MTD 320BVR Parts List

3
32
5
2
3
8
1
Item Part No. Description
1 753-04511 Air Cleaner/Muffler Cover Assembly
(includes 2 & 32)
2 791-180350B Air Cleaner Filter
3 791-180351 Carburetor Mounting Screw
4 791-180226 Wavey Washer
5 791-182070 Choke Knob and Screw
6 753-04418 Choke Lever Assembly (includes 5)
7 753-04419 Choke Lever and Plate (includes 6)
8 753-04333 Carburetor Assembly (includes 9 & 20)
9 791-610675 Carburetor Gasket
10 791-181860 Carb Mount Screw
11 791-683974B Primer and Hose Assembly
12 753-1196 Carb Mount Assembly (includes 10,13 & 14)
13 791-684451 Reed Assembly
14 753-1208 Carburetor Mount Gasket
15 753-04328 Crank Case Service Assembly
(includes 10)
16 791-612134 Rear Mounting Pad
17 753-04310 Fuel Tank Assembly (includes 18-20)
18 791-182438 Fuel Cap Assembly
19 791-181086 Fuel Return Line
20 791-682039 Fuel Line Assembly
21 791-145308 Front Mounting Pad
22 753-04409 Shroud Extension (includes 32)
23 791-182736 Flywheel Assembly
24 753-04481 Spacer
25 753-1199 Recoil Pulley Assembly
26 791-613102 Recoil Spring
27 791-611061 Rope Guide
28 791-180930 Pulley Retainer Assembly
4
6
7
11
13
9
10
12
14
42
43
38
39
40
41
ENGINE PARTS - MODEL 320BVR
2-CYCLE GAS MULCHING BLOWER VACUUM
16
18
17
21
19
47
15
45
46
44
37
36
34
Item Part No.
29 791-181079
30 791-613103
31 791-181862
32 791-181345
33 791-181931
34 791-182402
35 753-04109
36 791-610311B Spark Plug
37 753-04619
38 753-04689
39 753-04690
40 753-04691
41 753-04315
42 753-04620
43 753-04618
44 753-04323
45 753-04367
46 753-1197
47 791-182723
48 791-181524
49 791-182368
* 753-1209
* 753-04395
* Items Not Shown
20
23
24
25
26
35
28
22
33
Description
Pull Handle
Rope
Housing Screw
Cover Screw
Starter Housing Assembly (includes 25-32)
Wire Lead Assembly
Module Assembly
Exhaust Gasket
Spark Arrestor Screen
Plate
Hood
Screw
Muffler Mounting Bolt Assembly
Muffler Assembly (includes 37-42)
Cylinder Assembly (includes 46 & 47)
Piston and Rod Assembly
Cylinder Gasket
Cylinder Bolt
Crankshaft Extension
Washer
Piston Ring
Short Block Assembly
(includes 10, 15, 36, 44-47)
PPN- 41BS320G734
29
27
30
31
48
49
32
Issued 1/04
