Page 1: Owners Manual
4545 E BASELINE RD PHOENIX AZ 85040-6400 21A3087 FIRST CLASS STAMP HERE MODEL 620WE IN-WALL ENCLOSED LOUDSPEAKER OWNERS MANUAL... - Page 2 The Model 620WE utilizes its mounting wings to mount into a wall like conventional in-wall speakers, while incorporating an integral enclosure to provide a vapor barrier between you and the outside world.
- Page 3 As this is not always possible in keeping with aesthetic design of a particular room, the Model 620WE loudspeaker is designed with a pivoting tweeter which rotates to allow you to “aim” the high frequencies toward the listening position.
- Page 4 Attach loudspeakers wires to speaker terminals, observing correct polarity (positive to positive and negative to negative). Insert the speaker into the mounting hole. Be careful not to pinch the loudspeaker wires in the process. using the integral bubble levels located on the baffle, align the speaker’s frame either horizontally or vertically.
