Parameters
Los parámetros, Paramètres, Parameter
24.50
F s :
Hz
7.81
Q ms :
0.217
C ms :
mm/N
: 194.47
M ms
3.83
R ms :
kg/s
8.856
V as :
ft³ (
0.370
X max :
13.382
D:
in (
140.59
S d :
in² (
52.02
V d :
in³ (
0.93
Q es :
1.71
R e :
Ω
7.42
B l :
Tm
250
P rms :
Watts
0.831
Q ts :
0.382 %
η ο
:
88.40
SPLo:
SPL 2.83V/1m :
DESIGNED EXCLUSIVELY FOR
AMPLIFIERS
Recommended Power Rating of
La Potencia nominal recomendada, Le Pouvoir recommandé Evaluant, Empfohlene Kraft Einzuschätze
g
250.72
liters)
9.40
in (
mm)
339.90
mm)
907.00
cm²)
0.85
liters)
dB
94.63
dB
125 - 250 Watts RMS
T4515-44

Specifications

Las especificaciones , Spécifications, Spezifikationen
21A7470
