select extended result codes CONNECT result code reports DTE speed (see also the “Result Code...

  • Page 64: At& (Ampersand) Commands

    MultiMobile Owner’s Manual AT& (Ampersand) Commands Command &Bn &B0 &B1 * &B2 &Cn &C0 &C1 * &Dn &D0 &D1 &D2 * &D3 &F &Gn &G0 * &G1 &G2 &Jn &J0 * Factory default setting Options Function & Description Auto-retrain Hang up on a poor received signal Retrain on a poor received signal.
  • Page 65 Command &J1 &Kn &K0 &K3 * &K4 &Mn &M0 * &M4 &Pn &P0 * &P1 &Rn &R0 * &R1 &Sn &S0 * &S1 &Tn &T0 &T1 &T3 * Factory default setting Options Function & Description Send OK to DTE Set flow control Disable flow control Enable bi-directional hardware flow control (CTS/RTS)
  • Page 66 MultiMobile Owner’s Manual Command &T4 * &T5 &T6 &T7 &T8 &Vn &V0 &V1 &Wn &W0 &W1 &Yn &Y0 &Y1 &Zn=x * Factory default setting Options Function & Description Grant request from remote for RDL test Deny request from remote for RDL test Remote digital loopback test Remote digital loopback with self-test Local analog loopback with self-test...

  • Page 67: At% (Percent) Commands

    AT% (Percent) Commands Command %C1 * %G0 * AT\ (Back Slash) Commands Command \A0 * \C0 * * Factory default setting Options Function & Description Set auto-reliable fallback character n=1-127 Specify the ASCII character that tells the modem to return (or fallback) from auto-reliable (MNP) mode to a normal connection on the answering modem Data compression option...
  • Page 68 MultiMobile Owner’s Manual Command \G0 * \J0 * \K=n * Factory default setting Options Function & Description Set modem port flow control Disable port flow control Set port flow control to XON/XOFF Constant DTE speed option DCE and DTE rates are independent DTE rate adjusts to DCE connection rate after on-line Set break control...
  • Page 69 Command \N3 * * Factory default setting Options Function & Description n=0 or 1 Empty the data buffers and send the break to the remote modem n=2 or 3 Send break to the remote modem immediately n=4 or 5 Send break to the remote modem in sequence with data.
  • Page 70 MultiMobile Owner’s Manual Command \V0 * \X0 * * Factory default setting Options Function & Description Set inactive timer n=0 * Disable inactive timer n=1 - 90 Enable inactive timer. Length in minutes Protocol result codes Disable protocol result code (e.g. CONNECT 9600) Enable protocol result code (e.g.

  • Page 71: At- (Dash) Commands

    AT- (Dash) Commands Command Options -J1 * “Hn “H0 “H1 “H2 “H3 * * Factory default setting Function & Description Set V.42 detection phase Disable V.42 detection phase Enable V.42 detection phase Display firmware version number V.42bis compression control Disable V.42bis Enable V.42bis only when transmitting data Enable V.42bis only when receiving...

  • Page 72: S-Registers (Atsn=X)

    MultiMobile Owner’s Manual S-Registers (ATSn=x) Certain modem parameters are stored in memory locations called S-Registers. Use the S command to read or alter the contents of S-Registers. S0= 0-255 S0 sets the number of the rings required before the modem automatically answers a call. Set “S0=0” to disable auto-answer mode.
  • Page 73 Appendices S4= 0-127 S4 holds the decimal value of the character recognized as a line feed (asynchronous operation only). The line feed control character is output after the carriage return control character, if verbose result codes are enabled. The factory default is 010. S5= 0-127 S5 holds the decimal value of the character recognized as a backspace (asynchronous...
  • Page 74 MultiMobile Owner’s Manual S9=1-255 S9 sets the time, in tenths of a second, that the carrier must be present before the modem considers it valid and turns on RLSD. The factory default is 006. S10=1-255 S10 sets the length of time, in tenths of a second, that the modem waits before hanging up after a loss of carrier.
  • Page 75 S30=0-90 S30 controls the Inactivity timer, which sets the length of time, in minutes, that the modem counts when there is no data flow in or out the DTE serial port. A connection is disengaged when the counter reaches the preset value. Setting to S30 =0 disables the inactivity timer.
  • Page 76 MultiMobile Owner’s Manual S62 DTE rate status. The factory default is 016. 300 bps 600 bps 1200 bps 2400 bps 4800 bps 9600 bps 7200 bps 12000 bps 14400 bps 16800 bps 19200 bps 21600 bps 24000 bps 26400 bps 28800 bps 38400 bps S64 = 9-20...
  • Page 77 S72 selects DTE speed during data transfer. The factory default settings is 000. 300 bps 600 bps 600 bps 1200 bps 2400 bps 4800 bps 9600 bps 7200 bps 12000 bps 14400 bps 16800 bps 19200 bps 21600 bps 24000 bps 26400 bps 28800 bps 38400 bps...

  • Page 78: Result Codes

    MultiMobile Owner’s Manual Result Codes In Command mode, the MT3410ZLX can send information and status responses, or Result Codes, to your computer. Result Codes are used by communications programs and can also appear on your monitor. The form of the Result Code information displayed can be defined using the Qn , Vn , Wn and Xn commands.
  • Page 79 ATV0 ATV1 CONNECT RING NO CARRIER ERROR CONNECT 1200 NO DIAL TONE BUSY NO ANSWER CONNECT 2400 CONNECT 4800 CONNECT 9600 CONNECT 14400 CONNECT 19200 CONNECT 16800 CONNECT 57600 CONNECT 7200 CONNECT 12000 CONNECT 1200/75 CONNECT 75/1200 CONNECT 38400 CONNECT 21600 CONNECT 24000 CONNECT 26400 CONNECT 28800...
  • Page 80 MultiMobile Owner’s Manual ATV0 ATV1 CARRIER 300 CARRIER 75/1200 CARRIER 1200/75 CARRIER 1200 CARRIER 2400 CARRIER 4800 CARRIER 7200 CARRIER 9600 CARRIER 12000 CARRIER 14400 CARRIER 16800 CARRIER 19200 CARRIER 21600 CARRIER 24000 CARRIER 26400 CARRIER 28800 CARRIER 31200 CARRIER 33600 COMPRESSION: CLASS 5 COMPRESSION: V.42bis COMPRESSION: NONE...

  • Page 81: Appendix C - Regulatory Agency Information

    Appendices Appendix C - Regulatory Agency Information FCC Regulatory Statements Consumer Instructions 1. This equipment complies with part 68 of the Federal Communications Commission Rules. On the outside surface of this equipment is a label that contains, among other information, the FCC registration number and ringer equivalence number (REN).
  • Page 82 8. No repairs are to be made by you. Repairs are to be made only by Multi-Tech Systems or its licensees. Unauthorized repairs void registration and warranty. 9. This equipment cannot be used on public coin service provided by the telephone company.
  • Page 83 Manufacturer: Trade Name: Model Number: FCC Registration #: Ringer Equivalence: Modular Jack (USOC): Service Center in USA: Appendices Multi-Tech Systems, Inc. MultiMobile MT3410ZLX and MT3410ZLX-T/2 503TAI-30556-PT-E 0.6B RJ11C or RJ11W (single line) Multi-Tech Systems, Inc. 2205 Woodale Drive Mounds View, MN 55112...
  • Page 84 MultiMobile Owner’s Manual NOTE: This equipment has been tested and found to be comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a residential installation.

  • Page 85: Fcc Fax Update

    Appendices Warning: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. FCC Fax Update The Telephone Consumer Protection Act of 1991 makes it unlawful for any person to use a computer or other electronic device to send any message via a telephone fax machine unless such message clearly contains in a margin at the top or bottom of...
  • Page 86 MultiMobile Owner’s Manual Before installing this equipment, users should ensure that it is permissible to be connected to the facilities of the local telecommunications company. The equipment must also be installed using an acceptable method of connection. The customer should be aware that compliance with the above conditions may not prevent degradation of service in some situations.

  • Page 87: Index

    About This Manual ... 7 About This Product ... 7 Ampersand Commands ... 64 Artisoft Lantastic 6.0 Installation ... 28 AT Commands, S-Registers and Result Codes ... 59 Auto-answer ... 39, 72 Back Slash Commands ... 67 backspace character ... 73 Basic AT Commands ...
  • Page 88 MultiMobile Owner’s Manual Dash Commands ... 71 Data Specifications ... 57 Desired DCE speed ... 75 Dimensions ... 8 DOS Extended Memory Managers ... 31 Driver Directory Structure ... 32 Driver Installation Screen ... 15 Driver Software Installation ... 14 Drivers Upgrades ...
  • Page 89 Index Inactivity timer ... 75 Incoming rings ... 72 Installation ... 12, 29 Installing The MT3410ZLX or MT3410ZLX-T/2 Card(s) ... 12 Introduction and Description ... 7, 37 LAN Specifications ... 57 Line feed character ... 73 Loss of carrier setting ... 74 Manual Driver Installation ...
  • Page 90 MultiMobile Owner’s Manual NDIS Driver ... 34 NDIS2 Driver for Workgroup ... 23 NDIS3 Driver for Workgroup ... 21 NetWare driver/NetWare Server ... 47 Network ... 8 NOS Selection Screen ... 14 Novell Client Installation ... 17 Novell NetWare Installation ... 14 ODI Driver for Workgroups ...
  • Page 91 Index S-Registers ... 72 Service ... 49, 53 Ship Kit Contents ... 10 Software Installation ... 14 software problem ... 39 Software User License Agreement ... 50 Specifications ... 57 Technical support ... 52, 53, 54, 55 Transmitting power level adjustment ... 76 Troubleshooting ...
